Introduction to Eagle LNG Partners MAXVILLE In-Service Q3 2017 TALLEYRAND Eagles facilities in Florida are MARINE TERMINAL strategically located near In-Service Q3 2017 abundant gas supply, interstate pipelines, transportation hubs
MAXVILLE In-Service Q3 2017 TALLEYRAND MARINE TERMINAL In-Service Q3 2017 JACKSONVILLE EXPORT FACILITY FERC Permitting
Eagle’s facilities in Florida are strategically located near abundant gas supply, interstate pipelines, transportation hubs and a community receptive to the use of LNG.
2
MAXVILLE LNG FACILITY
Initial Liquefaction: 87,000 GPD (330 m3/d) Max Liquefaction: 200,000 GPD (760 m3/d) Storage Size: 1,000,000 Gallons (3,800 m3) 3
4
5
TALLEYRAND LNG BUNKER DEPOT
In service: Q4 2017 Storage Size: 2 x 1,000m3 tanks (~528,000 gallons total) Load Out Rate: 1,800-2,400 GPM under normal loading conditions Crowley Bunkering: approximately 380,000 LNG gallons per event Crowley Bunkering Time: Maximum allowable time from Ship arrival is 8 hours 6
7
VESSEL LOADING DOCK STORAGE TANK ONE of THREE “TRAINS” TANKER & ISO LOADING
JACKSONVILLE PLANT & TERMINAL
Liquefaction: 550,000 GPD/train, 1,650,000 GPD (6,245 m3/d) at full build out Storage Size: 12,000,000 Gallons (45,420 m3) 8
Eagle LNG ISO Containers Hub & Spoke World Scale
Delivered LNG Price by Solution
Plant Size LNG Volume LNG Solution
(MW) (Annual CM) 50 130K ISO, Eagle, H&S 100 265K Eagle, H&S 200 530K Eagle, H&S 300 790K Eagle, H&S 400 1,050K Eagle, World Scale 500 1,300K Eagle, World Scale >600 +1,600 World Scale
Source: Eagle Internal Estimates
9
10
Floating Storage and Regasification Unit (FSRU) Mobile Storage and Vaporization Small Permanent Storage Large Permanent Storage
Sean Lalani, President
Eagle LNG Partners seanlalani@eaglelng.com
