Intro to FreeSurfer Jargon Intro to FreeSurfer Jargon voxel surface volume vertex surface-based recon cortical, subcortical parcellation/segmentation registration, morph, deform, transforms (computing vs. resampling) Intro to FreeSurfer

slide-1
SLIDE 1

Intro to FreeSurfer Jargon

slide-2
SLIDE 2

Intro to FreeSurfer Jargon

voxel surface volume vertex surface-based recon cortical, subcortical parcellation/segmentation registration, morph, deform, transforms (computing vs. resampling)

slide-3
SLIDE 3

Intro to FreeSurfer Jargon

voxel

slide-4
SLIDE 4

Intro to FreeSurfer Jargon

surface

slide-5
SLIDE 5

Intro to FreeSurfer Jargon

surface

slide-6
SLIDE 6

Intro to FreeSurfer Jargon

vertex

slide-7
SLIDE 7

What FreeSurfer Does…

FreeSurfer creates computerized models of the brain from MRI data.

Input: T1-weighted (MPRAGE) 1mm3 resolution (.dcm) Output: Segmented & parcellated conformed volume (.mgz)

slide-8
SLIDE 8

Recon

“recon your data” …short for reconstruction …cortical surface reconstruction …shows up in command recon-all

slide-9
SLIDE 9

Recon

slide-10
SLIDE 10

Volumes

  • rig.mgz

T1.mgz brainmask.mgz wm.mgz filled.mgz (Subcortical Mass)

slide-11
SLIDE 11

Cortical vs. Subcortical GM

coronal sagittal

subcortical gm cortical gm

slide-12
SLIDE 12

Cortical vs. Subcortical GM

coronal sagittal

subcortical gm

slide-13
SLIDE 13

Parcellation vs. Segmentation

(subcortical) segmentation (cortical) parcellation

slide-14
SLIDE 14

Intro to FreeSurfer Jargon

voxel surface volume vertex surface-based recon cortical, subcortical parcellation/segmentation registration, morph, deform, transforms (computing vs. resampling)

slide-15
SLIDE 15

Registration

Goal: to find a common coordinate system for the input data sets Examples:  comparing different MRI images of the same individual (longitudinal scans, diffusion vs functional scans)  comparing MRI images of different individuals

slide-16
SLIDE 16

target

Inter-subject, uni-modal example

flirt 6 DOF subject flirt 9 DOF flirt 12 DOF

slide-17
SLIDE 17

Linear registration: 6, 9, 12 DOF

Flirt 6 DOF Flirt 9 DOF Flirt 12 DOF subject target

slide-18
SLIDE 18

Linear registration: 6, 9, 12 DOF

target subject Flirt 6 DOF Flirt 9 DOF Flirt 12 DOF

slide-19
SLIDE 19

Linear registration: 6, 9, 12 DOF

target subject Flirt 6 DOF Flirt 9 DOF Flirt 12 DOF

slide-20
SLIDE 20

Intra-subject, multi-modal example

before spatial alignment after spatial alignment

slide-21
SLIDE 21

before spatial alignment after spatial alignment

slide-22
SLIDE 22

before spatial alignment after spatial alignment

slide-23
SLIDE 23

Inter-subject non-linear example

target CVS reg

slide-24
SLIDE 24

Some registration vocabulary

 Input datasets:

 Fixed / template / target  Moving / subject

 Transformation models

 rigid  affine  nonlinear

 Objective / similarity functions  Applying the results

 deform, morph, resample, transform

 Interpolation types

 (tri)linear  nearest neighbor

slide-25
SLIDE 25

FreeSurfer Questions

Search for terms and answers to all your questions in the Glossary, FAQ,

  • r

FreeSurfer Mailing List Archives
