Introduction to hardware design of block ciphers Francesco Regazzoni Francesco Regazzoni 20 October 2015, Chia, Italy P. 1 Contents 1 Hardware Design 2 ASIC 3 Reconfigurable Devices Francesco Regazzoni 20 October 2015, Chia, Italy P. 2

slide-1
SLIDE 1

Introduction to hardware design of block ciphers Francesco Regazzoni

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 1
slide-2
SLIDE 2

Contents

1

Hardware Design

2

ASIC

3

Reconfigurable Devices Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 2
slide-3
SLIDE 3

Top-Down Approach From an high level specification (usually abstract) to detailed design by decomposition and successive refinement Answers to the question: “What do we build?” Handles the complexity

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 3
slide-4
SLIDE 4

Bottom-Up Approach From detailed primitive blocks to a larger and more complex functional block by combining primitives blocks Answers to the question: “How do we build it?” Focuses on the details Design usually proceed from both directions simultaneously

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 4
slide-5
SLIDE 5

Why Electronic Design Automation? Handle the complexity Design optimization Time to market

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 5
slide-6
SLIDE 6

Design Goals Speed Area Occupation Power Consumption Time to market Cost

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 6
slide-7
SLIDE 7

Speed Latency: time required to perform an action, measured in units of time (nanoseconds, clock periods, ...). Throughput: the number of such actions executed per unit of time, measured in units of what is being produced. Critical path: the path which creates longest delay Clock ≈

1 criticalpath

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 7
slide-8
SLIDE 8

Area Occupation Amount of silicon area occupied by the whole design

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 8
slide-9
SLIDE 9

Power Consumption Power = Current × Voltage, measured in Watt

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 9
slide-10
SLIDE 10

Power vs Energy Power = Current × Voltage, measured in Watt Energy = Power × Execution time, measured in Joule

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 10
slide-11
SLIDE 11

Time to Market and Cost Consumer electronic.... Non Recurring Engineering Costs

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 11
slide-12
SLIDE 12

Security?

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 12
slide-13
SLIDE 13

Contents

1

Hardware Design

2

ASIC

3

Reconfigurable Devices Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 13
slide-14
SLIDE 14

Simplified Hardware Design Flow (ASIC)

Algorithm Design C, Matlab, VHDL

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 14
slide-15
SLIDE 15

Simplified Hardware Design Flow (ASIC)

Algorithm Design C, Matlab, VHDL RTL (Architecture) Design Synthesizable HDL

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 14
slide-16
SLIDE 16

Simplified Hardware Design Flow (ASIC)

Algorithm Design C, Matlab, VHDL RTL (Architecture) Design Synthesizable HDL Gate

x y x XOR y

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 14
slide-17
SLIDE 17

Simplified Hardware Design Flow (ASIC)

Algorithm Design C, Matlab, VHDL RTL (Architecture) Design Synthesizable HDL Gate

x y x XOR y

Layout

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 14
slide-18
SLIDE 18

Standard Cell Library Library of Basic Gates (AND2x1, AND3x1, OR2X1...) Information about Logic function, power, area, timing Vertical and Horizontal Grid are defined All cells must have the same height

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 15
slide-19
SLIDE 19

Synthesis

RTL (Architecture) Design Synthesizable HDL Logic Synthesis Gate Level

x y x XOR y

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 16
slide-20
SLIDE 20

Definitions Logic Synthesis is the manipulation of logic specifications to create logic models as an interconnection of logic primitives Logic Synthesis determines the gate level structure of a circuit

From G. De Micheli, Synthesis and Optimization of Digital Circuits, McGraw-Hill Higher Education, 1994.

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 17
slide-21
SLIDE 21

Logic Synthesis Input and Output INPUT: HDL Description Technological Library (function, area, timing, power, environmental constraints) Synthetic Library (multipliers...) Constraints OUTPUT: Gate Level Netlist Estimation of area, timing, power (!) Timing constraints

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 18
slide-22
SLIDE 22

Typical Logic Synthesis Steps

  • ne

State Minimization two State Encoding three Combinatorial Logic Minimization four Technology Mapping

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 19
slide-23
SLIDE 23

Place and Route

Gate

x y x XOR y

Place and Route Layout

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 20
slide-24
SLIDE 24

Place and Route Input and Output INPUT: Gate level description of the circuit Physical view of the library (pin placement, ...) Constraints from synthesis OUTPUT: Gate Level Netlist Position and interconnection of the gates Estimation of area, timing, power (!)

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 21
slide-25
SLIDE 25

This is not yet the end! PADs Design Rule Checks Layout vs Schematic Check Tape out

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 22
slide-26
SLIDE 26

Contents

1

Hardware Design

2

ASIC

3

Reconfigurable Devices Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 23
slide-27
SLIDE 27

Reconfigurable Devices

Field Programmable Gate Arrays (FPGAs) Reconfigurable hardware devices Trade offs between ASIC and microprocessors Current progresses allow to store a complete SoC on FPGA

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 24
slide-28
SLIDE 28

Advantages of FPGA

Reduced non recurring engineering costs Reduced time to market Easier access to newer technologies

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 25
slide-29
SLIDE 29

High Level View

Configurable blocks (look-up-tables) Configurable routing matrix Input/Output blocks Memory configuration Advanced processing elements (DSP , whole processors)

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 26
slide-30
SLIDE 30

Simplified Hardware Design Flow (FPGAs)

HDL

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 27
slide-31
SLIDE 31

Simplified Hardware Design Flow (FPGAs)

HDL Synthesis

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 27
slide-32
SLIDE 32

Simplified Hardware Design Flow (FPGAs)

HDL Synthesis Place and route

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 27
slide-33
SLIDE 33

Simplified Hardware Design Flow (FPGAs)

HDL Synthesis Place and route Generate the bit stream

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 27
slide-34
SLIDE 34

Simplified Hardware Design Flow (FPGAs)

HDL Synthesis Place and route Generate the bit stream Burn the FPGA

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 27
slide-35
SLIDE 35

Hardware Design Final Remarks

Don’t compare apple with oranges!

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 28
slide-36
SLIDE 36

Questions? Thank you for your attention! mail: regazzoni@alari.ch

Francesco Regazzoni 20 October 2015, Chia, Italy

  • P. 29
