Investigating techniques from the 2000s for class model extraction Marianne Huchard, Ines Ammar, Ahmad Bedja-Boana, Jessie Carbonnel, Theo Chartier, Franz Fallavier, Julie Ly, Daniel Alias Nguyen Vu-Hao, Florian Pinier, Ralf Saenen and


slide-1
SLIDE 1

Investigating techniques from the 2000’s for class model extraction

Marianne Huchard, Ines Ammar, Ahmad Bedja-Boana, Jessie Carbonnel, Theo Chartier, Franz Fallavier, Julie Ly, Daniel Alias Nguyen Vu-Hao, Florian Pinier, Ralf Saenen and Sébastien Villon

Université Montpellier 2 - LIRMM July 9, 2014

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 1 / 22

slide-2
SLIDE 2

Context

1

Context

2

Walking in the literature

3

The proposed process

4

Current results

5

Conclusion and Perspectives

6

References

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 2 / 22

slide-3
SLIDE 3

Context

Industrial context

Request of a major (anonymous) IT service company Design Low-cost migration of a legacy software suite composed of: man-machine interfaces (HTML, VBScript/ASP, Javascript) several databases, SQL procedures (SQL Server 2000) procedural source code (VB6) Low-cost (money is invested in new developments) less effort than fully manual migration automatize as far as possible

  • pen-source, free, tools

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 3 / 22

slide-4
SLIDE 4

Context

Teaching context

Research and development project in Master course each student: 1 man/month distributed during 5 months (other classes and projects in parallel). read research papers (at least one per student) project managements activities: Gantt diagram, role/task distribution, meeting management reproduce solutions of papers 10 students 3 groups

  • ne common meeting every week (half of the meetings with IT service

company partner), and other meetings inside the groups

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 4 / 22

slide-5
SLIDE 5

Context

Project organization

Main tasks Reducing migration to class model extraction and to 2 software systems from the suite Designing a migration chain Choosing relevant research papers about class model extraction Implement the found extraction heuristics Apply to the software systems Group organization ACL Group (3): project management + 1 extraction heuristic CPS Group (3): analyze MMI code + 1 extraction heuristic Moretz Group (4): analyze SQL and VB code + 1 extraction heuristic

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 5 / 22

slide-6
SLIDE 6

Walking in the literature

1

Context

2

Walking in the literature

3

The proposed process

4

Current results

5

Conclusion and Perspectives

6

References

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 6 / 22

slide-7
SLIDE 7

Walking in the literature

The proposed papers

[Sahraoui et al., 1999] [Canfora et al., 1999]: minimization of coupling [Cimitile et al., 1999]: manual part, metrics+routine assig. algo. [van Deursen and Kuipers, 1999] [Lucca et al., 1997]: metrics+routine assig. algo. [Bhatti et al., 2008]: FCA on bad object design [Glavas and Fertalj, 2011] [Maletic and Marcus, 2001]: LSI + semantic clustering [Zou and Kontogiannis, 2003]: ad hoc alg. for amalgamating class properties

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 7 / 22

slide-8
SLIDE 8

The proposed process

1

Context

2

Walking in the literature

3

The proposed process

4

Current results

5

Conclusion and Perspectives

6

References

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 8 / 22

slide-9
SLIDE 9

The proposed process

The generic process

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 9 / 22

slide-10
SLIDE 10

The proposed process

Data extraction and encoding

Expected input data: tables, columns, functions, access, invocation Tools: FAMIX / MSE format, Verveine (http://www.moosetechnology.org/docs/famix) VBdepend (http://www.vbdepend.com) GSP (http://www.sqlparser.com ) Missing: VBdepend and GSP not free (trial versions were used) database representation in FAMIX analyzing VB functions where parameters are the SQL function and its parameters merge VB analysis result and SQL analysis result

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 10 / 22

slide-11
SLIDE 11

The proposed process

The instantiated process

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 11 / 22

slide-12
SLIDE 12

The proposed process

[Sahraoui et al., 1999] FCA++

FCA: data is accessed by routine select concepts by decreasing routine number and increasing data number classes are given by data part of the concepts merge concepts that have more in common than not in common assign functions to classes when they refer or modify them In current project: data are columns of the database tables routines are functions that directly have access to columns Tools: Concept Explorer (http://conexp.sourceforge.net) specific code for creating Formal Context and exploit the concept lattice

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 12 / 22

slide-13
SLIDE 13

The proposed process

[van Deursen and Kuipers, 1999] Dendogram

Hierarchical clustering on data similarly accessed by functions Create a CRUD matrix: data × functions calculate a distance matrix between data based on CRUD matrix build a dendogram based on distance and a chosen cut point assign functions to classes when they refer or modify only one class Tools: Entirely implemented

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 13 / 22

slide-14
SLIDE 14

The proposed process

[Glavas and Fertalj, 2011]

Meta-heuristics focus in the project: Simulated annealing solution: a set of candidate classes composed of data and functions fitness functions: software metrics (coupling, cohesion) Tools: AIMA framework (implements Peter Norvig And Stuart Russell’s "Artificial Intelligence - A Modern Approach 3rd Edition.") (http://code.google.com/p/aima-java/) specific Java code to connect to MSE files

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 14 / 22

slide-15
SLIDE 15

Current results

1

Context

2

Walking in the literature

3

The proposed process

4

Current results

5

Conclusion and Perspectives

6

References

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 15 / 22

slide-16
SLIDE 16

Current results

Application size

Software size (the smallest) two databases: 45 tables SQL+ VB code:

smallest software: 346 functions, 26042 LOC

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 16 / 22

slide-17
SLIDE 17

Current results

Results on TR software (smallest - 45 tables)

FCA++ attributes methods #class #min #max #av #min #max #av 74 2 165 10 30 8 Dendogram-11 attributes methods #class #min #max #av #max #min #av 20 1 36 12.8 12 2.5

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 17 / 22

slide-18
SLIDE 18

Current results

Analysis

FCA++ − many classes − post-treatment creates many duplications − attributes poorly distributed − merging method is too strict + all methods are assigned Dendogram + reasonable class number (correspond to connected tables) − few assigned methods Simulated annealing − difficulty to understand weighting in metrics − impossible to reproduce results of the paper on the included example

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 18 / 22

slide-19
SLIDE 19

Conclusion and Perspectives

1

Context

2

Walking in the literature

3

The proposed process

4

Current results

5

Conclusion and Perspectives

6

References

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 19 / 22

slide-20
SLIDE 20

Conclusion and Perspectives

Conclusion

not so easy to reproduce paper results no good results of FCA++ approach due to post-treatment limited results of dendogram approach for method assigment → Dendogram results have been chosen by the company for detailed study

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 20 / 22

slide-21
SLIDE 21

Conclusion and Perspectives

Perspectives

Change FCA++ post-treatment Add better method assigment to Dendogram Finalize Simulated Annealing Apply identifier analysis to tables/variables/columns names Use database schema Use MMI and interactions what about associations?

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 21 / 22

slide-22
SLIDE 22

Conclusion and Perspectives

Thank you!

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 22 / 22

slide-23
SLIDE 23

References

Bhatti, M. U., Ducasse, S., and Huchard, M. (2008). Reconsidering classes in procedural object-oriented code. In International Conference on Reverse Engineering (WCRE). Canfora, G., Cimitile, A., Lucia, A. D., and Lucca, G. A. D. (1999). A case study of applying an eclectic approach to identify objects in code. In IWPC, pages 136–143. IEEE Computer Society. Cimitile, A., Lucia, A. D., Lucca, G. A. D., and Fasolino, A. R. (1999). Identifying objects in legacy systems using design metrics. Journal of Systems and Software, 44(3):199–211. Glavas, G. and Fertalj, K. (2011). Solving the class responsibility assignment problem using metaheuristic approach. CIT, 19(4):275–283. Lucca, G. A. D., Fasolino, A. R., Guerra, P., and Petruzzelli, S. (1997). Migrating legacy systems towards object-oriented platforms. In ICSM, pages 122–129. IEEE Computer Society. Maletic, J. I. and Marcus, A. (2001). Supporting program comprehension using semantic and structural information.

Université Montpellier 2 - LIRMM SATToSE 2014 July 9, 2014 22 / 22

slide-24
SLIDE 24

References

In Müller, H. A., Harrold, M. J., and Schäfer, W., editors, ICSE, pages 103–112. IEEE Computer Society. Sahraoui, H. A., Lounis, H., Melo, W. L., and Mili, H. (1999). A concept formation based approach to object identification in procedural code.

  • Autom. Softw. Eng., 6(4):387–410.

van Deursen, A. and Kuipers, T. (1999). Identifying objects using cluster and concept analysis. In Boehm, B. W., Garlan, D., and Kramer, J., editors, ICSE, pages 246–255. ACM. Zou, Y. and Kontogiannis, K. (2003). Incremental transformation of procedural systems to object oriented platforms. In COMPSAC, pages 290–295. IEEE Computer Society.
