KMT - Kraus Messtechnik GmbH Germany

Founded in 1979 “Contactless data transmission from rotating or moving parts”

Application areas

Automotive Heavy Industry Mechanical Engineering Railway Shipbuilding Test Bench Wind Energy Aviation

Applications

Automotive

Torque measurement on belt disk at engine Torque wheel telemetry Temperature measurement on break disk Vibration measurement at car wheel Sensorless Speed & RPM measurement Point to point telemetry at test ground Torque measurement on drive shaft Pass-by noise telemetry for sound and TTL

Applications

Force & vibration measurement aircraft propeller Telemetry for helicopter main rotor Temperature measurement on break disk Torque measurement on drive shaft Small tracking antennas Telemetry for helicopter rotor test bench Air to ground radio network up to 50km range

Aviation

Telemetry for helicopter tail rotor

Applications

Force meas. at road building machine Force measurement at tank drive wheel Force measurement at fork lifter Torque measurement at dump truck Torque- measurement at corn harvester Torque meas. at earth moving machines Force measurement at snow groomer Torque measurement at large e-drives

Heavy Industry

Applications

Vibration measurement at fan blades Force measurement at beer brewery TTL incremental telemetry at cable manufacturing

• Temp. & force

measurement at grinding machine Force measurement on propeller shaft Force measurement at milling machine Force measurement at snow groomer Force measurement at choppers blades

Mechanical Engineering

Applications

• Temp. & force

measurement at break disk Force & torque measurement at railway wheel Force & torque measurement at tram wheel Force & torque measurement at railway wheel Force & torque measurement at railway test bench Temperature measurement at break disk Force & torque measurement at railway wheel Force & torque measurement at railway wheel

Railway

Applications

Torque meas. at big >100cm ø ship drive shaft Torque meas. at big 80cm ø ship drive shaft Torque & bending

• meas. at ship drive

shaft test bench Torque meas. at hovercraft drive shaft

• Temp. meas. at

ship drive shaft bearings Torque meas. at military frigate drive shaft Torque meas. at ship power generator shaft

Shipbuilding

Torque meas. at big >100cm ø ship drive shaft

Applications

Force meas. at water turbine test bench Force meas. at rail simulation test bench Torque & bending

• meas. at ship drive

shaft test bench Force meas. at planet gear box test bench Temperature measurement at tire test bench Torque meas. at gear test bench

Test bench

Force & vibration at helicopter main rotor test bench Force & torque measurement at railway test bench

Applications

Force & vibration

• meas. at blades of

wind turbine Torque meas. at rotor shaft of wind turbine Torque meas. at rotor shaft of wind turbine Bending meas. at rotor shaft of wind turbine Torque meas. at generator shaft of wind turbine Torque meas. at generator shaft of wind turbine Force meas. in planet gear box of wind turbine Force meas. at rotor hub of wind turbine

Wind Energy

Our product range

1-Channel telemetry for rotating shafts Multi-Channel telemetry for rotating shafts Point-to-point telemetry Rotating telemetry for wheels and rotors Thermo telemetry Steering torque sensor Sensor less Speed & RPM measurement Data Acquisition Software

1- Channel telemetry for rotating applications

TEL1-PCM-ENC in standard housing TEL1-PCM-ENC in heavy duty housing TEL1-PCM-ENC in end of shafts housing TEL1-PCM inductive power & data head TEL1-PCM-ENC

• n flexible PCB

TEL1-PCM decoder & ind. power generator TEL1-PCM-ENC in 2-half-collar housing for shafts TEL1-PCM-ENC in 2-half-collar housing large shafts

1- Channel telemetry for rotating applications

TEL1-PCM - block diagram

1- Channel telemetry for rotating applications

TEL1-PCM – SET of a standard delivery

Multi-channel telemetry for rotating applications

MT32-STG strain gage module 1 CH on PCB setup by jumper MT32 modules 8 CH RING for wind turbine MT32 modules 16 CH on railway shaft MT32 modules 4 CH for water turbine test MT32 modules 8 CH with encoder and transmitter MT32 modules 32 CH for planet gear box test MT32 modules 16 CH RING for railway MT32 decoder with data pickup

Multi-channel telemetry for rotating applications

MTP-STG strain gage module 2 CH on PCB setup by software MTP modules 8 CH with encoder MTP modules 8 CH with power & data head MTP modules 16 CH RING for water turbine MTP modules 24 CH with encoder & cable loom MTP-STG 4 CH strain gage module 4 CH housing MTP inductive power set with coil ring MTP SET with radio transmission and battery power

Multi-channel telemetry for rotating applications

MT32 - block diagram

Multi-channel telemetry for rotating applications

MT32 – SET example

Multi-channel telemetry for point to point

CT2-Mini ENC 2 CH transmitter with signal conditioning CTP4-ENC 4 CH transmitter with signal conditioning CTP16-ENC 16 CH transmitter with signal conditioning CTP16-ENC 16 CH transmitter

• pen, easy to

change SC Setup your signal conditioning modules easy by web interface CTP8-ENC 8 CH transmitter with signal conditioning HF diversity Box with 2 or 4 receiver for best radio signal quality CTP16-ENC 16 CH decoder with analog or digital IP-LAN OUT

Multi-channel telemetry for point to point

CTP – SET transmitting side with 1 TX antennas, LAN-Setup box, Sensor & power cables

Multi-channel telemetry for point to point

CTP – SET receiver side with 4 RX antennas, HF-Box, CTP16-Decoder, BNC16-Box

Multi-CH telemetry for rotating for wheels & rotors

CT2-Mini ENC 2 CH transmitter with signal conditioning CTP4-ENC 4 CH transmitter with signal conditioning CTP16-ENC 16 CH transmitter with signal conditioning CTP8-ENC 8 CH transmitter

• pen, easy to

change SC Setup your signal conditioning modules easy by web interface CTP8-ENC 8 CH transmitter with signal conditioning RF diversity Box with 2 or 4 built-in receivers for best radio signal quality CTP16/32-ENC 16-32 CH decoder with analog or digital IP-LAN OUT

Multi-CH telemetry for rotating for wheels & rotors

CTP16-Rotate – SET with 2 RX antennas, BATT-Charger, CTP16-Decoder, BNC16-Box, sensor and power cables, LAN-Setup-box

Thank you for your attention!

KMT - Kraus Messtechnik GmbH Gewerbering 9 D-83624 Otterfing - Germany

• Tel. +49-8024-48737

Fax +49-8024-5532 Email: info@kmt-telemetry.com Web: www.kmt-telemetry.com Martin Kraus
