Keep Alaska Moving through service and infrastructure Water and Roads Do not MIX!!!!!!! Design, Construction, and Maintenance Keep Alaska Moving through service and infrastructure Lets Start at the Very Beginning NEPA Purpose and need

slide-1
SLIDE 1

Keep Alaska Moving through service and infrastructure

slide-2
SLIDE 2

Keep Alaska Moving through service and infrastructure

  • Do not MIX!!!!!!!
  • Design, Construction, and Maintenance

Water and Roads

slide-3
SLIDE 3

Keep Alaska Moving through service and infrastructure

Lets Start at the Very Beginning

NEPA

  • Purpose and need
  • Alternatives
  • Avoidance, Minimize, and Mitigate impacts
  • Considerations
  • Coordination w/

Agencies

EFH MSFMCA CWA NHPA ESA MBTA CAA FWCA CZMA

slide-4
SLIDE 4

Keep Alaska Moving through service and infrastructure

Environmental Permits

  • Permits (pertaining to water)
  • ADF&G
  • COE
  • Flood Hazard
  • ADEC - APDES Construction General Permit &

401 Cert

  • Essential Fish Habitat Permit (part of NEPA, not

permit)

slide-5
SLIDE 5

Keep Alaska Moving through service and infrastructure

Other Criteria

  • DOT&PF Criteria
  • FHWA Criteria
  • Bioengineering cannot be sole means to

protect critical infrastructure

slide-6
SLIDE 6

Keep Alaska Moving through service and infrastructure

  • Different water challenges
  • Surface – Rain and Snow
  • Subsurface
  • Waterbody crossing/paralleling

Water and Roads

slide-7
SLIDE 7

Keep Alaska Moving through service and infrastructure

Surface Runoff on the Road

  • Road General Features
  • Road cross-slope
  • Foreslopes
  • Ditches
slide-8
SLIDE 8

Keep Alaska Moving through service and infrastructure

Surface Runoff on the Road

  • Special Considerations - Bridges
  • Scuppers
slide-9
SLIDE 9

Keep Alaska Moving through service and infrastructure

Surface Runoff on the Road

  • Special Considerations - Maintenance
  • Plowing
  • Sand
  • MS4
slide-10
SLIDE 10

Keep Alaska Moving through service and infrastructure

Subsurface

  • Groundwater
  • Storm Drain systems
  • Oil Grit Separators
  • LID
  • Sumps
slide-11
SLIDE 11

Keep Alaska Moving through service and infrastructure

Waterbody Crossings

slide-12
SLIDE 12

Keep Alaska Moving through service and infrastructure

Tier 1 Fish Passage Design

Tier 1 (Stream Simulation)

  • Slope < 0.5%: culvert span > 0.75*OHW
  • 0.5% ≤ Slope < 6%: culvert span > 0.9*OHW
  • Round: invert burial ≥ 40% of diameter
  • Pipe arch: invert burial ≥ 20% of rise.
  • Culvert slope ± 1% of natural stream slope.
  • Add Substrate in culvert to simulate streambed

and be stable during larger discharges

  • Provide baffles to help retain sediment.
slide-13
SLIDE 13

Coal Creek at K Beach Road 18’ diameter buried 7.2’, After

slide-14
SLIDE 14

Keep Alaska Moving through service and infrastructure

Tier 2 Fish Passage Criteria

  • Requires FishXing software created by USFS
  • Fish sustained and burst swimming vs. water

velocity

  • Add resting areas as needed
  • Compares water depth to minimum depth for fish
slide-15
SLIDE 15

Keep Alaska Moving through service and infrastructure

Tier 2 fish passage w ith baffles Alyeska Highw ay, Girdwood

slide-16
SLIDE 16

Keep Alaska Moving through service and infrastructure

Tier 3 Fish Passage Criteria

  • Use hydraulic calculations to ensure

successful fish passage

  • Both ADF&G and DOT&PF agree
slide-17
SLIDE 17

Keep Alaska Moving through service and infrastructure

Other information

  • Collaborate with ADF&G to provide the best

culvert designs that meet the criteria and constraints of both agencies

  • Erosion protection, as needed
slide-18
SLIDE 18

Wasilla Creek at Bogard, 17’-0” x 6’-9”

slide-19
SLIDE 19

Coal Creek at K Beach Road 2008, 10’ Diameter, Before, Outlet

slide-20
SLIDE 20

Coal Creek at K Beach Road 2008, Before, Outlet

slide-21
SLIDE 21

Coal Creek at K Beach Road, 2010, looking upstream

slide-22
SLIDE 22

Coal Creek at K Beach Road 2015, Tailw ater looking dow nstream

slide-23
SLIDE 23

Coal Creek at K Beach Road 2015 looking upstream

slide-24
SLIDE 24

Fish Creek at Knik Goose Bay Road Before, 2 – 12’ diameter

slide-25
SLIDE 25

Fish Creek at Knik Goose Bay Road After, 32’ x 12’

slide-26
SLIDE 26

Wasilla Creek at Palmer-Fishhook 17’-2”x11’-4”, buried 2.3’, 2016, Outlet

slide-27
SLIDE 27

Wasilla Creek at Palmer-Fishhook 2016 looking upstream

slide-28
SLIDE 28

Keep Alaska Moving through service and infrastructure

Fish Culverts in the design phase

  • North Fork Anchor River at Nikolaevsk Road
  • Crooked Creek at Sterling Highway
  • Two Moose Creek at Sterling Highway
  • Leader Creek near Naknek
  • Others on smaller streams
slide-29
SLIDE 29

Keep Alaska Moving through service and infrastructure

Parallel Flow Embankment Saturation

slide-30
SLIDE 30

Keep Alaska Moving through service and infrastructure

Parallel Flow, Erosion

slide-31
SLIDE 31

Keep Alaska Moving through service and infrastructure

Parallel Flow, Road Overtopping

slide-32
SLIDE 32

Keep Alaska Moving through service and infrastructure

Parallel Flow, Embankment Stabilization

slide-33
SLIDE 33

Keep Alaska Moving through service and infrastructure

Parallel Flow, Embankment Stabilization
