compilertree.com Implementing Data Layout Optimizations Implementing Data Layout Optimizations in the LLVM Framework in the LLVM Framework Prashantha NR (Speaker) CompilerTree Technologies CompilerTree Technologies

slide-1
SLIDE 1

compilertree.com

Implementing Data Layout Optimizations Implementing Data Layout Optimizations in the LLVM Framework in the LLVM Framework

Prashantha NR (Speaker) CompilerTree Technologies CompilerTree Technologies

http://in.linkedin.com/in/mynrp

Vikram TV CompilerTree Technologies

http://in.linkedin.com/in/tvvikram

Vaivaswatha N CompilerTree Technologies

http://in.linkedin.com/in/vaivaswatha

slide-2
SLIDE 2

Abstract

Speed difference between processor and memory is

increasing everyday increasing everyday

Array/structure access patterns are modified for better

cache behaviour

We discuss the implementation of a few data layout

modification optimizations in the LLVM framework

All

are Module Passes and implemented under lib/Transforms/DLO (currently not in llvm repo)

CompilerTree DLO 2

lib/Transforms/DLO (currently not in llvm repo)

slide-3
SLIDE 3

Outline

Structure

peeling, structure splitting and structure field reordering structure field reordering

Struct-array copy Instance interleaving Array remapping CompilerTree DLO 3

slide-4
SLIDE 4

Outline

Structure peeling, structure splitting and

structure field reordering structure field reordering

Struct-array copy Instance interleaving Array remapping CompilerTree DLO 4

slide-5
SLIDE 5

Structure Peeling: Motivation

struct S { int A; int B;

A,C – Hot fields

int B; int C; };

A,C – Hot fields B – Cold field

CompilerTree DLO 5

slide-6
SLIDE 6

Structure Peeling: Motivation

struct S { int A; int B;

A,C – Hot fields

int B; int C; };

Peeled structures:

A,C – Hot fields B – Cold field

CompilerTree DLO 6

struct S.Hot { int A; int C; }; struct S.Cold { int B; };

slide-7
SLIDE 7

Structure Splitting: Motivation

struct S { int A;

A – Hot B – Cold

int A; int B; struct S *C; };

B – Cold C – Pointer to struct S Presence of pointer to same type makes peeling invalid

CompilerTree DLO 7

slide-8
SLIDE 8

Structure Splitting: Motivation

struct S { int A; int B;

A – Hot B – Cold

int B; struct S *C; }; struct S {

Split structures:

B – Cold C – Pointer to struct S

CompilerTree DLO 8

struct S { int A; struct S *C; struct S.Cold *ColdPtr; }; struct S.Cold { int B; };

slide-9
SLIDE 9

Structure Peeling/Splitting

Implementation in LLVM

Done in 5 phases:

Done in 5 phases:

− Profile structure accesses − Legality − Reordering the fields − Create new structure types − Replace old structure accesses with new accesses

CompilerTree DLO 9

− Replace old structure accesses with new accesses

slide-10
SLIDE 10

Structure Peeling/Splitting

Implementation in LLVM

Profile structure accesses

− Currently static profile is used − Currently static profile is used − Each GetElementPtr of struct type is analyzed − Static profile count is maintained for each field of each struct − LoopInfo is used to get more accurate counts − This data is used in later phases to reorder the fields, decide

whether to peel, split the structure

CompilerTree DLO 10

slide-11
SLIDE 11

Structure Peeling/Splitting

Implementation in LLVM

Legality

− Not all structures can be peeled or split! − Not all structures can be peeled or split! − Cast to/from a given struct type − Escaped types / address of individual fields taken − Parameter types − Nested structures − Few others

CompilerTree DLO 11

Few others

slide-12
SLIDE 12

Structure Peeling/Splitting

Implementation in LLVM

Reordering the fields Reordering the fields

− Based on hotness of the fields − Based on affinity of the fields − Phase ordering problem

CompilerTree DLO 12

slide-13
SLIDE 13

Structure Peeling/Splitting

Implementation in LLVM

  • Creating new structure types

− Decide to peel or split the structure − Decide to peel or split the structure − Split the structure if:

any of the fields of the StructType is a self referring pointer or this StructType is a pointer in some other Struct Type

− Otherwise peel − Don't split or peel if:

there is only one field in the structure or

CompilerTree DLO 13

there is only one field in the structure or fields already show good affinity or just reordering the fields yield good profitability

slide-14
SLIDE 14

Structure Peeling/Splitting

Implementation in LLVM

  • Replace old structure accesses with new accesses:

− Replace each getelementptr that computes address to a field of

the old struct, with another one that computes the new address of that field.

− Cold

field access

  • f

a split structure need an additional getelementptr followed by a Load of the pointer in hot field that points to cold structure

CompilerTree DLO 14

slide-15
SLIDE 15

Outline

Structure

peeling, structure splitting and structure field reordering structure field reordering

Struct-array copy Instance interleaving Array remapping CompilerTree DLO 15

slide-16
SLIDE 16

Struct Array Copy: Motivation

After Structure to Array copy: Original access of structure field: for (i = 0; i < n; i++) { temp[i] = AoS[i].x; } for (i = 0; i < n; i++) { for (j = 0; j < n; j++) { sum = sum + temp[j]; } } struct S { . int x; . . } AoS[10000]; for (i = 0; i < n; i++) { for (j = 0; j < n; j++) { sum = sum + AoS[j].x;

CompilerTree DLO 16

sum = sum + AoS[j].x; } }

slide-17
SLIDE 17

Struct Array Copy: Motivation

We consider only Read-only loops. However, loops with We consider only Read-only loops. However, loops with

writes can also be chosen if profitable

Profitable when the access patterns of structure fields vary

across the program – modifying the structure itself is not beneficial

CompilerTree DLO 17

slide-18
SLIDE 18

Struct Array Copy

Implementation in LLVM

  • Module Pass
  • Analysis:

−

Identify Array of Structures

−

Identify loops with read-only struct field accesses

−

Legality

Trip count of the loop must be known before entering the loop Type casts, escaped types, etc (as before)

CompilerTree DLO 18

slide-19
SLIDE 19

Struct Array Copy

Implementation in LLVM

  • Transformation

− Allocate a temporary array of size equal to loop’s trip count and − Allocate a temporary array of size equal to loop’s trip count and

structure field type

− Create a loop before the read-only loop − Add instructions to initialize temporary array with specific field of

AoS

− Replace the AoS access in the read-only array with temporary

array accesses. Index is translated if necessary Free the temporary array after the loop

CompilerTree DLO 19

− Free the temporary array after the loop

slide-20
SLIDE 20

Outline

Structure

peeling, structure splitting and structure field reordering structure field reordering

Struct-array copy Instance interleaving Array remapping CompilerTree DLO 20

slide-21
SLIDE 21

Instance Interleaving: Motivation

for (i = 0; i < N; i++) { struct S { int a; int b; int c; int d; } A[N]; for (i = 0; i < N; i++) { for (j = 0; j < N; j++) A[j].a /= 2; for (j = 10; j < (N/2); j++) A[j].b *= 5; for (j = 0; j < (N/4); j++) A[j].c *= 76; for (j = 0; j < N; j++) A[j].d /= 5;

CompilerTree DLO 21

A[j].d /= 5; }

slide-22
SLIDE 22

Instance Interleaving: Motivation

struct S { int a; for (i = 0; i < N; i++) { for (j = 0; j < N; j++) A[j].a /= 2; int a; int b; int c; int d; } A[N]; A[j].a /= 2; a[j] for (j = 10; j < (N/2); j++) A[j].b *= 5; b[j] for (j = 0; j < (N/4); j++) A[j].c *= 76; c[j] for (j = 0; j < N; j++) int a[N]; int b[N]; int c[N];

CompilerTree DLO 22

for (j = 0; j < N; j++) A[j].d /= 5; d[j] } int c[N]; int d[N];

Array of structures to structure of arrays

slide-23
SLIDE 23

Module Pass Identify arrays of structures whose different fields are accessed

Instance Interleaving

Implementation in LLVM

Identify arrays of structures whose different fields are accessed

in different loops

Identify the “length” of the array of structures Legality (as before) Create new arrays of size “length” and corresponding field types Modify getelementptr computations to reflect indexing a specific

CompilerTree DLO 23

Modify getelementptr computations to reflect indexing a specific array, instead of an array of structures

slide-24
SLIDE 24

Outline

Structure

peeling, structure splitting and structure field reordering structure field reordering

Struct-array copy Instance interleaving Array remapping CompilerTree DLO 24

slide-25
SLIDE 25

Array Remapping: Motivation

Non-contiguous

array accesses can be rearranged

Non-contiguous

array accesses can be rearranged (remapped) to make them contiguous

Array

remapping is conceptually same as instance interleaving but happens with arrays

CompilerTree DLO 25

slide-26
SLIDE 26

1 2 3 4 5 6 7

for (i = 5; i < 4004; i = i + 4) { A[i + 6]

Iter 1

GroupSize

Array Remapping: Motivation

8 9 10 11 12 11 14 15 16 17 18 19 . . . . . . . .

A[i + 6] A[i + 1] A[i + 0] A[i - 5] }

Iter 1 Iter 2 Iter 3

Number of groups

  • The locality here is very poor

−

No locality can be found in a single iteration

CompilerTree DLO 26

. . . . . . . Iter N

No locality can be found in a single iteration

−

No locality can be found across iterations (think of large strides/less cache line size)

  • What if we remap this array?
slide-27
SLIDE 27

Array Remapping: Motivation

1 2 3 4 5 6 7 Iter 1

GroupSize

0(0) 4(1) 8(2) 12 16 . . . . 1(1000) 5(1001) 9(1002) 11 17 . . . 2(2000) 6(2001) 10(2002) 14 18 . . . . Iter 1 Iter 2 Iter 3 Iter 1000

  • Remap all accesses of A[i] as A[remap(i)]
  • Fetching current iteration data also brings in the next iteration
  • data. That is, we prefetch data of future “n” iterations in the

current iteration 8 9 10 11 12 11 14 15 16 17 18 19 . . . . . . . . Iter 1 Iter 2 Iter 3

Number of groups

2(2000) 6(2001) 10(2002) 14 18 . . . . 3(3000) 7(3001) 11(3002) 15 19 . . . .

CompilerTree DLO 27

current iteration . . . . . . . Iter N

remap(i) = i % GroupSize * NumberOfGroups + i / GroupSize

slide-28
SLIDE 28

Array Remapping

Implementation in LLVM

Get Loop Information (IndVar, Stride, TripCount) Identify array remapping candidates

−

Get array access pattern by analyzing constants

  • GEP accesses are checked for A[i + const] type accesses

−

Identify groups

  • Remainder = constant % stride
  • Groups of constants which have same remainder are identified

CompilerTree DLO 28

  • All groups must have equal number of remainders
slide-29
SLIDE 29

Array Remapping

Implementation in LLVM

  • Compute new array-access locations

−

Insert new instructions in the entire module for every access of array A i.e. A[i] becomes A[remap(i)] A[remap(i)]

  • remap(i) = i % GroupSize * NumberOfGroups + i / GroupSize
  • (GroupSize = Stride, NumberOfGroups = TripCount)

−

%1 = add nsw i64 %indvars.iv, 19 %arrayidx = getelementptr [100 x i32]* @a, i64 0, i64 %1 becomes %1 = add nsw i64 %indvars.iv, 19 %IterNum = urem i64 %1, %GroupSizeLD

CompilerTree DLO 29

%IterNum = urem i64 %1, %GroupSizeLD %Iter = mul i64 %IterNum, %NumGroupsLD %IterOffset = udiv i64 %1, %GroupSizeLD %NewIndex = add i64 %Iter, %IterOffset %arrayidx = getelementptr [100 x i32]* @a, i64 0, i64 %NewIndex

slide-30
SLIDE 30

Experimental Observations

Following benchmarks show significant gains with data layout

  • ptimizations

− libquantum with struct splitting/peeling − mcf with array copy/instance interleaving − lbm with array remapping

CompilerTree DLO 30

slide-31
SLIDE 31

Conclusion

Different data layout optimizations are closely related Going forward ...

− Framework for combined legality, profitability − Make Data layout optimizations work closely with Loop

Optimizer (much harder)

CompilerTree DLO 31

slide-32
SLIDE 32

Thank You Thank You Questions?

CompilerTree DLO 32

slide-33
SLIDE 33

References

D.C.

Suresh et. Al. Multi-core scalability impacting compiler optimizations - Springer COMPUTER SCIENCE - compiler optimizations - Springer COMPUTER SCIENCE - RESEARCH AND DEVELOPMENT Volume 25, Numbers 1-2 (2010), 15-24,

G Chakrabarti et. al. Structure Layout Optimizations in the

Open64 Compiler

Michael Lai – Extensions to Structure Layout Optimizations

in the Open64 compiler

CompilerTree DLO 33

in the Open64 compiler

Region Based Structure Layout Optimization by Selective

Data Copying by Sandya S. Mannarswamy, R. Govindarajan and Rishi Surendran
