Programming Abstraction in C++

Eric S. Roberts and Julie Zelenski

Stanford University 2010

slide-2
SLIDE 2

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Chapter 4. Using Abstract Data Types

slide-3
SLIDE 3

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-4
SLIDE 4

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Introduction

Abstract data type (ADT): A type defined in terms of its

  • behavior. (Rather than its representation, e.g., char is

represented by codes.)

slide-5
SLIDE 5

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Introduction

Abstract data type (ADT): A type defined in terms of its

  • behavior. (Rather than its representation, e.g., char is

represented by codes.) Separating behavior from implementation

  • Simplicity. Hiding internal representation from the client.
  • Flexibility. Implementation can be changed as long as the

interface (behavior) remains the same.

  • Security. Protect the implementation from the client.
slide-6
SLIDE 6

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Introduction

Abstract data type (ADT): A type defined in terms of its

  • behavior. (Rather than its representation, e.g., char is

represented by codes.) Separating behavior from implementation

  • Simplicity. Hiding internal representation from the client.
  • Flexibility. Implementation can be changed as long as the

interface (behavior) remains the same.

  • Security. Protect the implementation from the client.

Seven classes: Vector, Grid, Stack, Queue, Map, Lexicon, Scanner.

slide-7
SLIDE 7

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-8
SLIDE 8

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Vector class

A container class or collection class. Interface #include "vector.h" A naming convention. For example: grid.h, stack.h. Generalization of one-dimensional array type Variable size Effective size available Simple insert and delete Bound checking

slide-9
SLIDE 9

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Vector class (cont.)

Constructor Vector<int> vec; Specify the base type of a vector.

slide-10
SLIDE 10

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Vector class (cont.)

Constructor Vector<int> vec; Specify the base type of a vector.

  • Methods. Table 4-1, p. 127.

Example. vec.add(10), vec.removeAt(0).

slide-11
SLIDE 11

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Vector class (cont.)

Constructor Vector<int> vec; Specify the base type of a vector.

  • Methods. Table 4-1, p. 127.

Example. vec.add(10), vec.removeAt(0).

  • Question. How would you remove the last entry?
slide-12
SLIDE 12

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Idiom

Idiom: Going through a vector, p. 129

void PrintVector(Vector<int> & vec) { cout << "["; for (int i = 0; i < vec.size(); i++) { if (i > 0) cout << ", "; cout << vec[i]; } cout << "]" << endl; }

  • Note. Passing by reference.
slide-13
SLIDE 13

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Idiom

Idiom: Going through a vector, p. 129

void PrintVector(Vector<int> & vec) { cout << "["; for (int i = 0; i < vec.size(); i++) { if (i > 0) cout << ", "; cout << vec[i]; } cout << "]" << endl; }

  • Note. Passing by reference.

Question: Can you pass vec by value (without the ampersand)? If you can, what are the differences?

slide-14
SLIDE 14

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Passing by reference

void AddArrayToVector(Vector<int> & vec, int array[], int n) { for (int 1 = 0; i < n; i++) { vec.add(array[i]); } }

slide-15
SLIDE 15

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Passing by reference

void AddArrayToVector(Vector<int> & vec, int array[], int n) { for (int 1 = 0; i < n; i++) { vec.add(array[i]); } }

Question: Can you pass vec by value (without the ampersand)? If you can, what are the differences?

slide-16
SLIDE 16

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Passing by reference

void AddArrayToVector(Vector<int> & vec, int array[], int n) { for (int 1 = 0; i < n; i++) { vec.add(array[i]); } }

Question: Can you pass vec by value (without the ampersand)? If you can, what are the differences? Almost always pass classes by reference.

slide-17
SLIDE 17

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Idiom

Idiom: Open a text file, p. 131

void AskUserForInputFile(string promt, ifstream & infile) { while (true) { cout << prompt; string filename = GetLine(); infile.open(filename.c_str()); if (!infile.fail()) break; cout << "Unable to open " << filename << endl; infile.clear(); } }

  • Note. Don’t forget infile.close() after reading/writing.
slide-18
SLIDE 18

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Idiom

Idiom: Open a text file, p. 131

void AskUserForInputFile(string promt, ifstream & infile) { while (true) { cout << prompt; string filename = GetLine(); infile.open(filename.c_str()); if (!infile.fail()) break; cout << "Unable to open " << filename << endl; infile.clear(); } }

  • Note. Don’t forget infile.close() after reading/writing.

Study revfile.cpp, p. 130. A text file as lines, an object of Vector<string>.

slide-19
SLIDE 19

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-20
SLIDE 20

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Grid class

Generalization of two-dimensional array. Variable dimensions. Constructor Grid<double> matrix(3,2); Specify row and column dimensions, in addition to the base type.

  • Methods. Table 4-2, p. 132
slide-21
SLIDE 21

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Example

CheckForWin for the tic-tac-toe game, p. 133.

bool CheckForWin(Grid<char> & board, char mark) { for (int i = 0; i <3; i++) { if (CheckLine(board, mark, i, 0, 0, 1)) return true; if (CheckLine(board, mark, 0, i, 1, 0)) return true; } if (CheckLine(board, mark, 0, 0, 1, 1)) return true; return (CheckLine(board, mark, 2, 0, -1, 1)); }

check rows check columns check diagonal check antidiagonal

slide-22
SLIDE 22

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-23
SLIDE 23

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Stack class

Behavior: Last in, first out (LIFO). Only the top is accessible to the client. Fundamental operations: push, pop

slide-24
SLIDE 24

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Stack class

Behavior: Last in, first out (LIFO). Only the top is accessible to the client. Fundamental operations: push, pop

  • Applications. Nested function calls:

main() { call function F } function F() { call function G }

slide-25
SLIDE 25

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Stack class (cont.)

Function G is called last and returns first.

main local variables for F local variables for G

slide-26
SLIDE 26

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Stack class (cont.)

Constructor Stack<double> calculator; Specify a base type.

  • Methods. Table 4-3, p. 135.
slide-27
SLIDE 27

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Stack class (cont.)

Constructor Stack<double> calculator; Specify a base type.

  • Methods. Table 4-3, p. 135.
  • Example. Scientific calculator (HP C-13)

50.0 * 1.5 + 3.8 / 2.0 Reverse Polish notation (RPN): 50.0 ENTER 1.5 * 3.8 ENTER 2.0 / +

slide-28
SLIDE 28

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

RPN and stack

When the ENTER button is pressed, the previous value is pushed on a stack. When an operator button is pressed Pushing the previous value Popping two values Applying the operation to the two values Pushing the result on the stack

slide-29
SLIDE 29

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Example

50.0 ENTER 1.5 * 3.8 ENTER 2.0 / + Stack content, p. 136.

slide-30
SLIDE 30

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Example

50.0 ENTER 1.5 * 3.8 ENTER 2.0 / + Stack content, p. 136.

  • Question. What is the key sequence for

50.0 * (1.5 + 3.8) / 2.0 Think the stack content.

slide-31
SLIDE 31

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Example

50.0 ENTER 1.5 * 3.8 ENTER 2.0 / + Stack content, p. 136.

  • Question. What is the key sequence for

50.0 * (1.5 + 3.8) / 2.0 Think the stack content. An RPN calculator simulator, pp. 137–138.

slide-32
SLIDE 32

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-33
SLIDE 33

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Queue class

  • Behavior. First in, first out (FIFO). Only the head and tail are

accessible to the client. Fundamental operations: enqueue, dequeue Constructor Queue<int> queue;

  • Methods. Table 4-4, p. 139.
  • Application. Printer queue.
slide-34
SLIDE 34

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Example

Check-out line simulation. Models Discretize time to serialize events. Arrival process: Poisson distribution. Average probability of a customer arriving in a particular time interval. Parameter: ARRIVAL PROBABILITY Implementation: RandomChance(ARRIVAL PROBABILITY) Service time: Uniformly distributed within a range. Parameters: MIN SERVICE TIME, MAX SERVICE TIME Implementation: RandomInteger(MIN SERVICE TIME, MAX SERVICE TIME)

slide-35
SLIDE 35

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Check-out line simulation (cont.)

Simulating time. Parameter: SIMULATION TIME Implementation:

for (int t = 0; t < SIMULATION_TIME; t++) { if (RandomChance(ARRIVAL_PROBABILITY)) { queue.enqueue(t); } if (serviceTimeRemaining > 0) { serviceTimeRemaining--; if (serviceTimeRemaining == 0) nServed++; } else { totalWait = t - queue.dequeue(); serviceTimeRemaining = RandomInteger(MIN_..., MAX_...); } totalLength += queue.size(); }

slide-36
SLIDE 36

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-37
SLIDE 37

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Map class

  • Behavior. An association between a key (tag) and an

associated value (can be a complicated structure). A generalization of Vector. Fundamental operations: put, get

  • Application. Symbol table, an association between a variable

name and its value.

slide-38
SLIDE 38

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Map class

  • Behavior. An association between a key (tag) and an

associated value (can be a complicated structure). A generalization of Vector. Fundamental operations: put, get

  • Application. Symbol table, an association between a variable

name and its value. Constructor Map<double> symbolTable;

  • Note. The base type is the type of value, not tag.

For simplicity, the type of tag is always string.

slide-39
SLIDE 39

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Map class

  • Behavior. An association between a key (tag) and an

associated value (can be a complicated structure). A generalization of Vector. Fundamental operations: put, get

  • Application. Symbol table, an association between a variable

name and its value. Constructor Map<double> symbolTable;

  • Note. The base type is the type of value, not tag.

For simplicity, the type of tag is always string.

  • Methods. Table 4-5, p.147.
slide-40
SLIDE 40

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Map class

  • Behavior. An association between a key (tag) and an

associated value (can be a complicated structure). A generalization of Vector. Fundamental operations: put, get

  • Application. Symbol table, an association between a variable

name and its value. Constructor Map<double> symbolTable;

  • Note. The base type is the type of value, not tag.

For simplicity, the type of tag is always string.

  • Methods. Table 4-5, p.147.
  • Example. Airport codes. Figure 4-6, p. 150.
slide-41
SLIDE 41

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-42
SLIDE 42

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Lexicon class

  • Behavior. A list of alphabetically ordered words.

Fundamental operations: add, containsWord

slide-43
SLIDE 43

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Lexicon class

  • Behavior. A list of alphabetically ordered words.

Fundamental operations: add, containsWord Constructors Lexicon wordList; Lexicon english("EnglishWords.dat");

  • Note. No parameterized type (always string)

Formats of the data file text file, list of words, one word per line precompiled data file

slide-44
SLIDE 44

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Lexicon class (cont.)

  • Methods. Table 4-6, p. 152.
  • Example. twoletters.cpp, p. 153.

Check every possible two-letter combinations (262), if it is contained in EnglishWords.dat.

slide-45
SLIDE 45

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Lexicon class (cont.)

  • Methods. Table 4-6, p. 152.
  • Example. twoletters.cpp, p. 153.

Check every possible two-letter combinations (262), if it is contained in EnglishWords.dat. Why Lexicon now that we have Map?

slide-46
SLIDE 46

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Lexicon class (cont.)

  • Methods. Table 4-6, p. 152.
  • Example. twoletters.cpp, p. 153.

Check every possible two-letter combinations (262), if it is contained in EnglishWords.dat. Why Lexicon now that we have Map? Efficiency.

slide-47
SLIDE 47

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-48
SLIDE 48

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Scanner class

  • Behavior. Divide up a string into tokens

A sequence of consecutive alphanumeric characters, or A single-character string consisting of a space or punctuation mark. Fundamental operation: hasMoreTokens, nextToken Constructor Scanner scanner; No base type. (Always string.)

  • Methods. Table 4-7, p. 157.
slide-49
SLIDE 49

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Idiom

Idiom: Scan a file ifstream infile; Scanner scanner; AskUserForInputFile("Input file: ", infile); scanner.setInput(infile); while (scanner.hasMoreTokens()) { string word = scanner.nextToken(); ... do something with the token ... } infile.close();

slide-50
SLIDE 50

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Outline

1

Vector Class

2

Grid Class

3

Stack Class

4

Queue Class

5

Map Class

6

Lexicon Class

7

Scanner Class

8

Iterators

slide-51
SLIDE 51

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Iterators

Iterator: A subclass (of Vector, Grid, Map, Lexicon, Scanner).

  • Behavior. Stepping through the elements of a collection class.

Fundamental operations: hasNext, next

slide-52
SLIDE 52

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

Iterators (cont.)

Idiom: iterator, p. 158 Lexicon::Iterator iter = english.iterator(); while (iter.hasNext()) { string word = iter.next(); ... code to work with the word ... } Lexicon::Iterator A subclass of Lexicon iter An object of the class Lexicon::Iterator iter.next() Returns a value of type string (Lexicon) or base type (Vector or Grid or Map).

slide-53
SLIDE 53

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

foreach mechanism

Usage Idiom: foreach foreach (string word in english) { if (word.length() == 2) { cout << word << endl; } }

slide-54
SLIDE 54

Vector Class Grid Class Stack Class Queue Class Map Class Lexicon Class Scanner Class Iterators

foreach mechanism

Usage Idiom: foreach foreach (string word in english) { if (word.length() == 2) { cout << word << endl; } } It is simple and easy to use, but you should understand the

  • mechanism. The type of word (string) must match the base

type of the class (Lexicon) of which english is an object.
