Integrating Spark MLlib into Weka

Mark Hall Pentaho Data Mining Architect, Hitachi Vantara

Agenda

The Spark distributed processing framework was designed with iterative machine learning in mind. This session discusses:

• Integration of MLlib classification algorithms into Weka
• Consistent evaluation of algorithms on the desktop and in the cluster
• Benefits for data science practitioners

What’s Weka?

• Weka is a library containing a large collection of

machine learning algorithms, implemented in Java

• Main types of learning problems that it can tackle

– Classification: given a labeled set of observations, learn to predict labels for new observations – Regression: numeric value instead of label – Attribute selection: find attributes of observations that are important for prediction – Clustering: no labels, just identify groups of similar

• bservations (clusters)
• 190 plugin “packages”

Introduction

• Distributed Weka for

Spark package:

• Averaging for several

classifiers

• “Dagging” for all the rest
• Ensembles via Dagging can

work well, but…

– Partition size is another tuning parameter – Small partitions might lead to poor modelling power

Instances data

RDD<Instance>

Instances data

Partition 0 Partition 1

Instances streamed or batched to algorithm

Map partitions

Instances streamed or batched to algorithm Model Model

Cached

Voted ensemble

RDD<Model>

MLlib

• Small set of algorithms
• Learning is fully distributed —> single final model
• Could have an accuracy advantage over Dagging for complex problems
• Definitely has an advantage when model comprehensibility is important
• New distributedWekaSparkDev package

– No coding MLlib integration

MLlib Integration in Weka: Desktop Mode

• Weka wrapper classifiers for MLlib supervised

learning schemes

• Work like any other Weka classifier
• Operate on datasets that fit into main memory on

the desktop

• Can be used within Weka’s evaluation framework,

used as base classifiers in meta learners, combined with preprocessing filters, used in standard Knowledge Flow processes and used in repeated cross-validation experiments in the Experimenter

Under the Hood

• WEKA MLlib classifiers accept standard Instances
• bjects
• Weka filters are applied automatically (where

necessary)

– MLlibNaiveBayes wrapper discretizes numeric fields for Bernoulli model

• Instances are parallelized to RDD[Instance]
• RDD[Instance] converted to RDD[LabeledPoint]
• Local Spark cluster started on the fly
• Scoring only requires LabeledPoint data structure

– no Spark cluster/infrastructure required

MLlib Integration in Weka: Distributed Weka

• Run in a cluster
• Data sourced from Spark data frame-support formats
• Data frames converted to RDD[Instance], then to RDD[LabeledPoint]
• Weka filters can be applied within each RDD partition
• Implements hold-out and cross-validation for evaluation

Cross-Validation

• X-val folds that are consistent for both MLlib and Weka classifiers
• Max parallelism for Weka Dagging/model averaging

– Build all training fold classifiers in one pass over the data – Evaluate all classifiers in second pass Pass 1 Pass 2

Cross-Validation for MLlib

• MLlib classifiers – new

RDD for each training fold

– Assemble partial folds for fold k – Each fold processed sequentially in turn Fold 1 Fold 2 Fold 3 Fold 1 Fold 2 Fold 3

RDD partitions (original dataset)

Fold 1 Fold 1 Fold 2 Fold 2 Fold 3 Fold 3

RDD for test fold 1 RDD for training fold 1

MLlib M1

Partition 1 Partition 2

Demonstration

• MLlib classifiers running in Weka

Explorer, and Knowledge Flow

• Comparing MLlib schemes against

Weka, R and Python equivalents in the Weka Experimenter

• Deploying an MLlib model in PDI’s

WekaScoring step

Summary

What we covered today:

• Integration of MLlib algorithms continues Weka’s interoperability theme
• Provides convenient no-coding access to Mllib algorithms for desktop and

cluster-based execution

• Simplifies the data scientist’s job when considering multiple tools

– Weka vs R vs Scikit-learn vs MLlib within one unified experimental framework

Next Steps

Want to learn more?

• http://wiki.pentaho.com/display/DATAMINING/Pentaho+Data+Mining+Commun

ity+Documentation

• http://markahall.blogspot.co.nz/2017/07/integrating-spark-mllib-into-

weka.html
