Improved Measurements of the β-Decay Response of Liquid Xenon with the LUX Detector

Jon Balajthy

UC Davis, Department of Physics September 12, 2019

1

LUX Detector

• 4850’ level (4300 m w.e.) of the Sanford Underground

Research Facility in Lead, SD.

• Water tank for neutron shield/ muon veto
• 2-Phase (liquid/gas) xenon TPC

○ Sensitive to light (S1) and charge (S2) ○ 3-D position reconstruction

• Total/ fiducial mass of 370 kg/ 118 kg
• Combined science runs:

○ Excluded scattering cross sections below 1.1×10−46 cm2 for a 50 GeV WIMP ○ Exposure of 3.35×104 kg days ○ ~1100 fiducial counts

2

Combined Energy Model

Charge and light work functions are averaged into a single W = 13.7 ±0.2 eV/quanta. Some fraction, r, of Ni will be converted to N* α is empirically constant for ER

3

Nr will be randomly distributed with mean value, Ni ·PR, and standard deviation, σR. ER energy can equivalently be written:

• r, in terms of measurables:

Which can be rewritten:

ER Yields

Energy and field dependence of the recombination process is characterized by the yields: Important note- Ly and Qy are assumed to be complementary:

4

ER Yields in Post-WS 14C and 3H Data

Begin with S1 and S2 measurements in a collection of energy and field bins for both 14C and

3H.

• Fields: 43, 53, 65, 80, 98, 120, 147, 180, 220, 269, 329, 403, 491 V/cm

○ The drift field in Run04 was highly non-uniform (arXiv:1709.00095)

• Energies: 1-145 keVee

○ The 14C spectrum overlapped with 131mXe above this range

Procedure: 1. Model detector resolution in post-WS 2. Develop model of yields and recombination fluctuations (σR) 3. Numerically de-smear the reconstructed energy, S1, and S2 spectra 4. Measure Nγ/Ne in each energy/field bin (can then be used to calculate LY, QY, and PR)

5

Post-WS Doke Plot

6

• Doke plot measured

from Kr-83 + Xe-131 at a collection of drift times

• Only two lines, but

smearing due to E-field gives very good measurement

• f g1, g2

Post-WS Doke Plot

7

Errors dominated by systematic variation Two-point Doke plots in each drift bin gives a measurement of how g1 and g2 change as a function of position Introduces subdominant- dominant errors on final Ly, Qy measurements

S2 Tails in Post-WS LUX

Thought to be caused by emission

• f electron trains

Modeled by adding area to the LibNEST S2 output ○ Area drawn from an exponential distribution with mean = b*S2 ○ Added only to a certain fraction, R, of MC events ○ b and R found by matching 37Ar and 131mXe MC to data

8

S2 Tails in Post-WS LUX

9

The addition of the S2 to libNEST significantly improves the agreement with both 3H and

14C beta spectra

σR should be proportional to Ni

1/2 for a binomial process.

σR has been instead observed to be roughly proportional to ~Ni In LUX post-WS carbon-14 data, we add a Gaussian adjustment to the Ni dependence Where:

Recombination Fluctuations

10

Comparison to LUX WS2013

The adjusted σR model better reproduces the substructure of the LUX WS2013 measurements When Ne ≈ Nγ, the new model reproduces the WS2013 result

11

arXiv:1512.03133

De-Smearing a Beta Spectrum

• Continuous spectra will be smeared by

finite detector resolution.

• Similar effect is found in 2-D Ne, Nγ space
• Can be accounted for analytically by

integration

• In Post-WS, this is unwieldy due to S2 tails.

Instead we desmear numerically ○ Calculate ratio of true to measured Erec in MC & apply correction to data ○ Calculate ratio of true to measured Ne, Nγ in MC, and apply correction to data

12

The average Etrue in the 80 keV bin is 79.53 ±0.009 keV

Results- Snapshot

Results are reported in terms of photon-electron ratio Very low statistical error (shown in black) Systematic error is taken as quadrature sum of:

• g1/g2 uncertainty
• Absolute magnitude of

smearing correction

13

Post-WS Qy Compared to WS2013

We construct an empirical model to help compare LUX Post-WS to previous measurements. All the datasets considered agree with the model to about 1-σ. The QY results are consistent with WS2013 measurements at 180 and 100 V/cm, except...

14

arXiv:1512.03133 arXiv:1709.00800 arXiv:1610.02076 arXiv:1705.08958

Post-WS Qy Compared to WS2013

… Run03 tritium has distinct kink near endpoint This is due to mistake in WS2013 de-smearing. Recombination fluctuations are double counted- they are corrected for in both reconstructed energy and individual quanta.

15

Wrong

Beta vs EC

Also… 127Xe EC L-shell is consistent within systematic error bars, but just barely As per Dylan Temples’ talk on Monday- this discrepancy appears to be physical

16

Beta vs Photo-absorption

131mXe and 83mKr lines also show discrepancy with beta yields

• Photoabsorption events give higher light yield
• 83mKr is composite, and has even more intricacies

17

Compared to World Data

18

Compared to World Data

19

Good agreement with 3H data from Xenon100

Compared to World Data

20

Systematically below the Compton scattering data from neriX, Shanghai, and E. Dahl

Could point to physical difference in Compton/ beta yields?

Compared to World Data

21

Systematically below

37Ar EC data from

PIXeY.

Summary

22

• Developed model for S2 tails in LUX Post-WS data
• Added Gaussian adjustment to σR model
• Numerically de-smeared S1 and S2 spectra
• Measured LY, QY, and PR as functions of energy and electric field

○ Energy range from 1-145 keV ○ Field range from 43-491 V/cm

• Compared results to existing data

○ Very consistent with LUX WS2013 3H data ○ Consistent with WS2013 127Xe K- and M-shell ○ Hints of discrepancy with 127Xe L-shell ○ Agrees with 3H data from Xenon100 ○ Disagrees with all available Compton data

Extra Slides

23

Energy Deposition in LXe

24

An energetic particle interacting with a xenon nucleus will create:

• Excited xenon atoms (Xe*)
• Electron-ion pairs (e-, Xe+)
• Heat (not detected)

The excitons and ions form dimers with ground state atoms (Xe2*, Xe2

+).

After the initial partitioning, there is a recombination period (~50 ns) where:

e-+Xe2

+→ Xe**+Xe → Xe*+Xe + heat

The net result of this is that an ion is converted to an exciton.

ER Yields

25

For ER, PR, LY, and QY can all be written in terms of the Nγ/Ne ratio only:

Post-Run04 Injection Campaign

Following the primary WIMP-search run (WS2014-16), a series of NR and ER calibrations were performed.

• D-D
• 83Kr
• 131mXe
• 3H
• 14C
• 222Rn
• 37Ar

26

Beta Model from Post-Run04 14C and 3H Data

Fully empirical model of QY and σR

• QY is fit to the sum of two

asymmetric sigmoids

• The m1 and m7 parameters are

allowed to vary with field

• σR is the Gaussian adjusted

linear model presented in slide 6 Compton data from neriX is in tension

• n the 1-2 sigma level

27 Non-LUX datasets used to constrain model: Low energy: Boulton et al., 2017 High energy: Doke et al., 2002 0-field: Baudis et al., 2013 Aprile et al., 2012 High-field: Akimov et al., 2014

Results- 14C

28

Results- 3H

29
