Digital Video Systems

• S. Kasaei
• S. Kasaei

Room: CE 307 Department of Computer Engineering Sharif University of Technology E-Mail: skasaei@sharif.edu Webpage: http://sharif.edu/~skasaei

• Lab. Website: http://mehr.sharif.edu/~ipl

Acknowledgment

Most of the slides used in this course have been provided by:

• Prof. Yao Wang (Polytechnic University, Brooklyn) based on

the book: Video Processing & Communications written by: Yao Wang, Jom Ostermann, & Ya-Oin Zhang Prentice Hall, 1st edition, 2001, ISBN: 0130175471. [SUT Code: TK 5105 .2 .W36 2001].

Chapters 9 & 11

Video Coding using Motion Compensation

Kasaei 6

Outline

• Block-Based Hybrid Video Coding
• Overview of Block
• B

a sed Hybrid Video Coding

• Overlapped Block Motion Compensation
• Coding Mode Selection & Rate Control
• Loop Filtering
• Scalable Video Coding
• Motivation for Scalable Coding
• Basic Modes of Scalability
• Scalability in MPEG
• 2
• Fine Granularity Scalability in MPEG
• 4

Kasaei 7

Characteristics

• f Typical Videos

Frame t-1 Frame t

Adjacent frames are similar & changes are due to

• bject or camera motion.

Kasaei 8

Key Ideas in Video Compression

• Predicts a new frame from a previous frame & only

codes the prediction error.

• Prediction error cab be coded using the DCT method.
• Prediction errors have smaller energy than the
• riginal pixel values & can be coded with fewer bits.
• Those regions that cannot be predicted well will be

coded directly using DCT.

• Works on each macroblock (MB) (16x16 pixels)

independently to reduce the complexity.

• Motion compensation is done at the MB level.
• DCT coding of error is done at block level (8x8 pixels).

Kasaei 9

Different Coding Modes

Kasaei 10

Temporal Prediction

• No Motion Compensation:
• Works well in stationary regions.
• Uni
• d

irectional Motion Compensation:

• Does not work well for uncovered regions by object motion.
• Bi
• d

irectional Motion Compensation:

• Can better handle covered/uncovered regions.

$( , , ) ( , , ) f t m n f t m n = −1

$( , , ) ( , , ) f t m n f t m d n d

x y

= − − − 1 $( , , ) ( , , ) ( , , )

, , , ,

f t m n w f t m d n d w f t m d n d

b b x b y f f x f y

= − − − + + − − 1 1

Kasaei 11

Temporal Prediction

Although bi-directional prediction can

improve prediction accuracy & consequently coding efficiency, it incurs encoding delay & is typically not used in real-time applications.

H.261/H.263 use only uni-directional

prediction & a restricted bi-directional prediction (PB-mode).

MPEG employs both uni- & bi-directional

prediction.

Kasaei 12

Encoder Block Diagram

• f a Block-Based Hybrid Video Coder

[Hybrid: a combination of motion-compensated temporal prediction + transform coding.]

Kasaei 13

Decoder Block Diagram

Kasaei 14

Block-Based Hybrid Video Coding

• The encoder must emulate the decoder
• peration to deduce the same reconstructed

frame as the decoder.

• Frame types:
• When a frame is coded entirely in the intra-mode

I-frame.

• When a previous frame is used for prediction in the

inter-mode P-frame.

• When a weighted sum of previous & following frame

is used for prediction in the inter-mode B-frame.

• The mode information, MVs, & other side

information (picture format, block location, …) are coded using VLC.

Kasaei 15

Block-Based Video Partitions

Kasaei 16

MB Structure in 4:2:0 Color Format

4 of 8x8 Y blocks. 1 of 8x8 Cb blocks. 1 of 8x8 Cr blocks.

Kasaei 17

Block Matching Algorithm for Motion Estimation

Search Region

Frame t-1 (reference frame) Frame t (predicted frame)

MV

Kasaei 18

Macroblock Coding in I-Mode

DCT transform each 8x8 DCT block. Quantize DCT coefficients (with properly chosen quantization matrices). Zig

• z

ag order & run

• l

ength code quantized DCT coefficients.

Kasaei 19

Macroblock Coding in P-Mode

Estimate one MV for each macroblock (16x16). Depending on the motion compensation error, determine the coding mode (intra, inter

• w

ith

• n
• MC, inter
• with
• MC, etc.)

Original values (for intra

• mode) or motion compensation

errors (for inter

• mode) in each of the DCT blocks (8x8)

are DCT transformed, quantized, zig

• z

ag/alternate scanned, & run- length coded.

Kasaei 20

Macroblock Coding in B-Mode

• Same as for the P
• m
• de, except a macroblock can

be predicted from a previous frame, a following one,

• r both.

vb

v f

Kasaei 21

Overlapped Block Motion Compensation (OBMC)

• Conventional block motion compensation:
• One best matching block is found from a reference

frame.

• The current block is replaced by the best matching

block.

• OBMC:
• Each pixel in the current block is predicted by a

weighted average of several corresponding pixels in the reference frame.

• The corresponding pixels are determined by the

MVs of the current as well as adjacent MBs.

• The weights for each corresponding pixel depends
• n the expected accuracy of the associated MV.

Kasaei 22

OBMC using 4-Neighboring MBs

should be inversely proportional to the distance between x & the center of ([hm,1 & hm,4] > [hm,2 & hm,3])

weight assigned to estimated value based on MV (dm,k).

Kasaei 23

Optimal Weighting Design

• Convert to an optimization problem:
• Minimize:
• Subject to:
• Optimal weighting functions:

autocorrelation cross-correlation

Kasaei 24

How to Determine MVs with OBMC

• Option 1: using conventional BMA, minimize the

prediction error (MAD) within each MB independently.

• Option 2: minimize the prediction error

assuming OBMC:

Solve the MV for the current MB while

keeping the MVs for the neighboring MBs found in the previous iterations.

Kasaei 25

How to Determine MVs with OBMC

• Option 3: Using a weighted error criterion over

a larger block:

window function

Kasaei 26

Weighting Coefficients used in H.263

Kasaei 27

Window Function Corresponding to H.263 Weights for OBMC

Coding Parameter Selection

• Coding modes:
• Intra vs. inter, quantization parameter (QP) for

each MB, ME method ( different rates).

• Rate-distortion optimized selection, given a

target rate:

• Minimize the distortion, subject to the target rate

constraint:

simplified version:

The optimal mode is such that each MB works at the same R-D slope:

Kasaei 29

Rate Control

• Rate control:
• How to code a video so that the resulting bit

stream satisfies a target bit rate?

• For pleasant visual perception, video should have

a constant quality.

• But, the coding method necessarily yields variable

bit rate.

• So, at least the bit rate should be constant when

averaged over a short period.

• Rate control is also necessary when the video is to

be sent over a constant bit rate (CBR) channel.

• The fluctuation within the period can be smoothed

by a buffer at the encoder output.

Kasaei 30

Rate Control

Rate control accomplished steps:

• Step 1) Determine the target average bit rate at

the frame, GOB, & MB level, based on the current buffer fullness.

• Step 2) Satisfy frame level target rate by varying

frame rate (skip frames when necessary).

• Step 3) Satisfy GOB/MB level target rate by

varying the coding mode & QP at each MB.

(= Rate-distortion optimized mode selection.)

Kasaei 31

Loop Filtering

• Errors in previously reconstructed frames

accumulate over time with motion compensated temporal prediction.

• Error propagation leads to:
• Reduction of prediction accuracy.
• Increase of the bitrate needed for coding new

frames.

Kasaei 32

Loop Filtering

• Loop filtering:
• Filters the reference frame before using it for

prediction.

• Can be embedded in the motion compensation

loop.

• Half-pel motion compensation.
• OBMC.
• Loop filtering can significantly improve coding

efficiency.

• For theoretically optimal design of loop filters

see text.

Kasaei 33

Scalable Coding (Ch. 11)

• Scalability refers to the capability of recovering

physically meaningful image (or video) information by decoding only partial compressed bit stream.

• It is used when users try to access the same video

through different communication links (bandwidth scalability).

• A scalable stream can also offer adaptivity to

varying channel error characteristics & computing power at the receiving terminal.

• This includes: quality, spatial, temporal, &

frequency scalability.

Kasaei 34

Scalable Coding

• Motivation:
• Real networks are heterogeneous in rate.
• Streaming video from home (56 kbps) using

modem vs. corporate LAN (10-100 mbps).

• Scalable video coding:
• Ideal goal (embedded stream): creating a bit

stream that can be accessed at any rate.

• Practical video coder:
• layered coder: base-layer provides basic quality,

successive layers refine the quality incrementally.

• Coarse granularity: (typically known as layered

coder).

• Fine granularity (FGS).

Kasaei 35

Combined Spatial/Quality Scalability

Kasaei 36

Illustration of Scalable Coding

6.5 kbps 21.6 kbps 133.9 kbps 436.3 kbps Quality (SNR) Scalability Spatial Scalability

Kasaei 37

Quality Scalability by Multistage Quantization

coarse fine

Kasaei 38

Spatial/Temporal Scalability through Down/Up-Sampling

coarse fine

Kasaei 39

Scalability in MPEG-2

MPEG-2 is the earliest standard that offers

scalability tools.

Four types of scalability:

Data partition (frequency scalability). SNR scalability (quality scalability). Temporal scalability (frame-rate scalability). Spatial scalability (resolution scalability).

Kasaei 40

Fine Granularity Scalability in MPEG-4

MPEG-4 achieves fine granularity quality

scalability through bit-plane coding.

The DCT coefficients are represented

losslessly in binary bits.

The bit planes are coded successively, from

the most significant bit to the least.

The bit plane within each block is coded

using run-length coding.

Temporal scalability is accomplished by

combining I, B, & P-frames.

Spatial scalability is achieved by spatial

down/up-sampling.

Kasaei 41

Bit-Plane Coding

Kasaei 42

Bit-Plane Coding

Kasaei 43

Scalable Video Coding using Wavelet Transform

Wavelet-based image coding:

Full frame image transform (as opposed to

block-based transform).

Bit plane coding of the transform coefficients

can lead to embedded bit streams.

Embedded zero-tree wavelet (EZW)

SPIHT.

Kasaei 44

Scalable Video Coding using Wavelet Transforms

Wavelet-based video coding:

Temporal filtering with & without motion

compensation.

Can achieve temporal, spatial, & quality

scalability simultaneously.

MPEG4 uses DCT-based coding for natural

videos, but uses WT-based coding for still images & graphics.

Still an active research activity!

Kasaei 45

Homework 9

Reading assignment:

• Sec. 9.3, 11.1

Written assignment:

• Prob. 9.13, 11.3, 11.4

Computer assignment:

• Prob. 9.11, 9.12

Optional: 9.15

The End
