850V Ultra Junction X-Class HiPerFET™ Power MOSFETs with Fast Body Diodes

IXYS Corporation www.ixys.com

September 2016

2

• Developed using a charge compensation principle and proprietary process technology
• Lowest on-resistance RDS(on) in industry: (33mΩ in SOT-227, 41mΩ in PLUS264 & SOT-227)
• Low gate charge Qg
• Optimized fast, soft-recovery body diodes
• Superior dv/dt ruggedness
• Higher efficiency
• High power densities
• Easy to mount
• Low package inductance
• Available in international standard packages: TO-220, TO-263HV, SOT-227, TO-247, TO-264,

PLUS264™, TO-268HV)

Product Line Introduction

Industry’s lowest on-resistance Silicon devices

Key Technology Advantages

3

Ultra Junction Technology (combination of charge compensation principle and IXYS process technology)

• Better Figure of Merit (RDS(on) x Qg)
• Significantly reduced on-resistance and gate charge
• Very high power density
• Low conduction and switching losses
• Low gate drive requirements
• Enhanced Ruggedness
• Superior dv/dt performance (50V/ns)
• Avalanche capability
• Robust against device failure induced by voltage transients and accidental turn-on of parasitic

bipolar transistors

• Optimized Fast, Soft-Recovery Body Diode
• Minimizes electromagnetic interference (EMI)
• Able to achieve high efficiency and avoid device failure by removing all the energies

during high-speed switching

4

Available Parts

850V Ultra Junction X-Class HiPerFET™ MOSFETs with Fast Body Diodes!

Applications

5

Enabling very high power density!

• Industrial switched-mode and resonant-mode power supplies
• Electric vehicle battery chargers
• AC and DC motor drives
• DC-DC converters
• Renewable energy inverters
• Power Factor Correction (PFC) circuits
• Robotics and servo control

Single transistor forward converter Flyback converter Solar inverter

Competitive Landscape

6

The IXYS part IXFP20N85X achieves:

• Lower (better) Figure of Merit (RDS(on) x Qg)
• Far superior reverse-diode dv/dt ruggedness at 50V/ns
• Greater avalanche capability (EAS)

IXYS’ 850V Ultra Junction MOSFETs can be better replacements for the conventional 800V and 900V MOSFETs available on the market nowadays.
