ICS COOL ENERGY

THE TEMPERATURE CONTROL SPECIALISTS

ICS COOL ENERGY

THE TEMPERATURE CONTROL SPECIALISTS

ICS COOL ENERGY

THE TEMPERATURE CONTROL SPECIALISTS

GLOBAL PRESENCE, LOCAL SERVICE

WHERE WE MAKE IT WORK

REFERENTIES

GROUP ACCREDITATIONS

i-CHILLER

• 10°C to 30°C | 1.7 TO 505kW

i-CHILLER COMPACT i-CHILLER i-CHILLER MAX

• 10°C to 30°C

Process cooling duties from 7.2 to 233kW 19 sizes

• 10°C to 20°C

Process cooling duties 243 to 505kW 8 sizes 0°C to 30°C Process cooling duties from 1.7 to 4.7kW 4 sizes EcoDesign compliant Stock available immediately Fast cusomisation of standard models Individually factory tested Efficient R410A refrigerant Up to 5-year warranty 3-Bar pump as standard Dual Frequency (50/60HZ) version 7 to 65kW

i-TEMP

• 20°C to 400°C | Up to 1600kW

i-TEMP Indirect and direct water, pressurised water and oil TCUs up to 350°C Heating capacities from 4 to 72kW Cooling capacities from 23 to 600kW i-TEMP COMPACT Indirect and direct water TCUs up to 160°C Heating capacities from 6 to 36kW Cooling capacities from 23 to 600kW i-TEMP MAX Indirect and direct water, oil and thermal oil TCUs up to 400°C Electric heating capacities from 9 to 360kW Steam heating capacities up to 1600kW Cooling capacities from 92 to 1600kW Standard and compact version in stock and available immediately Fast customisation of standard models Advanced controller with LCD screen Interface options including ethernet and profibus Data capture to SD card Flow manifold attachment for greater temperature distribution

CHILLERS & FREE COOLING

• 10°C to 20°C | 5kW to 4MW

DRY AIR COOLERS ADIABATIC COOLERS

Ambient Air Coolers with Adiabatic Spray System 5kW to 4MW Ambient Air Coolers 5kW to 4MW

APTUS IMPERIUM MAGNUS

Chiller with scroll compressors

• 12°C to +20°C

25kW to 850kW Chiller with fixed or variable speed screw compressors

• 12°C to +20°C

300kW to 4MW Chiller with Turbocor compressor +5°C to +18°C 750kW to 3.5MW Versions available:

• Air Cooled
• Water Cooled
• Reversible Air

Cooled

• Reversible Water

Cooled

• Air Source

Simultaneous Heating & Cooling

• Internal Air Cooled
• Partial Free Cooling

with or without glycol

• Full Free Cooling

with or without glycol

• Partial Heat

Recovery

• Full Heat Recovery
• Condenserless
• High / Extra High

Efficiency

• Low / Extra Low

Noise

• Alternative low-GWP

refrigerant choices

CHILLER REFRIGERANT SELECTION R134a | R513A | R1234ze

✓ Best GWP ✓ Best EER / ESEER ✓ Heating @85C

• Larger Footprint
• Costs +15% appr
• Reduced Max Cap

✓ No Cost Penalty ✓ No Cap / size penalty

• Better GWP
• EER -5% / ESEER -1%

✓ No Cost Penalty ✓ No Cap / size penalty

• High GWP

✓ IMFA ✓ MAFA ✓ IMDW ✓ IMFW ✓ IMFH ✓ MAFW ✓ IMFA ✓ MAFA ✓ IMDW ✓ IMFW ✓ IMFH ✓ MAFW ✓ IMFA ✓ MAFA ✓ IMDW ✓ IMFW ✓ IMFH ✓ MAFW

GOOD BETTER BEST

FREE COOLING Free cooling utilises external ambient temperatures below your process

• perating temperature to reduce your energy costs by up to 70%.

Chillers with integrated free cooling provide efficiency with a smaller

• footprint. Dry Air Coolers provide bolt-on free cooling for even greater

efficiency due to the larger surface area.

SPECIAL PROCESS TEMPERATURE CONTROL SOLUTIONS

SPECIAL PROCESS TEMPERATURE CONTROL

Low temperature chillers to -40°C Full turnkey solutions for dimensional constraints Specification led projects Special fluid chillers & TCUs ATEX rated chillers & TCUs In-house technical expertise & design

Designed to meet your unique requirements and compliance standards

FULL TURNKEY PROJECTS

Your project delivered on time, on budget and hassle-free

Delivery, installation and commissioning Schematic drawings provided Integration with BMS System design to meet your exact requirements and budget Dedicated Regional Contract Manager Comprehensive site survey

PROJECT CONSIDERATIONS

Matching design loads Water leaving Temperature? Ambient Location Noise requirements Capacity control? Comparing equipment Compressor type:

• Screw
• Scroll
• Centrifugal

Free cooling Energy analysis / Power considerations Contingency planning Support

INSTALLATION

INSTALLATION MANAGEMENT

Attend site survey to confirm requirements Site survey and Assessment of current system Product selection System design and enabling works assessed and costed Quote presented for assessment and approval Site meeting with project manager and appropriate site staff RAMS and project Schedule submittal for approval minimum two weeks prior to commencement Carry out all elements of installation works, project manager to attend as required at milestone points Commission system upon completion Site visit for ’snagging’ if required INSTALLATION MANAGEMENT Project documentation and sign off

COMMISSIONING

COMMISSIONING

Factory trained & qualified technicians In-house technical & QHSE team Fully documented SATs & FATs Configured to meet your exact requirements Pre-commissioning water analysis 100-point full electrical, mechanical & hydraulic system commissioning

AFTERSALES

PPM & CONDITION BASED MONITORING

Remote monitoring Water treatment Parts & Glycol 24/7 breakdown support Energy efficient system enhancements & energy monitoring 100+ point maintenance program & tailored SLAs

Protecting your investment and minimising the risk of downtime

Benefit from: Tailor a package to include:

Free Technical Support Glycol Check Prioritised Calls 24/7 Engineer Availability F-Gas Compliance Custom Reporting Remote Monitoring Thermal Imaging Tailored Response Times Water treatment plan

PLANNED PREVENTATIVE MAINTENANCE

Water quality checks

Reduced labour rates

Discounted Spare Parts & Labour

Extended Warranty

Up to date Maintenance Log

• Experienced team of 45 fully qualified

Service Engineers

• Engineers located throughout UK and

Europe

• All Engineers are fully conversant with

current F-Gas Regulations, safe handling

• f refrigerants, COSHH and Health &

Safety Risk Assessment Regulations

• Engineers on call 24/7

FULLY QUALIFIED ENGINEERS

• 24/7 Support for planned

and emergency projects (45 Service Engineers in the UK)

• National depots and regional
• ffices located throughout

Europe

• 270+ Employees throughout

Europe

LOCAL SUPPORT, NATIONWIDE NETWORK

SHORT & LONG-TERM HIRE SOLUTIONS

Technically trained hire specialists 24/7 emergency service 500 Megawatt Hire Fleet available for heating and cooling Full turnkey solution including site visit and specification Tailored contingency plans Remote monitoring & inclusive boiler fuel management

COOLING HIRE PRODUCT RANGE

DRY AIR COOLERS PORTABLE AIR CONDITIONING FAN COILS & FAN COILS LT AIR HANDLING UNITS AIR & WATER CHILLERS COOLING TOWERS

HVAC & PROCESS

HIRE HEATING PRODUCT RANGE

DIESEL HEATERS TCUs ELECTRIC BOILERS OIL, GAS & STEAM BOILERS FAN HEATERS

HVAC & PROCESS

FUEL TANKS

Tailored to your industry, application and operation...

Technical sales specialists Full turnkey, energy efficient solutions Process specific temperature control Carbon Trust & Eurovent accredited with Eco-Design compliance World-wide service engineer team coverage

COMPLETE TEMPERATURE CONTROL SOLUTIONS

VRAGEN?

BEDANKT VOOR UW AANDACHT

24/7: 088 – 258 2580

Voornaam Achternaam Functie voornaam.achternaam@icscoolenergy.com GSM: +31 (0) 6 ?? ?? ?? ??
