INOAC COOL SYSTEM “ Quality Control of cold distribution – INOAC Cool System”, this effective and ideal cold insulation system securely and flexibly meets the needs of the most demanding distribution site. ① A wide temperature range We provide variety of Gel temp. and Gel size to suitable with customer application. ② Complete solution We work with you to select the very best combination of material to ensure optimum temperature control. ③ Eco-friendly Reusable, Save the environment and Save money. ④ Safe & Reliable No Toxic or Hazardous materials, Safe ad Efficient cold insulation transport systems. ⑤ After-sales service On-the-spot testing of product temperatures and fine-tuning ensure the optimum cold solution.

INOAC COOL SYSTEM Cold Transport Cold Gel Pack Containers

Cold Gel Pack INOAC COOL SYSTEM Cost-sav saving ng Repeated-use cold gel packs costs. Eco-fr Eco frie iendly ly An eco-friendly natural gel. (Food additive type and industrial gel are also available.) Pra ractica tical Integrated design with many kinds of cooler boxes. Dura rable le Diverse product range from a simple mate to superior durable plastic container.

Cold Gel Pack INOAC COOL SYSTEM Temperature bands of cold gel packs Six bands from melting point 0 to -25 C are available and give a good range of temperature control ※ Freezer temperature require lower than cold gel packs temperature 10 ℃ . Ex. Cold Gel -5 ℃ required Freezer -15 ℃

Cold Gel Pack INOAC COOL SYSTEM Cold Gel Pack Series ① COOL Series Reusable plastics container type. 140Wx195Lx25Tmm 142Wx235Lx30Tmm 180Wx280Lx29Tmm ② CO Series General-purpose pouch type for one way use. 220Wx140Lmm

Cold Gel Pack INOAC COOL SYSTEM ( For Thai market survey ) Break Even Point Calculate Comparison with INOAC Cold Gel COOL type : “ 250 Baht per Kg.” 20 Baht per kg. 5 Baht per kg. Just 13 times to B.E. !!! Just 50 times to B.E. !!! Cooling Item 50 shipment 10 shipment 100 shipment (Price/Kg.) Ice 5 Baht 50 Baht 250 Baht 500 Baht 200 Baht 1,000 Baht 2,000 Baht Dry ice 20 Baht 250 Baht 250 Baht 250 Baht INOAC Cool gel 250 Baht

Cold Gel Pack INOAC COOL SYSTEM Requirement for calculate quantity of Cold gel usage

Cold Transport Containers INOAC COOL SYSTEM Hi High gh-per performa formance c ce cold ld insulatio lation n storage storage Superb shielding and insulation gives outstanding cold storage. Increase reased tra ransp nsport ort effic fficie iently ntly Consolidated delivery and stacking operations increase loading efficiency. Comp mpac act When not in use containers, you can fold and stack away. Ease ase of h f han andling Some product allow container stacking. Superb light weight. Hygien Hy gienic ic Outstanding strength and easy maintenance.

Cold Transport Containers INOAC COOL SYSTEM Can setup with Trolley Can fold up, compact Light weight and easy Thermal Insulation delivery for warm goods is possible. for easy move. and space saving. to use. - Insulate thickness 6mm - Insulate thickness 30mm - Suitable for Chilled goods - Suitable for Frozen goods

INOAC COOL SYSTEM Cold storage container with high insulation and shielding properties

INOAC COOL SYSTEM Available products ① NeoCarter A5 Size: 570W x370L x 470Hmm ② NeoCarter B1 Size: 420Wx370Lx470Hmm

INOAC COOL SYSTEM ③ NeoCarter C1 Size: 730Wx550Lx1450Hmm ※ Normally Set up with Roll Box

INOAC COOL SYSTEM Lightweight container with excellent constant temperature control. Higher level of cold storage control. ① NeoAce Folding Type Size: 610W x380L x 550Tmm

INOAC COOL SYSTEM ② NeoAce for Roll Box Size: 730Wx550Lx1450Hmm

Cold Transport Containers INOAC COOL SYSTEM Available Option Pocket for Cold Gel Pack

INOAC COOL SYSTEM Required Temp. Cold Box Target Item Cold Gel -21 ℃ 、 - 25 ℃ Ice Cream -18 ℃ ↓ NeoCarter (+ little dry ice) <500Wx350Lx450H> <8pcs> Bet.-8 ～ -12 ℃ -11 ℃ 、 -15 ℃ Frozen Food NeoCarter <500Wx350Lx450H> <6pc> Bet. -3 ～ 5 ℃ Chilled Food NeoCarter 0 ℃ , -5 ℃ <500Wx350Lx450H> Bet. 0 ～ 10 ℃ Dairy/Milk <4pc> Condition: ① Outside Temp:35 ℃ ② Delivery Duration: 4hrs ③ Properly Cooled Before Transportation ④ Cold Gel Pack: CAH-1001

INOAC COOL SYSTEM Required Temp. Cold Box Target Item Cold Gel Ice Cream -18 ℃ ↓ -21 ℃ , - 25 ℃ NeoAce (+ little dry ice) <610Wx370Lx540H> <6pcs> Bet.-8 ～ -12 ℃ -11 ℃ , -15 ℃ Frozen Food NeoAce <610Wx370Lx540H> <5pc> Bet. -3 ～ 5 ℃ Chilled Food NeoAce 0 ℃ , -5 ℃ <610Wx370Lx540H> Bet. 0 ～ 10 ℃ Dairy/Milk <4pc> NeoAce Bet. 2 ～ 8 ℃ Vaccine/Blood 0 ℃ <610Wx370Lx540H> <5pc> + PE Sheet (5Tmm) Condition: ① Outside Temp:35 ℃ ② Delivery Duration: 6 ～ 8hrs ③ Properly Cooled Before Transportation ④ Cold Gel Pack: CAH-1001
