Click to edit Master title style Interactive Modelling and Rendering of Clouds Jesper Mosegaard , PhD Head of Computer Graphics Lab Alexandra Institute Denmark Click to edit Master title style 19/03/15 Page 2 The Alexandra Institute Click

slide-1
SLIDE 1

Click to edit Master title style

Jesper Mosegaard, PhD Head of Computer Graphics Lab Alexandra Institute Denmark

Interactive Modelling and Rendering of Clouds

slide-2
SLIDE 2

Click to edit Master title style

19/03/15 Page 2

slide-3
SLIDE 3

Click to edit Master title style

  • Private not-for-profit company within IT

– Technology transfer from University research through GTS institutes (Danish model)

  • Application oriented research
  • Consultancy for companies

The Alexandra Institute

slide-4
SLIDE 4

Click to edit Master title style

Interdisciplinary collaboration

slide-5
SLIDE 5

Click to edit Master title style

Problem statement

19/03/15 Page 5

slide-6
SLIDE 6

Click to edit Master title style

… even more difficult

slide-7
SLIDE 7

Click to edit Master title style

  • Simulating fluid dynamics is slow
  • Shaping through parameters is in-direct
  • Viewport does not represent final quality

Traditional workflow

19/03/15 Page 7

From https://vimeo.com/30189748

slide-8
SLIDE 8

Click to edit Master title style

External video

slide-9
SLIDE 9

Click to edit Master title style

  • User-guided procedural content generation with instant feedback to make even

the most advanced setups possible.

  • High-quality real-time rendering which allows for continuous visual quality

tweaking.

  • Less time spent waiting.

– More time for what really matters – being creative.

Taming the Elements

slide-10
SLIDE 10

Click to edit Master title style

This month tutorials featured in

19/03/15 10

Elementacular.com

slide-11
SLIDE 11

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

slide-12
SLIDE 12

Click to edit Master title style

Data Representation

Antoine Bouthors et. al.: ”Interactive multiple anisotropic scattering in clouds”

slide-13
SLIDE 13

Click to edit Master title style

Rasterization-based voxelization

"Octree-Based Sparse Voxelization Using The GPU Hardware Rasterizer" Cyril Crassin (NVIDIA), Simon Green (NVIDIA), in OpenGL Insights, July 2012

slide-14
SLIDE 14

Click to edit Master title style

Voxelization Results

slide-15
SLIDE 15

Click to edit Master title style

Voxelization Results

slide-16
SLIDE 16

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

✔

slide-17
SLIDE 17

Click to edit Master title style

  • Voxelization produces voxels for each triangle fragment.

– In practice a lot of geometry is self-intersecting. – We need the outer voxels for distance field calculation

Why do we need to floodfill?

slide-18
SLIDE 18

Click to edit Master title style

  • Easy-to-use general-purpose compute.
  • OpenGL 4.3 feature.
  • Very powerful coupled with Image load/store.

– Read/write to 3D texture at arbitrary positions. – Perform atomic operations on storage.

Compute Shaders

slide-19
SLIDE 19

Click to edit Master title style

  • Two Compute Shaders

– tag initial outside voxels (if visible from all three axes) – Iteratively grow voxels outside.

Floodfilling on the GPU

Input mesh Thin voxelization Initial tagging Iterative growth

slide-20
SLIDE 20

My ¡Cloud ¡

slide-21
SLIDE 21

Thin ¡shell ¡voxeliza3on ¡

slide-22
SLIDE 22

Seed ¡floodfill ¡

slide-23
SLIDE 23

Itera3ve ¡floodfill ¡

slide-24
SLIDE 24

Itera3ve ¡floodfill ¡

slide-25
SLIDE 25

Itera3ve ¡floodfill ¡

slide-26
SLIDE 26

Itera3ve ¡floodfill ¡

slide-27
SLIDE 27

Itera3ve ¡floodfill ¡

slide-28
SLIDE 28

Removing ¡internal ¡voxels ¡

slide-29
SLIDE 29

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

✔ ✔

slide-30
SLIDE 30

Click to edit Master title style

  • Single compute shader.
  • Propagate distance information from initial surface voxels:

– If voxel is tagged as outside and not part of the initial surface, pull minimum distance. – Combine using imageAtomicMin. – Complicated by the fact that atomic operations only work on 32bit integers.

Dilation and Distance Estimation

slide-31
SLIDE 31

Ini3al ¡distances ¡to ¡triangles ¡

slide-32
SLIDE 32

Distance ¡itera3on ¡1 ¡

slide-33
SLIDE 33

Distance ¡itera3on ¡2 ¡

slide-34
SLIDE 34

Map ¡to ¡densi3es ¡

slide-35
SLIDE 35

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

✔ ✔ ✔

slide-36
SLIDE 36

Click to edit Master title style

  • Specialized compute shaders.
  • A major part of getting the look right.
  • Fractals based on GPU generated Simplex and Worley noise
  • Wispys based on gridless advection

Making Some Noise

Based on Siggraph 2011 Course “Production Volume Rendering Systems”.

slide-37
SLIDE 37

Click to edit Master title style

Making Some Noise

slide-38
SLIDE 38

19/03/15 ¡ Page ¡38 ¡

Simplex ¡roughness ¡ Wispy ¡roughness ¡

slide-39
SLIDE 39

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

✔ ✔ ✔ ✔

slide-40
SLIDE 40

Click to edit Master title style

Real-time single scattering

slide-41
SLIDE 41

Click to edit Master title style

  • Single- vs. multi-scatter of light in volumes

Lighting the Volumes

Multi-scatter (FLD) Combination Single-scatter

slide-42
SLIDE 42

Click to edit Master title style

Multi-scatter

19/03/15 Page 42

  • D. Koerner, J. Portsmouth, F. Sadlo, T. Ertl, B. Eberhardt:

Flux-Limited Diffusion for Multiple Scattering in Participating Media Computer Graphics Forum, vol. 33, no. 6, pp. 178-189, 2014.

slide-43
SLIDE 43

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Whispy Field

✔ ✔ ✔ ✔ ✔

Distance Field Noise Field

slide-44
SLIDE 44

Click to edit Master title style

  • Naïve approach:
  • Prohibitively slow for real-time.

Real-time single scattering

slide-45
SLIDE 45

Click to edit Master title style

  • Exploit the fact that in-scattered irradiance can be separated from

primary ray absorption.

  • Update only when lights are dirtied.
  • March towards each light accumulating the irradiance into a separate

light buffer using compute shader.

  • When raymarching – Use light buffer instead of marching to light.

Real-time single scattering

slide-46
SLIDE 46

Click to edit Master title style

Overview

Raymarch Voxelization Floodfilling Dilation & distance approximation Light Fields Raymarch User- controlled fractal evaluation Mesh Image Distance Field Noise Field Whispy Field

✔ ✔ ✔ ✔ ✔ ✔

slide-47
SLIDE 47

Click to edit Master title style

  • Animation
  • Other plugins for real-time editing of natural effects
  • Integrate into later stages of the production pipeline

Future work

slide-48
SLIDE 48

Click to edit Master title style

Users are what makes this interesting

slide-49
SLIDE 49

Click to edit Master title style

Thank you for your attention

Mail: jesper.mosegaard@alexandra.dk Twitter: @mosegaard LinkedIn: linkedin.com/in/mosegaard Please complete the Presenter Evaluation sent to you by email or through the GTC Mobile App. Your feedback is important!
