Integrated Thermal Management Technology When is therm TECH required ? When luminaires are left running during the day or to prevent thermal runaway. What is required for therm TECH in an application ? High wattage & external luminaires need

SLIDE 1

SLIDE 2

Integrated Thermal Management Technology

When is thermTECH required ?

When luminaires are left running during the day or to prevent thermal runaway.

What is required for thermTECH in an application ?

High wattage & external luminaires need an intelligent LED driver with NTC capabilities.

SLIDE 3

SLIDE 4

NTC : Negative Temperature Coefficient

The function of the NTC is to send a signal to the LED driver to reduce the output current to the LED’s. This is done when the temperature is too high. It will reduce the current therefore reducing the heat.

Temperature(°C) Current(mA)

Current VS Heat

Temperature

WHAT IS NTC?

LED max temp (110°) (110°)

SLIDE 5

SLIDE 6

SLIDE 7

SLIDE 8

LED & TEMPERATURE MEASUREMENT POINT

SLIDE 9

SLIDE 10

SLIDE 11

Argo Istria Lumina Modra Rhoda

Max temp: 96°C @ 700mA Max temp: 89°C @ 900mA Max temp: 82°C @ 900mA Max temp: 102°C @ 1050mA Max temp: 87°C @ 900mA

Max current RLS runs LED’s LED Max Current RLS Max Current

Oslon Giant 1800mA 1050mA Duris E5 180mA 116mA Duris E3 100mA 38mA E2835 120mA 55mA

WHERE TO USE NTC?

OSLON GIANT Maximum Ambient Temperature = 135°C Tc

SLIDE 12

LIGHT DEGREDATION CURVE | OSLON GIANT

SLIDE 13

LIGHT DEGREDATION CURVE | DURIS E5
