Jamie Cremeans Mechanical Engineering Christian Guynes Mechanical Engineering Stephen Kelley Mechanical Engineering

slide-1
SLIDE 1
slide-2
SLIDE 2

Jamie Cremeans

  • Mechanical Engineering

Christian Guynes

  • Mechanical Engineering

Stephen Kelley

  • Mechanical Engineering
slide-3
SLIDE 3

Nicolas Meacham

  • Mechanical Engineering

Ben Severe

  • Mechanical Engineering
slide-4
SLIDE 4

Sponsor

3Core, Inc.

Faculty Advisor

Gregory Kallio, Ph.D

slide-5
SLIDE 5
  • Farmers need on-site cold storage

Function:

Reduce waste and excess costs Provide more efficient cooling solution Ability to increase volume based on need Functional Portability

slide-6
SLIDE 6
  • Requirement:

Qual./Quant. Must Do: Reach/maintain required temperature, at 108 oF ambient temp, wind, clear sky quantitative Maintain humidity within 20% of target quantitative Temporal/Spatial temperature distribution quantitative Alert System qualitative Run off 120v/240v AC power source. qualitative Full-scale cost under $20,000 quantitative Should Do: Modular qualitative Full-scale cost under $15,000 quantitative Would Be Nice: Solar Powered qualitative Have mobility of some form qualitative Full-scale cost under $10,000 quantitative

slide-7
SLIDE 7

Requirement Engineering Specification Metric Method / Device Target Condition Temperature Range Degrees Celsius Temperature Data Logger 1.1 – 12.8 oC (34-55) oF Average value within unit Temperature Control Temporal/ Spatial Degrees Celsius Temperature Data Logger +/-1.4 oC (+/-2.5) oF 48 oC (108) oF

Clear Sun /wind

Humidity Range Mass water / Unit Volume of Air & Water Percent Humidity Hygrometer 85-97 % Average value within unit Energy Savings Power kWh Watt Hour Meter 15% Above Industry Standard Steady State Similar Ambient Conditions Fork lift Accessible Dimensions/ Strength Test Accessible Level Mobile Mass Kg Scale <4536 Kg Unloaded

slide-8
SLIDE 8
  • SIP Walls and Roof

Reinforced Floor

Structure

Split V-C Refrigeration

7,300 BTU/hr

Lengthwise Modularity Transportable Solar PV (optional)

slide-9
SLIDE 9
slide-10
SLIDE 10

!

Size

Height: 5 ft Width: 5 ft Length: 6 ft

Total heat rate

Qin≅812 BTU/hr

Cooling

Window A/C modified with the CoolBot

Validate full-size calculations

Sensors: temperature, watt-meter, etc.

slide-11
SLIDE 11

!

Exterior – Gel Coated Fiberglass Panels Vapor Barrier – 6 mil plastic Structurally insulated panels (SIPs) FRP – Fiber reinforced Plastic

slide-12
SLIDE 12

!

slide-13
SLIDE 13

"

slide-14
SLIDE 14

! #

slide-15
SLIDE 15
slide-16
SLIDE 16

"

slide-17
SLIDE 17

$

slide-18
SLIDE 18
slide-19
SLIDE 19

%&

slide-20
SLIDE 20

'

slide-21
SLIDE 21

("

slide-22
SLIDE 22

()*

slide-23
SLIDE 23

+!

slide-24
SLIDE 24

+

slide-25
SLIDE 25
slide-26
SLIDE 26

+'

slide-27
SLIDE 27

++

slide-28
SLIDE 28

,$+

slide-29
SLIDE 29

+

Delta = Pretest – Posttest

slide-30
SLIDE 30

&

$3,500.00 $380.00 $7,500.00 $2,300.00

Total Project Cost: $13,680.00

Material Cost Trailer Labor Donated Material

slide-31
SLIDE 31

$

Structure and insulation were completely

effective

Difficulties encountered in sealing doors Next iteration should focus on more

efficient refrigeration unit

Produce prototype size without forklift

accessible floor

Gather information from more farmers

slide-32
SLIDE 32

(,

Donations

SIP material from Todd Harris of SIPerior

Homes

Fiberglass Exterior from Bill Hill of Precision

Craft Boat Works

Decal design and purchase from North Valley

Food Hub

Generator from CSU Chico College of

Agriculture

Welding from Gordon of Butte College

Welding Program

Guy Rents forklift for testing
