Kill-Safe Synchronization Abstractions Matthew Flatt Robert Bruce Findler University of Utah University of Chicago 1 Sibling Food-Sharing Protocol 2 Sibling Food-Sharing Protocol 3 Sibling Food-Sharing Protocol 4 Sibling Food-Sharing

slide-1
SLIDE 1

Kill-Safe Synchronization Abstractions

Matthew Flatt University of Utah Robert Bruce Findler University of Chicago

1

slide-2
SLIDE 2

Sibling Food-Sharing Protocol

2

slide-3
SLIDE 3

Sibling Food-Sharing Protocol

3

slide-4
SLIDE 4

Sibling Food-Sharing Protocol

4

slide-5
SLIDE 5

Sibling Food-Sharing Protocol

5

slide-6
SLIDE 6

Sibling Food-Sharing Protocol

6

slide-7
SLIDE 7

Sibling Food-Sharing Protocol

7

slide-8
SLIDE 8

Sibling Food-Sharing Protocol

  • By inspection, the protocol is fair
  • No parental supervision required

8

slide-9
SLIDE 9

Sharing among Processes

9

slide-10
SLIDE 10

Sharing among Processes

10

slide-11
SLIDE 11

Sharing among Processes

11

slide-12
SLIDE 12

Sharing among Processes

12

slide-13
SLIDE 13

Sharing among Processes

  • Queue should be safe and fair
  • Should require no kernel supervision

13

slide-14
SLIDE 14

Sharing in Java

synchronized

14

slide-15
SLIDE 15

Sharing in Java

synchronized Thread.stop ⇒ synchronized isn't enough

15

slide-16
SLIDE 16

Sharing in Java

synchronized Thread.stop ⇒ synchronized isn't enough

16

slide-17
SLIDE 17

Sharing in Java

synchronized ... Thread.stop ⇒ synchronized isn't enough

17

slide-18
SLIDE 18

Sharing in Java

synchronized ... Thread.stop ⇒ synchronized isn't enough ∴ Java has no Thread.stop

18

slide-19
SLIDE 19

Why Terminate?

  • Execute code in a programming environment (DrScheme)

19

slide-20
SLIDE 20

Why Terminate?

  • Execute code in a programming environment (DrScheme)
  • Cancel actions that allocate resources (HTML browser)

20

slide-21
SLIDE 21

Why Terminate?

  • Execute code in a programming environment (DrScheme)
  • Cancel actions that allocate resources (HTML browser)
  • Stop misbehaving servlets (web server)

21

slide-22
SLIDE 22

Building Kill-Safe Abstractions

abstraction abstraction thread-safe abstraction thread-safe abstraction kill-safe thread-safe abstraction kill-safe thread-safe abstraction

22

slide-23
SLIDE 23

Building Kill-Safe Abstractions

abstraction abstraction Programmer effort — but generally understood thread-safe abstraction thread-safe abstraction kill-safe thread-safe abstraction kill-safe thread-safe abstraction

23

slide-24
SLIDE 24

Building Kill-Safe Abstractions

abstraction abstraction Programmer effort — but generally understood thread-safe abstraction thread-safe abstraction Programmer effort — the subject of this talk kill-safe thread-safe abstraction kill-safe thread-safe abstraction

24

slide-25
SLIDE 25

Building Kill-Safe Abstractions

abstraction abstraction Start with Concurrent ML [Reppy 88] thread-safe abstraction thread-safe abstraction kill-safe thread-safe abstraction kill-safe thread-safe abstraction

25

slide-26
SLIDE 26

Building Kill-Safe Abstractions

abstraction abstraction Start with Concurrent ML [Reppy 88] thread-safe abstraction thread-safe abstraction Add MzScheme's custodians and a little more kill-safe thread-safe abstraction kill-safe thread-safe abstraction

26

slide-27
SLIDE 27

Sharing in Concurrent ML

27

slide-28
SLIDE 28

Sharing in Concurrent ML

28

slide-29
SLIDE 29

Sharing in Concurrent ML

29

slide-30
SLIDE 30

Sharing in Concurrent ML

Abstraction-as-process naturally supports termination

30

slide-31
SLIDE 31

Sharing in Concurrent ML

Abstraction-as-process naturally supports termination Remaining problem: who controls the abstraction's process?

31

slide-32
SLIDE 32

Managing Processes and Threads

32

slide-33
SLIDE 33

Managing Processes and Threads

33

slide-34
SLIDE 34

Managing Processes and Threads

= custodian = capability to execute

34

slide-35
SLIDE 35

Managing Processes and Threads

= custodian = capability to execute

35

slide-36
SLIDE 36

Managing with Custodians

36

slide-37
SLIDE 37

Managing with Custodians

37

slide-38
SLIDE 38

Managing with Custodians

38

slide-39
SLIDE 39

Managing with Custodians

39

slide-40
SLIDE 40

Managing with Custodians

Queue terminated with servlet

40

slide-41
SLIDE 41

Thread-Safe Abstractions

A language to support abstractions:

  • Concurrent ML primitives for thread communication
  • Custodians for process hierarchy

Each abstraction:

  • Manager thread for state

41

slide-42
SLIDE 42

Towards Kill Safety with Custodians

42

slide-43
SLIDE 43

Towards Kill Safety with Custodians

43

slide-44
SLIDE 44

Towards Kill Safety with Custodians

Not kill-safe among servlets

44

slide-45
SLIDE 45

Kill Safety through Joint Custody

45

slide-46
SLIDE 46

Kill Safety through Joint Custody

46

slide-47
SLIDE 47

Kill Safety through Joint Custody

47

slide-48
SLIDE 48

Kill Safety through Joint Custody

48

slide-49
SLIDE 49

Kill Safety through Joint Custody

Queue runs exactly as long as servlets

49

slide-50
SLIDE 50

Why a Thread can have Multiple Custodians

50

slide-51
SLIDE 51

Why a Thread can have Multiple Custodians

51

slide-52
SLIDE 52

Why a Thread can have Multiple Custodians

52

slide-53
SLIDE 53

Why a Thread can have Multiple Custodians

53

slide-54
SLIDE 54

Why a Thread can have Multiple Custodians

54

slide-55
SLIDE 55

Why a Thread can have Multiple Custodians

Queue is only mostly dead

55

slide-56
SLIDE 56

Why a Thread can have Multiple Custodians

Queue is only mostly dead

56

slide-57
SLIDE 57

Why a Thread can have Multiple Custodians

Use queue ⇒ grant custodian

57

slide-58
SLIDE 58

Kill-Safe Abstractions

A language to support abstractions:

  • Concurrent ML primitives for thread communication
  • Custodians for process hierarchy
  • Operation to grant a thread another custodian

Each abstraction:

  • Manager thread for state
  • Each action grants custodian to manager thread

58

slide-59
SLIDE 59

Non-Solution #1 — Atomic Region

= atomic

59

slide-60
SLIDE 60

Non-Solution #1 — Atomic Region

= atomic Queue might harm

  • ther servlets

60

slide-61
SLIDE 61

Non-Solution #2 — Disjoint Process

61

slide-62
SLIDE 62

Non-Solution #2 — Disjoint Process

62

slide-63
SLIDE 63

Non-Solution #2 — Disjoint Process

63

slide-64
SLIDE 64

Non-Solution #2 — Disjoint Process

Queue runs forever

64

slide-65
SLIDE 65

Non-Solution #3 — Meta-Servlet

65

slide-66
SLIDE 66

Non-Solution #3 — Meta-Servlet

Merely moves the “kernel”

66

slide-67
SLIDE 67

Solution — Joint Custody

67

slide-68
SLIDE 68

Details (See Paper)

  • Custodians granted through thread-resume
  • CML's guard-evt a natural place for thread-resume
  • Improved nack-guard-evt for two-step protocols
  • Kill-safe does not always imply break-safe, nor vice-versa

68

slide-69
SLIDE 69

A Thread-Safe Queue

(define-struct safe-q (put-ch get-ch)) (define (safe-queue) (define q (queue)) (define get-ch (channel)) (define put-ch (channel)) (define (q-loop) (sync (choice-evt (wrap-evt (channel-send get-ch (peek q)) (lambda () (get q))) (wrap-evt (channel-recv put-ch) (lambda (v) (put q v))))) (q-loop)) (spawn q-loop) (make-safe-q put-ch get-ch)) (define (safe-get sq) (channel-recv (safe-q-get-ch sq))) (define (safe-put sq v) (channel-send (safe-q-put-ch sq) v))

69

slide-70
SLIDE 70

A Kill-Safe Queue

(define-struct safe-q (manager-t put-ch get-ch)) (define (safe-queue) (define q (queue)) (define get-ch (channel)) (define put-ch (channel)) (define (q-loop) (sync (choice-evt (wrap-evt (channel-send get-ch (peek q)) (lambda () (get q))) (wrap-evt (channel-recv put-ch) (lambda (v) (put q v))))) (q-loop)) (define manager-t (spawn q-loop)) (make-safe-q manager-t put-ch get-ch)) (define (safe-get sq) (resume sq) (channel-recv (safe-q-get-ch sq))) (define (safe-put sq v) (resume sq) (channel-send (safe-q-put-ch sq) v)) (define (resume sq) (thread-resume (safe-q-manager-t sq) (current-thread)))

70
