Introduction to Performance Analysis

Visualization and Analysis of Performance on Large-scale Software Todd Gamblin LLNL

VAPLS 2013

Katherine Isaacs UC Davis, LLNL

Lawrence Livermore National Laboratory

1.

Bad algorithm

• Poor computational complexity, poor performance

2.

Takes poor advantage of the machine

• Code does not use hardware resources efficiently
• Different code may take better or worse advantage of different types
• f hardware
• Many factors can contribute

—

CPU, memory, threading, network, I/O

3.

It just has a lot of work to do

• Already using best algorithm
• Maps well to machine
• Distinguishing between these scenarios is difficult!

Why does my code run slowly?

Lawrence Livermore National Laboratory

• Profiling is one of the most

fundamental forms of performance analysis

• Measures how much time is spent

in particular functions in the code

• May include calling context
• May map time to particular files/line

numbers

• Helps programmers locate the

bottleneck

• Amdahl’s law: figure out what needs

to be sped up.

Profiling a single process

Source Code Elapsed Time Functions

Screenshot from HPCToolkit

Lawrence Livermore National Laboratory

• Modern chips offer special Hardware Performance Counters:
• Event counters, e.g.:

—

Number of FP, integer, memory, etc. instructions

—

Number of L1, L2 cache misses

—

Number of pipeline stalls

—

Only so many counters can be measured at once.

• Instruction Sampling

—

Precise latency and memory access information

—

Operands and other metadata for particular instructions

—

Newer chips support this

• Counters provide useful diagnostic information
• Can explain why a particular region consumes lots of time.
• Generally need to attribute counters to source code or another domain first.

How do we measure hardware?

Lawrence Livermore National Laboratory

• Once you’ve identified the “hot

spot”, how do you know what the problem is?

• Have to dig deeper into hardware
• Understand how code interacts with

the architecture

• Processors themselves are

parallel:

• Multiple functional units
• Multiple instructions issued per clock

cycle

• SIMD (vector) instructions
• Hyperthreading
• Can code exploit these?

Understanding processor complexity

17-core Blue Gene/Q SOC

17 Processor Cores Shared L2 Cache

Lawrence Livermore National Laboratory

Processor 0

• Threads and processes
• n a single node

communicate through shared memory

• Memory is hierarchical
• Many levels of cache
• Different access speeds
• Different levels of sharing

in cache

Understanding memory

Core 0 Core 1 Core 2 Core 3 L2 Cache L1 Cache L1 Cache L1 Cache L1 Cache Main Memory

Lawrence Livermore National Laboratory

• Access to main memory

may not have uniform access time

• More cores means uniform

latency is hard to maintain

• Many modern processors

have Non-Uniform Memory Access latency (NUMA)

• Time to access remote

sockets is longer than local

• nes

Understanding memory

Processor 0

C0 C1 C2 C3 L2 L1 L1 L1 L1

Memory 0

Processor 1

C0 C1 C2 C3 L2 L1 L1 L1 L1

Memory 1 Memory 3 Memory 2

Processor 3

C0 C1 C2 C3 L2 L1 L1 L1 L1

Processor 3

C0 C1 C2 C3 L2 L1 L1 L1 L1

4-socket, 16-core NUMA node

Lawrence Livermore National Laboratory

• Tianhe-2 in China
• 3.1 million Intel Xeon Phi cores
• Fat tree network
• Titan at ORNL
• 560,000 AMD Opteron cores
• 18,688 Nvidia GPUs
• 3D Torus/mesh network
• IBM Blue Gene/Q at LLNL
• 1.5 million PowerPC A2 cores
• 98,000 network nodes x 16 cores
• 5D Torus/mesh network

Modern supercomputers are composed of many processors

Lawrence Livermore National Laboratory

• Each node in the network is a multi-

core processor

• Programs pass messages over the

network

• Many topologies:
• Fat Tree
• Cartesian (Torus/Mesh)
• Dragonfly

– Multiple routing options for each one!

• Most recent networks have extensive

performance counters

• Measure bandwidth on links
• Measure contention on node

Processors pass messages over a network

4-D Torus network topology Fat Tree Network Topology

Lawrence Livermore National Laboratory

• Tracing records all function calls and messages
• Can record along with counters
• Large volume of records
• Clocks may not be synchronized
• Identify causes and propagation of delays
• Log behavior of adaptive algorithms in practice

Tracing in a message-passing application

Screenshot from Vampir

Lawrence Livermore National Laboratory

• Map hardware events to source code, data

structures, etc.

• Understand why performance is bad
• Take action based on what the hardware data

correlates to

• Most programmers look at a small fraction of

hardware data

• Automated visualization and analysis could help

leverage the data

Understanding parallel performance requires mapping hardware measurements to intuitive domains

Lawrence Livermore National Laboratory

• HPCToolkit: hpctoolkit.org
• mpiP: mpip.sourceforge.net
• Open|Speedshop: openspeedshop.org
• Paraver: www.bsc.es/computer-sciences/performance-tools/paraver
• PnMPI: scalability.llnl.gov/pnmpi/
• Scalasca: www.scalasca.org
• ScalaTrace: moss.csc.ncsu.edu/~mueller/ScalaTrace/
• TAU: www.cs.uoregon.edu/research/tau/
• VampirTrace: www.tu-dresden.de/zih/vampirtrace

…and many more!

Tools for collecting performance measurements
