SLIDE 1
github.com/zzenonn linkedin.com/in/zzenonn
SECURITY ENGINEER
t h s
Implementing Security and Incident Response with the ELB Miguel - - PowerPoint PPT Presentation
Implementing Security and Incident Response with the ELB Miguel - - PowerPoint PPT Presentation
Implementing Security and Incident Response with the ELB Miguel Zenon Nicanor L. Saavedra SECURITY ENGINEER github.com/zzenonn linkedin.com/in/zzenonn t h s Module Define Elastic Load Balancing Overview Understand different ELB security
SLIDE 2
SLIDE 3
Load Balancers
SLIDE 4
Distributes incoming traffic across instances Performs health checks
- n instances
Scales without disrupting
- verall flow of requests
SLIDE 5
Security Benefits of an ELB
Single point of contact and first line of defense Authentication management End-to-end encryption using TLS for HTTPS
SLIDE 6
Types of Load Balancers
Application Load Balancer Network Load Balancer Classic Load Balancer
SLIDE 7
Types of Load Balancers
Application Load Balancer Network Load Balancer
SLIDE 8
Advanced load balancing of HTTP and HTTPS traffic Operates at the request level (Layer 7) Load balancing of TCP, TLS, and UDP traffic Operates at the network level (Layer 4)
Application vs. Network Load Balancer
SLIDE 9
Comparison of Load Balancers
Network Transport Session Presentation Application
Ne Netw twork k Load ad Bal alan ancer Ap Applicati tion Load ad Bal alan ancer
- Operates at Layer 4
- Load balancing of TCP packets
- For high-performance applications
- Integrates with AWS Shield Advanced
- Operates at Layer 7
- Routes traffic based on content of the requests
- Provides user authentication
- Integrates with AWS Certificate Manager, AWS
WAF, and AWS Shield Advanced
VS VS.
SLIDE 10
Public vs. Private ELB
We Webtier Se Securit ity Group Ap Apptier Se Securit ity Group We Webtier EL ELB B Security ty Group Da Datatier Se Securit ity Group Ap Apptier EL ELB B Security ty Group Inbound Rule Allow TCP Port 443 Source: 0.0.0.0/0 (Any) Inbound Rule Allow TCP Port 80 Source: Webtier ELB Security Group Inbound Rule Allow TCP Port 8088 Source: Webtier Security Group Inbound Rule Allow TCP Port 8088 Source: Apptier ELB Security Group Inbound Rule Allow TCP Port 3306 Source: Apptier Security Group
Pu Public subnet Pr Private subnet
Av Availability Zone 2 Av Availability Zone 1 Av Availability Zone 2 Av Availability Zone 1
SLIDE 11
ELB TLS Options
EC2 Security Group EC2 Security Group EC2 Security Group Elastic Load Balancing (no termination)
HTTPS HTTPS HTTPS HTTPS
Elastic Load Balancing (Terminate TLS & Re-negotiate) Elastic Load Balancing
Encrypted Unencrypted Encrypted Encrypted Encrypted Encrypted
TLS Termination TLS Termination & Renegotiate TLS Pass Through
SLIDE 12
Globomantics’ Needs
SLIDE 13
ALB: Path-based Routing
globomantics.com Application Load Balancer
Availability Zone A Availability Zone B /posts /profile /msgs Pr Profile Ms Msgs Po Posts Pr Profile Ms Msgs Po Posts
SLIDE 14
What about authentication?
SLIDE 15
ALB: Authentication
HTTPS Listener
- 1. Unauthenticated request
- 2. Redirect to Open ID Provider
- 4. Authenticated Session
- 3. Authenticate User
OpenID Provider Action Authenticate-
- idc
Forward Identity Headers
Target Application
Action
Application Load Balancer
SLIDE 16
Globomantics’ Needs
SLIDE 17
NLB: UDP and Static IP
VO VOIP VO VOIP VO VOIP 5600/UDP 5600/UDP 5 6 / U D P
SLIDE 18
Summary of Load Balancers
Application Load Balancer Network Load Balancer Classic Load Balancer
Protocols Platforms Logging Health checks TLS offloading Path-based routing Static/elastic IPs User authentication HTTP, HTTPS TCP, UDP, TLS TCP, TLS/SSL, HTTP, HTTPS VPC VPC EC2-Classic, VPC
SLIDE 19
Mitigating DDoS Attacks
SLIDE 20
An explicit attempt by an attacker to prevent legitimate use of a service
Denial of Service Attack
SLIDE 21
Many machines performing DoS actions
Distributed Denial of Service
SLIDE 22
Distributed Denial of Service
Network Transport Session Presentation Application
La Layer 3 & 4 Attacks La Layer 7 7 Attacks
- UDP Reflection
- SYN Flood
- ICMP Flood
- HTTP Flood
- Slow loris
SLIDE 23
s h s
Minimize the attack surface Safeguard exposed resources Be ready to scale and absorb the attack
DDoS Mitigation Strategies
SLIDE 24
Sample Architecture
Availability Zone B Public subnet Private subnet Protected subnet RDS Standby DB instance Availability Zone A Public subnet Private subnet Protected subnet NAT Gateway
RDS Master DB instance
ELB Internet Gateway Routers and route tables Subnets
VPC
172.16.0.0 172.16.1.0 172.16.2.0
NAT Gateway Security Groups
App Servers App Servers Web Servers Web Servers
SLIDE 25
Sample Architecture
Availability Zone B Public subnet Private subnet Protected subnet RDS Standby DB instance Availability Zone A Public subnet Private subnet Protected subnet NAT Gateway
RDS Master DB instance
ELB Internet Gateway Routers and route tables Subnets
VPC
172.16.0.0 172.16.1.0 172.16.2.0
NAT Gateway Security Groups
App Servers App Servers Web Servers Web Servers
SLIDE 26
Sample Architecture
Availability Zone B Public subnet Private subnet Protected subnet App Servers RDS Standby DB instance Availability Zone A Public subnet Private subnet Protected subnet App Servers NAT Gateway
RDS Master DB instance
ELB
Web Servers Web Servers
Internet Gateway Routers and route tables Subnets
VPC
172.16.0.0 172.16.1.0 172.16.2.0
Auto Scaling Auto Scaling
NAT Gateway Security Groups
SLIDE 27
“Isn’t scaling expensive?”
SLIDE 28
AWS Shield AWS Shield Advanced
AWS DDoS Mitigation
SLIDE 29
Always on (Free) Automatic Layer 3 and 4 Protection Integrates with Cloudfront All Shield features ELB+EC2 Protection Cost Protection 24/7 Response Team Comes with free WAF
AWS DDoS Mitigation
SLIDE 30
Responding to Incidents
SLIDE 31
Incident and Globomantics
Hacker Customer Engineer
SLIDE 32
Demo
t h s
Respond to an incident on an EC2 instance Document an instance for quarantine using tags Isolate an incident for further investigation All using the CLI
SLIDE 33
t h s
Load balancers
- Security features
- Design patterns
