Intrinsically Safe Process control training presented by Grant Paul Novaris Pty Ltd Hazardous Areas Hazardous area an area where concentrations of flammable gases, vapors, or dusts may occur. Offshore platforms Petrochemical plants

slide-1
SLIDE 1
slide-2
SLIDE 2

Intrinsically Safe Process control training

presented by

Novaris Pty Ltd Grant Paul

slide-3
SLIDE 3

Hazardous Areas

Hazardous area – an area where concentrations

  • f flammable gases, vapors, or dusts may occur.
  • Offshore platforms
  • Petrochemical plants
  • Oil and gas tankers
  • Gas pipelines
  • Mines
  • Flour mills
slide-4
SLIDE 4

Hazardous Areas

Novaris Intrinsically Safe (IS) range

EEx ia IIC T4. (Type ia, Group 2C gases, Temperature category 4).

slide-5
SLIDE 5

Hazardous Areas

Gas zones

Zone 0 Flammable atmosphere highly likely to be present - may be present for long periods or even continuously (>10%) Zone 1 Flammable atmosphere possible but unlikely to be present for long periods (<10%, >0.1%) Zone 2 Flammable atmosphere unlikely to be present except for short periods of time - typically as a result of a process fault condition. (<0.1%)

slide-6
SLIDE 6

Hazardous Areas

Gas groups

Group Representative Gases I All Underground Coal Mining. Firedamp (methane) IIA Industrial methane, propane, petrol and the majority of industrial IIB Ethylene, coke oven gas and other industrial gases IIC Hydrogen, acetylene, carbon disulphide

IIC marked equipment can be used for both IIA and IIB

slide-7
SLIDE 7

Hazardous Areas

Temperature classification (Auto-ignition)

T-Class Hazards which will not ignite at temperatures below: T1 450°C T2 300°C T3 200°C T4 135°C T5 100°C T6 85°C

Gas Temperature Methane 580 °C Hydrogen 560 °C Propane 493 °C Ethylene 425 °C Acetylene 305 °C Naphtha 290 °C Carbon disulfide 102 °C

slide-8
SLIDE 8

Hazardous Areas – Type of Protection

Equipment Code Description Suitable for zones Ex ia Intrinsic safety 'ia' 0, 1, 2 Ex ib Intrinsic safety 'ib' 1,2 Ex ic Intrinsic Safety 'ic' 2 Ex d Flameproof protection 1,2 Ex p Purge/pressurized protection 1,2 Ex px Purge/pressurized protection 'px' 1,2 Ex py Purge/pressurized protection 'py' 1,2 Ex pz Purge/pressurized protection 'pz' 2 Ex e Increased safety 1,2 Ex m Encapsulation 1,2 Ex ma Encapsulation 0,1,2 Ex mb Encapsulation 1.2 Ex mc Encapsulation 2 Ex o Oil immersion 1,2 Ex q Sand / powder (quartz) filling 1,2 Ex n Type - n protection 2 Ex s Special protection Normally 1 and 2

slide-9
SLIDE 9

Hazardous Areas

Equipment category

Category 1 equipment may be used in zone 0, zone 1 or zone 2 areas Category 2 equipment may be used in zone 1 or zone 2 areas Category 3 equipment may only be used in zone 2 areas

slide-10
SLIDE 10

Hazardous Areas

Novaris Intrinsically Safe (IS) range

EEx ia IIC T4. (Type ia, Group 2C gases, Temperature category 4).

slide-11
SLIDE 11

Signal Line Protection for Process control

  • Plug in surge arrester module
  • Only 7mm wide
  • High Energy Design
  • Multistage Protection
  • IECEx ia IIC T4 certified
  • Failsafe design
  • Suitable for all signalling

applications

slide-12
SLIDE 12

SL Circuit Diagram

E1 E2 L1 L2

LINE LOAD

slide-13
SLIDE 13

Surge GDT MOV 2nd MOV

slide-14
SLIDE 14

Voltage vs. Frequency

slide-15
SLIDE 15

Threaded Signal Line Protectors

  • Protection for 2, 3 and 4 wire

process control transmitters

  • All mode protection
  • Does not affect calibration
  • IECEx ia IIC T4 Certified
  • M20x1.5 (IECEx Exd Certified)
  • ½” NPT
  • ¾” NPT
slide-16
SLIDE 16

SLT Circuit Diagram

SCN

L2 L1

slide-17
SLIDE 17

SSP6A Series Surge Protector

  • Plug in surge arrester

module

  • Only 7mm wide
  • 9.6kA Imax MOV

Protection

  • IECEx ia IIC T4 certified
  • Up to 6A pass through

current

slide-18
SLIDE 18

SSP6A Circuit Diagram

E1 E2 L1 L2

LINE LOAD

slide-19
SLIDE 19
slide-20
SLIDE 20

Analogue and Digital I/O

Cabinet earth SL-36-G Marshalling/System Cabinet Instrument Enclosure SLT1-36-M/NXX L1 L2 E1 E2 PLC/SCADA I/O + I/O -

slide-21
SLIDE 21

SSP6A - 250mA to 6A

Cabinet earth SSP6A-26-G Marshalling/System Cabinet Instrument Enclosure SLT1-36-M/NXX L1 L2 E1 E2 PLC/SCADA I/O + I/O -

slide-22
SLIDE 22

4-20mA loop

Cabinet earth SL-420-G Marshalling/System Cabinet Instrument Enclosure SLT1-36-M/NXX L1 L2 E1 E2 PLC/SCADA I/O + I/O -

slide-23
SLIDE 23

Interposing Relay Protection

Cabnet earth SSP6A-26-G Marshalling/System Cabinet Instrument Enclosure SLT1-36-M/NXX L1 L2 E1 E2 24VDC PS 24V + 0V - CH 0 PLC/SCADA Interposing Relay 6A

slide-24
SLIDE 24

Resistive Temperature Detectors – 4 Wire

Cabinet earth SL-RTD-G Marshalling/system cabinet Instrument Enclosure SLT4-RTD-M/NXX RTD Control Instrumentation Or PLC L1 L2 E1 E2 L1 L2 E1 E2

slide-25
SLIDE 25

Resistive Temperature Detector – 3 Wire & 4 Wire

Cabinet earth SL-RTD-G Marshalling/system cabinet Instrument Enclosure SLT4-RTD-M/NXX RTD Control Instrumentation Or PLC L1 L2 E1 E2 L1 L2 E1 E2 Cabinet earth SL-RTD-G Marshalling/system cabinet Instrument Enclosure SLT4-RTD-M/NXX RTD Control Instrumentation Or PLC L1 L2 E1 E2

slide-26
SLIDE 26

HART over 4-20mA Loop

Cabinet earth SL-DH-G Marshalling/System Cabinet Instrument Enclosure SLT1-36-M/NXX L1 L2 E1 E2 PLC/SCADA I/O + I/O -

slide-27
SLIDE 27

RS232

Cabinet earth SL-DH-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA RX TX Common Cabinet earth SL-DH-G Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA TX RX Common SCN SCN

slide-28
SLIDE 28

RS485

Cabinet earth SL485-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA TX/RX TX/RX Screen Cabinet earth SL485-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA TX/RX TX/RX Screen SCN SCN SCN SCN

slide-29
SLIDE 29

Multidrop RS485

Cabinet earth SL485-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA Tx/Rx+ Tx/Rx- Screen SCN SCN Cabinet earth SL485-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA Tx/Rx+ Tx/Rx- Screen Cabinet earth SL485-EC90 Marshalling/System Cabinet L1 L2 E1 E2 PLC/SCADA Tx/Rx+ Tx/Rx- Screen SCN SCN SCN SCN Cabinet earth SL485-EC90 Marshalling/system cabinet L1 L2 E1 E2 L1 L2 E1 E2 Tx/Rx+ Tx/Rx- Screen SCN SCN SCN SCN Tx/Rx+ Tx/Rx-

slide-30
SLIDE 30

RS422

Cabinet earth SL485-EC90 Marshalling/system cabinet L1 L2 E1 E2 L1 L2 E1 E2 Cabinet earth SL485-EC90 Marshalling/system cabinet L1 L2 E1 E2 L1 L2 E1 E2 Tx+ Tx- Rx+ Rx- Screen Rx+ Rx- Tx+ Tx- Screen SCN SCN SCN SCN SCN SCN SCN SCN

slide-31
SLIDE 31

Signal reference table

Signal/Protocol PLC/Cabinet Meter/Instrument ±5V Analogue or Digital SL7V5-G or SSP6A-14-G SLT1-7V5-M/NXX ±12V Analogue or Digital SL18-G or SSP6A-14-G SLT1-18-M/NXX ±24V Analogue or Digital SL36-G or SSP6A-26-G SLT1-36-M/NXX ±48V Analogue or Digital SL68-G or SSP6A-65-G SLT1-68-M/NXX ±110V Analogue or Digital SSP6A-130-G SDT2-130-M/NXX 4-20mA Loop SL420-G (also SL420i-G) SLT1-36-M/NXX 4 Wire RTD 2 x SL-RTD-G SLT4-RTD-M/NXX 3 Wire RTD 2 x SL-RTD-G SLT4-RTD-M/NXX 2 Wire RTD SL-RTD-G SLT4-RTD-M/NXX HART SL-DH-G SLT1-36-M/NXX RS232 SL-DH-G SL-DH-EC90 RS485 SL485-EC90 (also SL485i-EC90) SL485-EC90 RS422 2 x SL485-EC90 2 x SL485-EC90 Profibus DP SL485-EC90 SL485-EC90 Profibus PA SSP6A-38-G SSP6A-38-G Profinet UTP-RJ45-24CAT6 UTP-RJ45-1CAT6 Modbus Check physical layer Check physical layer Modbus – TCP UTP-RJ45-24CAT6 UTP-RJ45-1CAT6 Industrial Ethernet Network UTP-RJ45-24CAT6 UTP-RJ45-1CAT6 Computer Network (Ethernet) UTP-RJ45-24CAT6 UTP-RJ45-1CAT6
