Implementation of Underwater Channel Emulator (1804)

Aaron DeMaio, Michael Stratton, and Nicholas Gorbenko Advisor: Dr. Peter WIllett Sponsor: The MITRE Corporation

slide-2
SLIDE 2

Overview

  • Channel Emulation
  • Underwater Effects

○ Path losses due to spreading and absorption ○ Ambient Noise ○ Multipath Reverberation ○ Doppler Spreading

  • Design

○ Basic Design ○ Setup

  • Data Accuracy

○ Impulse Response

  • Results so far
  • Timeline
slide-3
SLIDE 3

Channel Emulation

  • Software Defined Radio System

○ Models time-varying underwater channel and effects in software and hardware ○ Design Platform ■ Based in C++ ■ Uses 3 USRP X310 Software Defined Radios ○ Benefits ■ Cheaper ■ More reliable ■ More closely models underwater channels ■ Modular Figure 1: USRP X310 Software Defined Radio

slide-4
SLIDE 4

Main Underwater Effects

  • Four main problems with underwater channel modeling

○ Path losses due to spreading and absorption ○ Ambient noise ○ Reverberation due to multipath ○ Doppler spreading Figure 2: Multipath reverberation

slide-5
SLIDE 5

Path Losses due to spreading and absorption

  • Path losses modeled using Thorp’s equation
  • The equation dictates that the attenuation is related to the frequency of the signal
  • Mostly used to obtain the transfer function
slide-6
SLIDE 6

Multipath and Doppler Spreading

  • Multipath is modeled with tapped delay line
  • The tapped delay line also models doppler spreading due to the delays
  • Input signal is modulated with a delay and coefficient and the output is a sum of

these signals

  • Each sample is input through this delay line to simulate each signal having many

copies that arrive at different times

slide-7
SLIDE 7

Basic Design

  • One USRP X310 to act as a transmitter
  • A second USRP X310 as a transceiver connected to another laptop
  • Laptop will process the received signals and add channel effects
  • Final USRP X310 will receive signal
slide-8
SLIDE 8

The Setup

*CE = Channel emulator

slide-9
SLIDE 9

Basic Design (cont.)

  • Creating the channel

○ Code in C++ to model the channel effects ■ Ambient noise modeled with Gaussian Curve ■ Path Losses modeled with spherical spreading ■ Reverberation due to multipath modeled with time-varying response ■ Doppler spreading modeled by adding frequency variations

slide-10
SLIDE 10

Checking Data Accuracy

  • How can the validity of the channel simulation be established?

○ Impulse response ○ Checking against a MATLAB version done by Milica Stojanovic

slide-11
SLIDE 11
  • Found through an impulse train

○ Vector [1,0,0,0… inputted into delay line

  • Output signal is measured to be the impulse

response

Impulse Response

slide-12
SLIDE 12

Multipath Response Part 1

  • Channel Response to input data
slide-13
SLIDE 13

Multipath Response Part 2

  • Delay Response
slide-14
SLIDE 14

Noise Response

  • Effects of SNR of channel on signals
slide-15
SLIDE 15

Spring Timeline

slide-16
SLIDE 16

Questions?
