Incorporating Molecular Flexibility into Three- Dimensional Structural Kernels

Andreas Jahn

• 4. German Conference on Chemoinformatics

10.11.2008 Goslar

Andreas Jahn

2

Introduction & Motivation

“… enzyme and substrate must fit each other like a lock and key.” (Emil Fischer, 1894) “Form follows function.” (Louis H. Sullivan, 1896) Activity is a function of the 3D structure.

• 3D structure is not unique due to the flexibility
• f the compounds.
• What are the possible 3D structures?
• Possible solution:

Conformational sampling

• But: Time-consuming & non deterministic

Try to encode the flexibility and possible shape into the data structure.

Andreas Jahn

3

Basics

Optimal Assignment Kernel

• Atom-based similarity measure
• RBF kernel calculates local

atom similarity using atom and bond descriptors

• Incorporates the local

neighbourhood

• Atom-wise similarity acts as

weight of an edge in complete bipartite graph.

• Choose edges that maximize the

sum of the edges.

source; QSAR Comb. Sci., 2006, 25, 4, 317-323

) , ( ) , (

RBF

j i j i w Κ =

+

) , ( ) , (

RBF 1 RBF 1

j1 i2 j1 i1 Κ + Κ γ γ

+

• +

Κ ) , (

RBF 2

j2 i3 γ

Andreas Jahn

4

Basics Two problems of the Optimal Assignment Kernel Fix the kernel matrix with

source; J.-P. Vert, Technical Report HAL-002182 78, 2008

Ι − Κ ← Κ

min

λ

The Optimal Assignment Kernel is not a valid kernel function. No consideration of the flexibility and the shape of the structures.

Andreas Jahn

5

Methods - Overview

Two different methods were implemented

• OAKFLEX
• Encode the neighbourhood flexibility space relative to an atom.
• Determine the similarity of the flexibility space.
• Incorporate the similarity of the flexibility space into the Optimal

Assignment Kernel.

• Rigid Superposition
• Identify rigid scaffolds of the structures.
• Superposition of rigid fragments and determine a similarity score.
• Integrate the similarity score into the Optimal Assignment Kernel.

Andreas Jahn

6

Rigid Superposition

• Rule-based expert system identifies rigid scaffolds of the

structures.

• Calculate all pairwise similarity values.
• Calculate the optimal assignment of the fragments.

Molecule a Molecule b

Fragment #1 Fragment #2 Fragment #1 Fragment #2 Molecule a Similarity of Fragments Molecule b 19.262 6.599 F #2 8.676 23.662 F #1 F #2 F #1

23.662 19.262

Andreas Jahn

7

Rigid Superposition

• Superposition of the assigned fragments.
• Calculate a similarity score based on the overlap volume.
• Integrate information into the Optimal Assignment Kernel.

Andreas Jahn

8

OAKFLEX

• The flexibility space results from rotatable bonds.

All single bonds outside of a ring generate flexibility spaces.

• Flexibility space of the whole molecule is important.

For each atom the relative flexibility space has to be enumerated.

• Flexibility spaces have to be comparable.

Unique parameterisation of the space necessary.

Encode the neighbourhood flexibility space relative to an atom

Andreas Jahn

9

OAKFLEX

Flexibility space and the unique parameterisation

• Core atom acts as origin.
• Parameterisation of the flexibility relative to core atom.
• 1st order rotation is parameterised by d1 and r1.

Core atom Neighbour n1 Rotatable bond Neighbour n2

Andreas Jahn

10

OAKFLEX

Enumeration of the 1st order rotations

• Depth-limited search with limited depth of 2.
• Prune subtrees after rigid bond.

1 2 7 8 4 9 10 11 3 6 5

Andreas Jahn

11

OAKFLEX

Extension to the 2nd order rotation

• Unique parametrization by M1, M2, r2 and h.
• Additional flag necessary for case

differentiation.

Core atom

h

Andreas Jahn

12

OAKFLEX

Different cases of the 2nd order rotation

• Both cases are special cases of the 1st order rotation.

Only two parameters and the flag are necessary.

Core atom Core atom Atom n1

Andreas Jahn

13

OAKFLEX

Enumeration of the 2nd order rotations

• Depth-limited search with limited depth of 3.
• Prune subtrees after 2 rigid bonds.

Andreas Jahn

14

OAKFLEX

Similarity calculation of two flexibility spaces

• RBF kernel based on the parameters.
• Individual σ to adjust weight of the parameter

Core atom Core atom

d r d r

Parameters: Parameters:

        − + − −

=

r d

r r d d

e

σ σ 2 ) ( 2 ) (

2 2

Similarity

Andreas Jahn

15

OAKFLEX

Comparison of the flexibility spaces of two core atoms

• Atoms have list of flexibility spaces.
• But: Only one similarity value is needed.

Calculate similarity matrix and use

• ptimal assignment.

Atom a Atom b #1 #2 #1 #2 #3 RBF(#2,#3) RBF(#2,#2) RBF(#2,#1) #2 RBF(#1,#3) RBF(#1,#2) RBF(#1,#1) #1 #3 #2 #1 Similarity

) , ( ) , ( ) , ( ) , ( b b k a a k b a k b a k ←

Normalize similarity value

Andreas Jahn

16

OAKFLEX

Overview of the calculation steps

Atom A 1st R. Atom B 1st R. Atom A 2nd R. Atom B 2nd R. RBF-Kernel RBF-Kernel Matrix 1st R. Matrix 2nd R. Hungarian Method Hungarian Method Flex-Matrix Local atom similarity Matrix Hungarian Method Normalisation Kernel value

OAK

1st R. similarity matrix 2nd R. similarity matrix

Andreas Jahn

17

Results

• Methods evaluated on 8 QSAR datasets compiled by

Sutherland et al.

• Using ε-SVR to build models.
• Seeded 10-fold multirun
• Equal folds for both methods
• Comparison of the methods possible
• 100 multiruns generate 1000 MSE values.
• Each value is considered as a sample of a Gaussian distribution.

Paired Wilcoxon signed-rank test determines significant shifts of the mean.

• Hypotheses for the test:

source; J. Med. Chem., 2004, 47, 22, 5541-5554

FLEX FLEX

H H

OAK OAK 1 OAK OAK

: : µ µ µ µ > =

Andreas Jahn

18

Results

0.022 0.59 ± 0.24 0.42 ± 0.24 0.57 ± 0.25 0.47 ± 0.26 THRθ 0.149 0.66 ± 0.22 1.56 ± 1.00 0.64 ± 0.21 1.64 ± 0.96 THERη 0.089 0.60 ± 0.29 0.53 ± 0.37 0.59 ± 0.25 0.55 ± 0.33 GPBζ 0.001 0.73 ± 0.08 0.60 ± 0.17 0.71 ± 0.08 0.64 ± 0.19 DHFRε 0.001 0.53 ± 0.12 0.97 ± 0.27 0.51 ± 0.13 1.02 ± 0.31 COX2δ < 0.001 0.54 ± 0.17 0.58 ± 0.25 0.48 ± 0.19 0.67 ± 0.30 BZRγ 0.02 0.52 ± 0.19 0.80 ± 0.30 0.48 ± 0.21 0.86 ± 0.36 AchEβ 0.98 0.71 ± 0.13 1.52 ± 0.63 0.73 ± 0.13 1.48 ± 0.61 ACEα p-value Q2 MSE Q2 MSE Dataset OAKFLEX OAK

α Angiotensine Converting Enzyme, β Acetylcholinesterase, γ Benzodiazepine Receptor, δ Cyclooxygenase II, ε Dihydrofolate Reductase, ζ Glycogen Phosphorylase B, η Thermolysin, θ Thrombin

Andreas Jahn

19

Computation time

Comparison of the avg. runtime

• Overhead between 16% and 70%.
• Overhead correlates with the flexibility of the molecules.

1.53 1.70 1.46 1.36 1.37 1.16 1.26 1.49 Factor Dataset 51% 24% 36% 58% 66% 77% 71% 35% Ring atoms 18.0 12.3 6.9 8.2 8.5 5.6 8.5 7.9 Ø OAKFLEX (ms) 11.7 7.2 4.7 6.0 6.2 4.8 6.7 5.3 Ø OAK (ms) THR THERM GPB DHFR COX2 BZR AchE ACE

Andreas Jahn

20

Discussion

• Interpretation of kernel models are difficult.
• But: Visualization of the mappings disclose differences.

OAK OAKFLEX

Andreas Jahn

21

Conclusion

• Method incorporates molecular flexibility for similarity

calculations.

• Significant performance gain in 5 of 8 QSAR datasets.
• Type of encoding the flexibility not suitable for all datasets.

(ACE: Quality of the model decreased)

• Publication: Fechner, N.; Jahn, A.; Hinselmann, G.; Zell, A. Journal of

Chemical Information and Modeling, in revision.

Center for Bioinformatics Tübingen

Computer Science Department • Computer Architecture • Prof. Zell

Acknowledgement

I thank Nikolas Fechner, Georg Hinselmann and Andreas Zell.

Center for Bioinformatics Tübingen

Computer Science Department • Computer Architecture • Prof. Zell

Thank you for your attention

Andreas Jahn

24

OAKFLEX

Performance tuning

• Hungarian method:
• Performance problem due to high number of calculations.

Implementation of a greedy heuristic to reduce computational cost.

( )

( )

3

b a + Ο

Hungarian Heuristic Hungarian Heuristic 0,008% 0,561% Difference 2,18 2,709 2,091 2,079 Ø sum 2nd order rotations 1st order rotations
