Lane ESD Technology Services Core Firewall Overview Districts Behind Firewall Blachly Creswell Crow-Applegate-Lorane Fern Ridge Junction City Lowell Mapleton Screened, but exempt from policies Marcola

SLIDE 1

Lane ESD Technology Services Core Firewall Overview

SLIDE 2

Districts Behind Firewall

Blachly
Creswell
Crow-Applegate-Lorane
Fern Ridge
Junction City
Lowell
Mapleton
Marcola
McKenzie
Oakridge
Pleasant Hill
Siuslaw
South Lane

Screened, but exempt from policies

Bethel
Lane Community College
Lane ESD

SLIDE 3

Netscreen-1000 ISG

SLIDE 4

SLIDE 5

SLIDE 6

SLIDE 7

Reports

Lane ESD sent a report to districts with

their respective policies earlier October.

Any comments or questions around the

reports?

Are you okay with the method of transfer

and format?

SLIDE 8

What to include when submitting a policy request?

Short description
Source address or source address group
Destination address or destination address group
Service (what protocol or port #) or service group
Action (accept, deny, reject)

SLIDE 9

To Deny or Reject?

Deny – simply drops packet Reject – drops the packet and sends a TCP reset (RST) segment to the source host for TCP traffic and an ICMP “destination unreachable, port unreachable” message (type 3, code 3) for UDP traffic.

SLIDE 10

Do you require a traffic counter or policy log?
Do you require policy scheduling? Do you need a one time

exception?

Troubleshooting and Monitoring

SLIDE 11

Traffic Counters

The total number of bytes of traffic to which this policy applies and records the information in historical graphs.

SLIDE 12

Policy Logs

SLIDE 13

Device and Support

Juniper has not issued any notices regarding hardware EOL.
Juniper has announced the end of engineering and support for

ScreenOS 6.3 on 01/23/2020.

LESD maintains a support contract with Juniper and keeps up with

firmware upgrades.

LESD backs up configuration three times a week.
We send all security level notices to our syslog. Daily log sizes range

from 1.8GB to 2.8GB.

SLIDE 14

Syslog

2014-10-07 09:00:46

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00012: UDP flood! From 163.41.125.10:1060 to 163.41.62.5:514, proto UDP (zone netsrvs-untrust int ethernet1/3). Occurred 1 times. (2014-10-07 09:00:54)<000>

2014-10-07 09:00:46

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00008: IP spoofing! From 59.156.126.171:6881 to 163.41.117.203:45433, proto UDP (zone inet-trust int ethernet1/2). Occurred 2 times. (2014-10-07 09:00:54)<000>

2014-10-07 09:00:46

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00008: IP spoofing! From 93.180.5.26:42378 to 163.41.116.98:53, proto UDP (zone inet-trust int ethernet1/2). Occurred 1 times. (2014-10-07 09:00:54)<000>

2014-1
2014-10-07 09:00:56" duration=0 policy_id=226 service=udp/port:62563 proto=17 src zone=Global dst zone=Global action=Deny sent=0 rcvd=28

src=1.234.228.119 dst=163.41.3.174 src_port=28247 dst_port=62563 session_id=0 reason=Traffic Denied<000>

2014-10-07 09:00:48

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00008: IP spoofing! From 202.107.198.250 to 163.41.118.109, proto 1 (zone inet-trust int ethernet1/2). Occurred 1 times. (2014-10-07 09:00:56)<000>

2014-10-07 09:00:48

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00008: IP spoofing! From 202.107.198.250:1681 to 163.41.118.109:49153, proto UDP (zone inet-trust int ethernet1/2). Occurred 1 times. (2014-10-07 09:00:56)<000>

2014-10-07 09:00:48

Local5.Alert 163.41.62.249 core1-fw: NetScreen device_id=core1-fw [Root]system-alert-00008: IP spoofing! From 118.209.38.14:57398 to 163.41.117.151:46342, proto UDP (zone inet-trust int ethernet1/2). Occurred 1 times. (2014-10-07 09:00:56)<000>
