4/15/05 1 of 37

Implementing Optimized Collective Communication Routines on the IBM BlueGene/L Supercomputer

CS 425 term project By Sam Miller samm@scl.ameslab.gov April, 18, 2005

4/15/05 2 of 37

Outline

• What is BlueGene/L? (5 slides)
• Hardware (3 slides)
• Communication Networks (2 slides)
• Software (2 slides)
• MPI and MPICH (1 slide)
• Collective Algorithms (5 slides)
• Better Collective Algorithms! (12 slides)
• Performance
• Conclusion

4/15/05 3 of 37

Abbreviations Today

• BGL = BlueGene/L
• CNK = Compute Node Kernel
• MPI = Message Passing Interface
• MPICH2 = MPICH 2.0 from Argonne Labs
• ASIC = Application Specific Integrated Circuit
• ALU = Arithmetic Logic Unit
• IBM = International Biscuit Makers (duh)

4/15/05 4 of 37

What is BGL 1/2

• Massively parallel distributed memory cluster of

embedded processors

• 65,536 nodes! 131,072 processors!
• Low power requirements
• Relatively small, compared to predecessors
• Half system installed at LLNL
• Other systems going online too

4/15/05 5 of 37

What is BGL 2/2

• BlueGene/L at LLNL (360 Tflops)

– 2,500 square feet, half a tennis court

• Earth Simulator (40 Tflops)

– 35,000 square feet, requires an entire building

4/15/05 6 of 37

4/15/05 7 of 37

4/15/05 8 of 37

4/15/05 9 of 37

Hardware 1/3

• CPU is PowerPC 440

– Designed for embedded applications – Low power, low clock frequency (700 MHz) – 32 bit :-(

• FPU is custom 64-bit

– Each PPC 440 core has two of these – The two FPUs operate in parallel – @ 700MHz this is 2.8 Gflops per PPC 440 core

4/15/05 10 of 37

Hardware 2/3

• BGL ASIC

– Two PPC 440 cores, four FPUs – L1, L2, L3 caches – DDR memory controller – Logic for 5 separate communications networks – This forms one compute node

4/15/05 11 of 37

Hardware 3/3

• To build the entire 65,536 node system

– Two ASICs with 256 or 512 MB DDR RAM form a compute card – Sixteen compute cards form a node board – Sixteen node boards form a midplane – Two midplanes form a rack – Sixty four racks brings us to: – 2x16x16x2x64 = 65,536!

4/15/05 12 of 37

4/15/05 13 of 37

Communication Networks 1/2

• Five different networks

– 3D torus

• Primary for MPI library

– Global tree

• Used for collectives on MPI_COMM_WORLD
• Used by compute nodes to communicate with I/O nodes

– Global interrupt

• 1.5 usec latency over entire 65k node system!

– JTAG

• Used for node bootup and servicing

– Gigabit Ethernet

• Used by I/O nodes

4/15/05 14 of 37

Communication Networks 2/2

• Torus

– 6 neighbors have bi-directional links at 154 MB/sec – Guarantees reliable, deadlock free delivery – Chosen due to high bandwidth nearest neighbor connectivity – Used in prior supercomputers, such as Cray T3E

4/15/05 15 of 37

Software 1/2

• Compute node runs stripped down Linux called

CNK

– Two threads, 1 per CPU – No context switching, no VM – Standard glibc interface, easy to port – 5000 lines of C++

• I/O nodes run standard PPC Linux

– They have disk access – Run a daemon called console I/O daemon (ciod)

4/15/05 16 of 37

Software 2/2

• Network software has 3 layers

– Topmost is MPI Library – Middle is Message Layer

• Allows transmission of arbitrary buffer sizes

– Bottom is Packet layer

• Very simple
• Stateless interface to torus, tree, and GI hardware
• Facilitates sending & receiving packets

4/15/05 17 of 37

MPICH

• Developed by Argonne National Labs
• Open source, freely available, standards

compliant MPI implementation

• Used by many vendors
• Chosen by IBM due to use of Abstract

Device Interface (ADI) and design for scalability

4/15/05 18 of 37

Collective Algorithms 1/5

• Collectives can be implemented with basic send

and receives

– Better algorithms exist

• Default MPICH2 collectives perform poor on

BGL

– Assume crossbar network, poor node mapping – Point-to-point messages incur high overhead – No knowledge of network specific features

4/15/05 19 of 37

Collective Algorithms 2/5

• Optimization is tricky

– Message size and communicator shape are deciding factors – Large messages == optimize bandwidth – Short messages == optimize latency

• I will not talk about short message collectives further today
• If optimized algorithm isn’t available, BGL falls

back on default MPICH2

– It will work because point-to-point messages work – Performance will suck however

4/15/05 20 of 37

Collective Algorithms 3/5

• Conditions for selecting optimized collective

algorithm are made locally

– What is wrong with this?

• Example:

char buf[100], buf2[20000]; if (rank == 0) MPI_Bcast(buf, 100, …); else MPI_Bcast(buf2, 20000, …);

– Not legal according to MPI standard, but… – What if one node uses the optimized algorithm and the

• thers use the MPICH2 algorithm?
• Deadlock - or worse

4/15/05 21 of 37

Collective Algorithms 4/5

• Solution to previous problem:

– Make optimization decisions globally – This incurs a slight latency hit – Thus, only used when offsetting increases in bandwidth are important: Ex: long message collectives

4/15/05 22 of 37

Collective Algorithms 5/5

• Remainder of slides

– MPI_Bcast – MPI_Reduce, MPI_Allreduce – MPI_Alltoall, MPI_Alltoallv

• Using both the tree and torus networks

– Tree operates only on MPI_COMM_WORLD

• Has a built in ALU, but only fixed point :-(

– Torus has deposit bit feature, requires rectangular communicator shape (for most algorithms)

4/15/05 23 of 37

Broadcast 1/3

• MPICH2

– Binomial tree for short messages – Scatter then Allgather for large messages – Perform poor on BGL due to high CPU overhead and lack of topology awareness

• Torus

– Uses deposit bit feature – For n-dimension mesh, 1/n of message is sent in each direction concurrently

• Tree

– Does not use ALU

4/15/05 24 of 37

Broadcast 2/3

• Red lines represent one spanning tree of

half the message

• Blue lines represent another spanning tree
• f the other message half

4/15/05 25 of 37

Broadcast 3/3

4/15/05 26 of 37

Reduce & Allreduce 1/4

• Reduce essentially a reverse broadcast
• Allreduce is a reduce followed by broadcast
• Torus

– Can’t use deposit bit feature – CPU bound, bandwidth is poor – Solution: Hamiltonian path, huge latency penalty, but great bandwidth

• Tree

– Natural choice for reduction using integers! – Floating point performance is bad

4/15/05 27 of 37

Reduce & Allreduce 2/4

• Hamiltonian path for 4x4x4 cube

4/15/05 28 of 37

Reduce & Allreduce 3/4

4/15/05 29 of 37

Reduce & Allreduce 4/4

4/15/05 30 of 37

Alltoall and Alltoallv 1/5

• MPICH2 has 4 algorithms

– Yes 4 separate ones – BGL performace is bad due to network hot spots and CPU overhead

• Torus

– No communicator size restriction! – Does not use deposit bit feature

• Tree

– No alltoall tree algorithm, it would not make sense

4/15/05 31 of 37

Alltoall and Alltoallv 2/5

• BGL Optimized torus algorithm

– Uses randomized packet injection – Each node creates a destination list – Each node has same seed value, different offset

• Bad memory performance?

– Yes! – Torus payload is 240 bytes (8 cache lines) – Multiple packets in adjacent cache lines to each destination are injected before advancing

• Measurements showed 2 packets to be optimal

4/15/05 32 of 37

Alltoall and Alltoallv 3/5

4/15/05 33 of 37

Alltoall and Alltoallv 4/5

4/15/05 34 of 37

Alltoall and Alltoallv 5/5

4/15/05 35 of 37

Conclusion

• Optimized collectives on BGL off to a good start

– Superior performance than MPICH2 – Exploit knowledge about network features – Avoid performance penalties like memory copies and network hot spots

• Much work remains

– Short message collectives – Non-rectangular communicators for the torus network – Tree collectives using communicators other than MPI_COMM_WORLD – Other collectives: scatter, gather, etc.

4/15/05 36 of 37

Questions?
