Discriminating Among Direct Human Interventions and Climate Change Impacts on the Water Cycle H.P. Nachtnebel (IWHW-BOKU) hans_peter.nachtnebel@boku.ac.at Hydropredict2010 H.P. Nachtnebel Organisers and sponsors Hydropredict2010 H.P.

slide-1
SLIDE 1

Hydropredict2010 H.P. Nachtnebel

Discriminating Among Direct Human Interventions and Climate Change Impacts

  • n the Water Cycle

H.P. Nachtnebel (IWHW-BOKU) hans_peter.nachtnebel@boku.ac.at

slide-2
SLIDE 2

Hydropredict2010 H.P. Nachtnebel

Organisers and sponsors

slide-3
SLIDE 3

Hydropredict2010 H.P. Nachtnebel

Organisation of the presentation

  • Objectives and introduction
  • Methodology for assessing human impacts
  • Methodology for climate change impact studies
  • Identified changes and discrimination among CC

and HI

  • Summary and conclusions
slide-4
SLIDE 4

Hydropredict2010 H.P. Nachtnebel

Objectives

  • Analysis of changes in the hydrological cycle
  • Evaluation of methodological approaches to

discriminate among impacts originating from climate change, direct human intervention and natural variability of processes

  • Elaboration of techniques for regional impacts

studies

slide-5
SLIDE 5

Hydropredict2010 H.P. Nachtnebel

slide-6
SLIDE 6

Hydropredict2010 H.P. Nachtnebel

Methodology for the assessment of human interventions

  • Time series analysis
  • Experiments
  • Comparative studies
  • Detailed (physical) hydrological models
slide-7
SLIDE 7

Hydropredict2010 H.P. Nachtnebel

Role of scale

From Blöschl et al; 2007

slide-8
SLIDE 8

Hydropredict2010 H.P. Nachtnebel

Human Impacts at different scales

  • Linear, local measures (river channelisation)
  • Regional spatial measures (land use changes)
  • Large scale impacts (land use changes)
slide-9
SLIDE 9

Hydropredict2010 H.P. Nachtnebel

Channelisation of rivers

slide-10
SLIDE 10

Hydropredict2010 H.P. Nachtnebel

Impacts on floods

River training works Partial duration series of floods (1961-1992)

slide-11
SLIDE 11

Hydropredict2010 H.P. Nachtnebel

Climate change ?

  • No significant changes in the annual

precipitation (rather a decrease)

  • No significant change in intensive rainfall

events

Partial duration series of intensive rainfall events (Sajach)

slide-12
SLIDE 12

Hydropredict2010 H.P. Nachtnebel

Comparison of input and output

  • No significant change in precipitation (neither in

total amount, nor in extremes)

  • Increase in flood ferquency and intensity

Input Output Input Output

slide-13
SLIDE 13

Hydropredict2010 H.P. Nachtnebel

Land use changes in a smaller catchment

  • Catchment area about 700 km2
  • Increase in forested area in the last 100 years
  • Channelisation of rivers (up to 30 years flood)
  • Small increase in residential area
slide-14
SLIDE 14

Hydropredict2010 H.P. Nachtnebel

Assessment of Land Use Changes

A distributed model is applied (Debene and Nachtnebel, 2004)

Soil layer Surface runoff Interflow Groundwater flow Snow layer

Snow layer

Surface runoff

Identification of homogeneous regions HBV-type

slide-15
SLIDE 15

Hydropredict2010 H.P. Nachtnebel

Assessment of River Training Works in the Traisen catchment

Debene (2004)

Changes in the peak flow

Peak flow versus changes

Discharge (m3/s)

slide-16
SLIDE 16

Hydropredict2010 H.P. Nachtnebel

Assessment of Land Use Changes

The 1997 flood The 1997 event under conditions of 1880

Change in Peak flow Peak flow (m3/s)

slide-17
SLIDE 17

Hydropredict2010 H.P. Nachtnebel

Impacts on Aral Sea

slide-18
SLIDE 18

Hydropredict2010 H.P. Nachtnebel

Modelling the consequences

  • Modelling and simulation tools

hydrological model water balance model water management models agricultural models economic model ecological model (salinity, variability, depth)

  • Impacts on the water bodies of

Aral Sea

  • Impacts on the Delta areas
  • Impacts on the Priaralie region
slide-19
SLIDE 19

Hydropredict2010 H.P. Nachtnebel

The Aral Sea catchment

  • Growth of population
  • Enlargement of irrigation from 1950-1980
  • Increase of industrial water demand
  • Inefficient water use
  • Lack of international cooperation
  • The inflow to Aral Sea has been drastically

reduced

  • The seasonal cycle has been changed
  • …..
slide-20
SLIDE 20

Hydropredict2010 H.P. Nachtnebel

Conclusions

  • The direct human impacts are measurable
  • The human impacts may change the water

regime drastically

  • Human impacts may chane also the seasonal

cycle

  • What‘s about climate impacts ?
slide-21
SLIDE 21

Hydropredict2010 H.P. Nachtnebel

Methodology for the assessment of climate change impacts

  • Trend analysis of time

series

  • Comparative catchment

studies

  • GCMs and RCMs
  • Downscaling approaches

1912 1969 Vernagt glacier

Wanner et al. 2000

slide-22
SLIDE 22

Hydropredict2010 H.P. Nachtnebel

Do Heavy Rainfall Events Become more Frequent ?

Zahl der Tage mit mehr als 30 mm Niederschlag in Wien Reihe 1961 - 2001

2 1 4 1 1 1 2 3 1 3 1 2 2 1 2 2 1 1 2 1 2 4 3 2 2 2 5 4 2 2

1 2 3 4 5 6 1961 1962 1963 1964 1965 1966 1967 1968 1969 1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 Jahr Tage

(after Rudel, ZAMG 2002)

YES !!!!

Number of days per year with more than 30 mm/day (Vienna)

slide-23
SLIDE 23

Hydropredict2010 H.P. Nachtnebel

Do Heavy Rainfall Events Become more Frequent ?

Zahl der Tage mit mehr als 30 mm Niederschlag in Wien Reihe 1903 - 2001

3 2 1 2 3 1 2 3 1 5 1 3 44 00 22 33 2 4 2 1 2 4 2 11 2 1 3 3 4 22 5 22 3 11 00 44 222 11 3 5 2 1 4 1 11 2 3 1 3 1 2 2 1 2 00 2 1 1 2 1 2 4 3 22 2 5 4 2 2

1 2 3 4 5 6 1903 1905 1907 1909 1911 1913 1915 1917 1919 1921 1923 1925 1927 1929 1931 1933 1935 1937 1939 1941 1943 1945 1947 1949 1951 1953 1955 1957 1959 1961 1963 1965 1967 1969 1971 1973 1975 1977 1979 1981 1983 1985 1987 1989 1991 1993 1995 1997 1999 2001 Jahr Tage

(after Rudel, ZAMG 2002)

NO !!!!

Number of days per year with more than 30 mm/day (Vienna)

slide-24
SLIDE 24

Hydropredict2010 H.P. Nachtnebel

Possible impacts of climate change on the water balance of Austria

  • Analysis at the catchment scale require high

resolution models (RCMs) or any downscaling approach

  • REMO-UBA RCM was used (10*10 km grid)

Quelle: Formayer

Anomalies in temperature Anomalies in rainfall

slide-25
SLIDE 25

Hydropredict2010 H.P. Nachtnebel

Analysis of RCMs

  • The simulated T and P time series show large

deviations from observations

  • The spatial pattern is shifted
  • Data need adjustment (bias correction,

transfomation, quantile mapping, etc.)

  • The scenario outputs show large differences in P
  • Large uncertainty in the simulated data
slide-26
SLIDE 26

Hydropredict2010 H.P. Nachtnebel

Comparison between simulation and

  • bservation for the control period
slide-27
SLIDE 27

Hydropredict2010 H.P. Nachtnebel

Climate signal in T and P

Temperature Precipitation Difference of long term mean values (1961-1990 und 2036-2065) A1B scenario

slide-28
SLIDE 28

Hydropredict2010 H.P. Nachtnebel

Changes of long term mean values of precipitation

Long term mean annual precipitation

slide-29
SLIDE 29

Hydropredict2010 H.P. Nachtnebel

Hydrological simulation

  • RCM- data were corrected
  • A 1*1 km grid was used for Austria
  • Simualtion at monthly time steps
  • The hydrological model was calibrated for the

past by fitting to 188 gauging stations

  • Glaciers were also simulated
slide-30
SLIDE 30

Hydropredict2010 H.P. Nachtnebel

Some simulation results (1961-1990) flow duration curves

slide-31
SLIDE 31

Hydropredict2010 H.P. Nachtnebel

Veränderungen im Abfluss

A1B scenario Difference between 1961-1990 in mm

  • 2011-2040
  • 2036-2065
  • 2061-2090

Changes in mean annual runoff

slide-32
SLIDE 32

Hydropredict2010 H.P. Nachtnebel

Water balance of Austria

  • The observed trend in the last fifty years is also

found in the hydrological simulations

  • A different development N and S of the

mountains (in the South decrease in the North a small increase in P)

  • Runoff decreases between 5-25 % due to

increased evaporation

slide-33
SLIDE 33

Hydropredict2010 H.P. Nachtnebel

Large scale simulations: precipitation

slide-34
SLIDE 34

Hydropredict2010 H.P. Nachtnebel

Large scale simulations: runoff

Change in annual river runoff between the 1961-1990 baseline period and two future time slices (2020s and 2070s) for the A2 scenarios (Alcamo et al., 2007).

slide-35
SLIDE 35

Hydropredict2010 H.P. Nachtnebel

Considering both:

  • Human impacts: dams, irrigation,…
  • Climate change
  • At the global scale
slide-36
SLIDE 36

Hydropredict2010 H.P. Nachtnebel

slide-37
SLIDE 37

Hydropredict2010 H.P. Nachtnebel

slide-38
SLIDE 38

Hydropredict2010 H.P. Nachtnebel

slide-39
SLIDE 39

Hydropredict2010 H.P. Nachtnebel

Water Stress Changes until 2025

80% of future stress from population & development not climate change! e.g. 85% US global change research funding goes to climate and carbon

(Vörösmarty et al. 2001)

slide-40
SLIDE 40

Hydropredict2010 H.P. Nachtnebel

Role of scale

  • Land use impact may increase with catchment

area (Aral Sea catchment, Nile,…)

  • Climate change impact may decraese with

catchment area (when areas with different climate signals are within the catchment)

slide-41
SLIDE 41

Hydropredict2010 H.P. Nachtnebel

Summary and conclusions

  • In all our data we find both: human impacts and

climate change

  • In many regions the direct human impacts on

water resources are much larger than expected changes

  • For climate change impacts studies a careful

adjustment of RCM data is needed, otherwise…

  • Large uncertainty in RCMs
  • Select different model outputs and different

emission scenarios

slide-42
SLIDE 42

Hydropredict2010 H.P. Nachtnebel

Thank you for your attention
