Andrew Verstak averstak@kermetico.com www.kermetico.com Kermetico High Velocity Air-Fuel Thermal Spray HVAF Application Development 1. Superior hard & tough coatings for new markets Gas-tight WC-based 1,500-1,700 HV 300 Cr 3 C 2

slide-1
SLIDE 1

Kermetico High Velocity Air-Fuel Thermal Spray

Andrew Verstak averstak@kermetico.com www.kermetico.com

slide-2
SLIDE 2

HVAF Application Development

  • 1. Superior hard & tough coatings for new markets

 Gas-tight  WC-based 1,500-1,700 HV300  Cr3C2-based 1,100 HV300, service up to 900oC  MoB-based 1,200 HV300, service up to 1,100oC  Thin coatings (40-70 micron) for:

High and alternating stress, impact, etc. Economy grades for “flash chrome” replacement

www.kermetico.com averstak@kermetico.com 2

slide-3
SLIDE 3

www.kermetico.com averstak@kermetico.com 3

HVAF Application Development

  • 2. Economical “currently specified quality” coatings

for existing and new markets 1,200 HV300 /<0.8% porosity WC-coatings, sprayed at 65-70% DE with spray rates 33+ kg/hour

slide-4
SLIDE 4

Kermetico HVAF Gun Design

Fuel Gas Air Powder + carrier gas Nozzle Combustion chamber Ceramic insert

1100-1500 m/s 850 m/s 40-50 m/s Gas velocity <1500oC ~1600oC 1900oC Gas temperature Spray particle Acceleration Heating

www.kermetico.com averstak@kermetico.com 4

slide-5
SLIDE 5

Combustion Temperature: HVAF vs. HVOF

Adiabatic combustion temperature of fuels in oxygen and air (a=1, 20oC, 1 Bar)

www.kermetico.com averstak@kermetico.com 5

3052 2526 2927 3200 3109 1960 1980 2010 2210 2093 500 1000 1500 2000 2500 3000 3500 Methane Propane MAPP Hydrogen Kerosene

T, oC

Oxygen Air

Metals, T melting Metals, T boiling

slide-6
SLIDE 6

www.kermetico.com averstak@kermetico.com 6

HVOF:

Combustion temperature is higher by more than 1000oC than melting temperature of metals; Combustion temperature may exceed metal boiling temperature.

HVAF:

Combustion temperature only slightly higher than metal melting temperature.

Lower Gas Temperature in HVAF:

slide-7
SLIDE 7

Lower Gas Temperature in HVAF:

Affects coating properties

Prevention of oxidation of metals and oxidation/ thermal deterioration of carbides Note: oxygen activity is 5-times lower in HVAF

Influences gun design

HVAF ability to use heating in long/ slow-gas combustion chambers = long time for “soft” heating High pressure in the chamber = better heat transfer

www.kermetico.com averstak@kermetico.com 7

slide-8
SLIDE 8

Combustion Temperature: AF vs OF Design

Ability to use heating in long/ slow-gas combustion chambers = long time for “soft” heating High pressure in the chamber = better heat transfer Result: High energy efficiency of HVAF (same or lower power while higher spray rates than HVOF)

www.kermetico.com averstak@kermetico.com 8

slide-9
SLIDE 9

Energy Efficiency = COST

State-of-the-art HVOF: JP 5000 270 kW spray rate 5 kg/hour DJ 2600 115 kW spray rate 4 kg/hour Kermetico HVAF: AK6 130 kW spray rate 28 kg/ hour AK5 80 kW spray rate 15 kg/hour AK-ID 30 kW spray rate 5 kg/hour

www.kermetico.com averstak@kermetico.com 9

slide-10
SLIDE 10

Acceleration of spray particles in the nozzle: Gas velocity & density Time (nozzle length) Particle size Smaller particles are accelerated to higher velocities. HVAF uses smaller particle size without material

  • xidation/ thermal deterioration

www.kermetico.com averstak@kermetico.com 10

slide-11
SLIDE 11

Note on nozzle wall influence on particle velocity: HVOF – dramatic (more so – in radial injection) HVAF – no influence

www.kermetico.com averstak@kermetico.com 11

slide-12
SLIDE 12

Particles Acceleration: Influence of the Nozzle Walls

HVOF (kerosene) per A. Voronetsky et. all, ITSC2004

Influence of Rp on the mean particles velocity at LS=250 mm. (pсс =0.9 MPa, dp=30 μm, Lb=100 mm)

Rp= D powder jet / D nozzle

www.kermetico.com averstak@kermetico.com 12

Nozzle wall Nozzle axis

slide-13
SLIDE 13

Particles Acceleration in the Nozzle

Kermetico HVAF: D powder jet / D nozzle = 0.1-0.2 I. There is practically no restriction on the nozzle length to reach necessary acceleration of spray particles II. Uniform acceleration = uniform coating structure and properties

www.kermetico.com averstak@kermetico.com 13

slide-14
SLIDE 14

Uniformity of HVAF Coatings Properties:

Hardness of HVOF and Kermetico HVAF WC-10Co-4Cr coatings (Schlumberger, UK)

HVAF HVOF

www.kermetico.com averstak@kermetico.com 14

Relative standard deviation, % HVAF: 3.9 % HVOF: 15.7-17.8%

slide-15
SLIDE 15

WC-10Co-4Cr Coating Characterization

Propane 1470 HV300

www.kermetico.com averstak@kermetico.com 15

slide-16
SLIDE 16

WC-10Co-4Cr Coating Characterization

Propane- 60% Butane 1500 HV300 Propylene 1650 HV300

www.kermetico.com averstak@kermetico.com 16

slide-17
SLIDE 17

Kermetico HVAF:

Carbides are hard, but… ductile

30 40 50 60 70 80 90 500 1000 1500 2000

2

C4 Coating

Powder 3 3 2 2 2 1 1 1 1 1 1 1 1

1:WC 2:Co3W3C 3:Co

1

2/degree Internsity/a.u.

3 3 2 2 2

WC-12Co Propane 1540 HV300

www.kermetico.com averstak@kermetico.com 17

slide-18
SLIDE 18

Data of Central Power Research Institute Bangalore, India

Comparison of WC-10Co-4Cr coatings, deposited with HVOF (JP5000) and Kermetico HVAF (AK06)

Notes: HVOF optimized for the best cavitation resistance HVAF applied in different modes, targeting different particle velocity (coating hardness)

www.kermetico.com averstak@kermetico.com 18

slide-19
SLIDE 19

Spray Parameters: Normalized

JP5000 HVOF Kermetico AK6 HVAF Nozzle 5L Nozzle 5E Nozzle 5O Oxidizer flow, SLPM O2: 873.1 Air: 2,104 (O2: 421.0) Fuel, g/sec 5.01 2.65 O2/Fuel Ratio vs. Stoichiometric 1.16 (Oxidizing) 1.03 (~Neutral) Carrier Nitrogen, SLPM 10.85 21 Combustion pressure, Bar 7.56 5.25 Powder feed rate, g/sec 1.50 2.22 Particle average size, micron 27 18 Particle velocity, m/s 740 895 +/-2 960 +/-3 1010+/-4 Particle temperature, oC 1790-1840 1470 +/-10 1460 +/-10 1470 +/-10 Particle kinetic energy, mJ 29.4 12.7 14.7 16.2 Energy density, GJ/m3 = = Contact pressure, GPa 3.8 5.6 6.4 7.1

www.kermetico.com averstak@kermetico.com 19

slide-20
SLIDE 20

Mechanical Properties: WC-10Co-4Cr

140 70 58 54 1180 1308 1439 1473

200 400 600 800 1000 1200 1400 1600 JP5000 HVOF AK06-N 5L AK06-N 5E AK06-N 5O

Vickers Hardness of WC-10Co-4Cr coatings

Hardness, HV300 Standard Deviation, HV300

www.kermetico.com averstak@kermetico.com 20

slide-21
SLIDE 21

Mechanical Properties: WC-10Co-4Cr

0,70 0,50 0,80 0,15 3,86 6,33 6,86 5,60

0,00 1,00 2,00 3,00 4,00 5,00 6,00 7,00 8,00 JP5000 HVOF AK06-N 5L AK06-N 5E AK06-N 5O

Fracture Toughness K1C of coatings, MPa*m1/2

K1C K1C Standard Deviation

www.kermetico.com averstak@kermetico.com 21

slide-22
SLIDE 22

Mechanical Properties: WC-10Co-4Cr

21 21 20 20

290 411 452 450

100 200 300 400 500 JP5000 HVOF AK06-N 5L AK06-N 5E AK06-N 5O

Young's Modulus E of WC-10Co-4Cr coatings Young's Modulus E, GPa E Standard Deviation, GPa

www.kermetico.com averstak@kermetico.com 22

slide-23
SLIDE 23

Cavitation Resistance

  • f WC-10Co-4Cr HVOF and HVAF coatings

( dw/dt ) AF1 (5O) = 0.23 mg/h ( dw/dt ) AF3 (5E) = 0.71 mg/h ( dw/dt ) AF2 (5L) = 0.96 mg/h ( dw/dt ) HVOF = > 3.26 mg/h

Nozzle 5O Nozzle 5L Nozzle 5E

( dw/dt ) 16Cr-5Ni steel = 2.0 - 2.5 mg/h

www.kermetico.com averstak@kermetico.com 23

slide-24
SLIDE 24

Surface SEM Micrographs of WC-10Co-4Cr Coatings after Cavitation Testing

Test duration: 1 hour JP5000 HVOF AK6 HVAF

www.kermetico.com averstak@kermetico.com 24

slide-25
SLIDE 25

Surface SEM Micrographs of WC-10Co-4Cr Coatings after Cavitation Testing

Test duration: 9 hours JP5000 HVOF AK6 HVAF

www.kermetico.com averstak@kermetico.com 25

slide-26
SLIDE 26

Resistance to Silt Erosion

WC-10Co-4Cr HVOF and HVAF coatings

1 hr 2 hr 3 hr JP5000 HVOF AK06-N 5L AK06-N 5E AK06-N 5O

16,3 3,8 3,7 2,4 30,4 6,5 5,4 4,9 47,0 8,6 7,4 7,3 Cumulative weight loss of coatings during silt erosion test, mg

1 hr 2 hr 3 hr www.kermetico.com averstak@kermetico.com 26

slide-27
SLIDE 27

Other Third-party Data, Comparing Kermetico HVAF WC-10Co-4Cr Coatings to the Best HVOF and Detonation Systems

www.kermetico.com averstak@kermetico.com 27

slide-28
SLIDE 28

www.kermetico.com averstak@kermetico.com 28

slide-29
SLIDE 29

Hunan University Changsha, Hunan, China:

WC-10Co-4Cr HVOF & HVAF coatings. Cavitation test

60 120 180 240 300 360 420 480 540 600 660 720 2 4 6 8 10 12 Volume loss (mm

3)

Time (minutes) AISI316:y=0.0156x-0.4789 DJ Coating:y=0.0121x+0.4744 AK Coating:y=0.0047x+0.0922

www.kermetico.com averstak@kermetico.com 29

slide-30
SLIDE 30

www.kermetico.com averstak@kermetico.com 30

0,0 0,5 1,0 1,5 2,0 2,5 3,0 GTV K2 HVOF GTV K2 UHVOF Kermetico AK6 HVAF

InnoMat GmbH Report on WCCoCr coatings for Stellba AG (2016)

ASTM G75-07: Slurry Erosion Test, mg/hour ASTM G65-04 (B): Rubber Wheel Test, mg/min Ball-On-Disc Test, micron/10,000 cycles Gesellschaft für innovative Materialtechnik InnoMat GmbH Annaberger Str. 240, 09125 Chemnitz Stellba AG Wohlerstrasse 51 CH - 5605 Dottikon

slide-31
SLIDE 31

www.kermetico.com averstak@kermetico.com 31

Slat Spray: All WCCoCr Samples Passed 312-Hour Test

Before testing After 312-hours testing

K2 HVOF K2 UHVOF AK6 HVAF

Note: HVAF samples were tested after Pin-On-Disc Wear Test

slide-32
SLIDE 32

www.kermetico.com averstak@kermetico.com 32

Economic Aspects of Kermetico HVAF Spraying: Your Choice of Cost and Quality

HVAF-E (Economy) – meets HVOF specs HVAF-B (Balanced) – exceeds HVOF specs HVAF-U (Ultra) – substantially exceeds HVOF specs

slide-33
SLIDE 33

Economic Aspects of Kermetico HVAF

Gun Setup Coating Hardness , HV300 Coating Porosity, % Deposition Efficiency, % Economy (E) 1050-1250 <0.8 65+ Balanced (B) 1250-1350 <0.5 48 - 58 Ultra (U) 1450-1700 <0.1 36 - 42

www.kermetico.com averstak@kermetico.com 33

O.D. 38 mm: Rate 25 kg/hour O.D. 330 mm: Rate 32 kg/hour High spray rates are applicable for large and small parts

Data for WC-10Co-4Cr, agglomerated & sintered powder

slide-34
SLIDE 34

HVOF vs HVAF WC-10Co-4Cr Costs

www.kermetico.com averstak@kermetico.com 34

Comparison of HVAF and HVOF operating costs, USD per hour (prices in Texas, USA) 50 100 150 200 250 300 DJ2600 HVOF (Hydrogen) JP5000 HVOF (Kerosene) HVAF -E HVAF-B HVAF-U

Oxidant Fuel Spare parts Power, etc. Labor+Overhead Amortizing

slide-35
SLIDE 35

Comparison of HVAF and HVOF Cost

(prices in Texas, USA)

www.kermetico.com averstak@kermetico.com 35

50 100 150 200 250 300 350 DJ2600 HVOF JP5000 HVOF HVAF -E HVAF-B HVAF-U

Operating cost per kg deposited Powder cost per kg deposited

1000 1100 1200 1300 1400 1500 1600 DJ2600 HVOF JP5000 HVOF HVAF -E HVAF-B HVAF-U

WCCoCr Coating Hardness, HV300 DJ2600 HVOF JP5000 HVOF HVAF-E HVAF-B HVAF-U

Spray Rate, kg/hour 4 5 32 26 26 Deposition Efficiency 50% 43% 65% 46% 38%

Cost per WCCoCr kg deposited, USD

Note: Cost of WC-Co-Cr powder: $81.4 per kg

slide-36
SLIDE 36

WC-Co-Cr powder cost: 81.4 USD/kg DJ2600 HVOF JP5000 HVOF AK7 HVAF (E) Total operating cost, USD/hour $260 $223 $160 Spray rate, kg/hour 4 5 32 Deposition efficiency, % 50 43 65 Deposition rate, kg/hour 2.2 2.2 20.8 Cost per KG of sprayed coating, USD $293 $293 $133 AK7 savings per KG of deposited coating, USD $160 $160

www.kermetico.com averstak@kermetico.com 36

HVOF vs HVAF WC-10Co-4Cr Costs

Changing a HVOF system to Kermetico HVAF saves $160,000 USD per each metric ton of deposited tungsten carbide coating

slide-37
SLIDE 37

Examples of Kermetico HVAF Applications

www.kermetico.com averstak@kermetico.com 37

slide-38
SLIDE 38

Mud Rotors, Oil Drilling: WC-20Cr7Ni, WC-10Co-4Cr

www.kermetico.com averstak@kermetico.com 38

slide-39
SLIDE 39

Hydro-Power: Francis Turbine Runner and Head Cover

WCCoCr Application by Plackart Ltd., Russia

www.kermetico.com averstak@kermetico.com 39

slide-40
SLIDE 40

Hydro-Power: a Metering Needle Valve and a Seat

Application by RenCoat Ltd., China

www.kermetico.com averstak@kermetico.com 40

slide-41
SLIDE 41

A Sliding Gate of a Catalyst Tower

Spraying: Upper slide gate

www.kermetico.com averstak@kermetico.com 41

slide-42
SLIDE 42

Hydraulic Rods of Dock Cranes

Hard chrome performance: 0.5 year max (pitting) HVAF WC-Co-Cr coating performance: 4+ years

www.kermetico.com averstak@kermetico.com 42

slide-43
SLIDE 43

A Refinery Sulfur Condenser Vessel

Application of Hastelloy C HVAF coating DIA 1.8 m x L 2.4 m

www.kermetico.com averstak@kermetico.com 43

slide-44
SLIDE 44

Refinery: Automated Coating Application with the Rotating AK5 Gun Inside a Processing Vessel

www.kermetico.com averstak@kermetico.com 44

Diameter: 1.8 m Length: 11.8 m

slide-45
SLIDE 45

Refinery: Heat exchanger vessels

www.kermetico.com averstak@kermetico.com 45

slide-46
SLIDE 46

Double-Elbow, Coke Transport Line

12-inch ID, 6-feet long

www.kermetico.com averstak@kermetico.com 46

slide-47
SLIDE 47

Double-Elbow, Spraying with rotating AK5 gun

www.kermetico.com averstak@kermetico.com 47

slide-48
SLIDE 48

Coke Line Cyclone: Application of WC-10Co-4Cr Coating with the Rotating AK5 Gun

www.kermetico.com averstak@kermetico.com 48

slide-49
SLIDE 49

Coke Line Cyclone: Application of WC-10Co-4Cr Coating with the Rotating AK5 Gun

www.kermetico.com averstak@kermetico.com 49

slide-50
SLIDE 50

Small ID Transport Pipe Line Components: Application of WC-10Co-4Cr Coating with the Rotating AK-IDR Gun

www.kermetico.com averstak@kermetico.com 50

slide-51
SLIDE 51

Oil Refinery: Pump Casing ID Spraying

www.kermetico.com averstak@kermetico.com 51

slide-52
SLIDE 52

Oil Drilling: Fluid-End Pump Casing, 5-inch (125 mm) ID

Application of coating with AK-IDR rotating gun

www.kermetico.com averstak@kermetico.com 52

slide-53
SLIDE 53

Wear Rings on HT Pump Housings and Impeller Hubs

AK7 Stellite 6 coating

  • ver Stellite weld overlay

Housing ring: Stellite 6 Impeller ring: WCCoCr HT (400oC) Pump coating solutions: Housing ring: Stellite 6 Impeller ring: Stellite 1

www.kermetico.com averstak@kermetico.com 53

slide-54
SLIDE 54

Geothermal Power: Turbine Rotor WCCoCr 86/10/4

www.kermetico.com averstak@kermetico.com 54

slide-55
SLIDE 55

Titanium: HVAF

Titanium: Shrouded HVAF

www.kermetico.com

averstak@kermetico.com 55

slide-56
SLIDE 56

Tin Spraying with HVAF SL Gun for Low-melting Point Metals

www.kermetico.com averstak@kermetico.com 56

slide-57
SLIDE 57

WC-Co-Cr 1 mm thick

Kermetico HVAF

www.kermetico.com averstak@kermetico.com 57

slide-58
SLIDE 58

Tensiometer Roll: AK7 HVAF, WC-10Co-4Cr, 1.8 mm thick

www.kermetico.com averstak@kermetico.com 58

slide-59
SLIDE 59

AK-HH: hand-held HVAF

Kermetico HVAF Blast & Spray Systems

www.kermetico.com averstak@kermetico.com 59

slide-60
SLIDE 60

Press Pistons, Winemaking

www.kermetico.com averstak@kermetico.com 60
