workplace 6 Anika Spears Design Project Manager Breakfast with the Stars 2 If we were building your standard premium grade office building Energy = 87 kgCO 2 /m 2 = 309 cars* Water = 31,100,000L = 15.5 olympic pools* * based on a car

slide-1
SLIDE 1

workplace6

Anika Spears

Design Project Manager Breakfast with the Stars

slide-2
SLIDE 2

2

If we were building your standard premium grade office building…

Energy = 87 kgCO2/m2 = 309 cars* Water = 31,100,000L = 15.5 olympic pools*

  • * based on a car producing 4.5t CO2/ year
  • ** based on an olympic pool capacity of 2 mega L
slide-3
SLIDE 3

3

Today

  • Overview
  • What made us 6 Green Star?
  • Computer fly through
  • Questions
slide-4
SLIDE 4

4

WE ARE HERE!

slide-5
SLIDE 5

5

How the project began…

Expression of interest Building owner Developer D&C contractor

slide-6
SLIDE 6

6

How the project began…

Architect Electrical, mechanical hydraulics, lifts services & ABGR, daylight, PMV modeling Structural Engineers ESD advice

slide-7
SLIDE 7

7

Light shelves/ sun hoods Green structure Operable windows Reused materials Low e glass

slide-8
SLIDE 8

8

75m

Typical Floor Plate

  • NLA 3,600m2

75m 24m

slide-9
SLIDE 9

9

2 2 Waste Man. MAN 7 1 1 Commissioning Agent MAN 4 1 1 Building Users Guide MAN 5 2 3 Environmental Man. MAN 6 12 1 2 2 Points Available Points Achieved Title Credit No 11 Total 1 Building Tuning MAN 3 2 Commissioning Clauses MAN 2 2 GS Accredited Professional MAN 1

Management What made us 6 Green Star?

slide-10
SLIDE 10

10

Management

  • We are all accredited professionals
  • CIBSE commissioning/ on going services tuning
  • Good construction management
CLASS ELECTRICAL SERVICES
slide-11
SLIDE 11

11

1 1 Tenant Exhaust Riser IEQ 16 1 1 Formaldehyde Min. IEQ 14 1 1 Mould Prevention IEQ 15 2 2 Thermal Comfort IEQ 9 2 Individual Temp. Control IEQ 10 Na Na Asbestos IEQ 11 1 2 Internal Noise Levels IEQ 12 3 3 VOC IEQ 13 1 2 External Views IEQ 8 1 1 Electric Lighting Levels IEQ 7 3 Daylight IEQ 4 1 Daylight Control Glare IEQ 5 1 1 High Frequency Ballasts IEQ 6 26 1 2 3 Points Available Points Achieved Title Credit No 16 Total 1 Carbon Dioxide Monitoring IEQ 3 2 Air Change Effectiveness IEQ 2 1 Ventilation Rates IEQ 1

Indoor Environment Quality

slide-12
SLIDE 12

12

External views

Good noise levels

Inter-connecting tenancy stair Internal atrium Natural daylight Low VOCs

paints, carpets, adhesives & sealants

slide-13
SLIDE 13

13

External views 50% greater fresh air rates

Low VOC

Good air distribution

CO2 monitoring

Comfortable noise levels Mould prevention

Good lighting design Max 400 lux High frequency ballasts

Chilled beams for

thermal comfort

slide-14
SLIDE 14

14

3 4 Office Lighting Power Den. ENE 5 1 1 Office Lighting Zoning ENE 6 2 2 Peak Energy Demand Red. ENE 7 1 1 Tenancy Sub metering ENE 4 24 1 15 Yes Points Available Points Achieved Title Credit No 21 Total 1 Electrical Sub metering ENE 3 13 Energy Improvement ENE 2 Yes Energy ENE 1

Energy

slide-15
SLIDE 15

15

efficient air conditioning alternative energy good lighting design

ABGR = 5 star + 40% improvement

slide-16
SLIDE 16

16

5 5 Commuting Public Transport TRA 4 11 3 1 2 Points Available Points Achieved Title Credit No 9 Total 3 Cyclist Facilities TRA 3 1 Small Parking Spaces TRA 2 Provision of Car Parking TRA 1

Transport

slide-17
SLIDE 17

17

4 4 Cooling Tower Water WAT 4 1 1 Fire Systems Water WAT 5 13 1 2 5 Points Available Points Achieved Title Credit No 13 Total 1 Landscape Irrigation WAT 3 2 Water Meters WAT 2 5 Potable Water Efficiency WAT 1

Water

slide-18
SLIDE 18

18

Saving Water

  • 4 star water fixtures

6 star urinals

  • Extensive water metering
  • No cooling towers

16.5 million L/ year saved

slide-19
SLIDE 19

19

  • Produces 40,000L/ day

Recycle Water Factory

  • Sewer mining
  • On display for public

viewing

slide-20
SLIDE 20

20

Giving Back to the Community

Saving 31.1 million L

  • f drinking water/ year!!
  • All site and park

irrigation water 15,500L 15,500L 9,000L

Exceeding Green

Star benchmarks

  • All building grey

water

workplace6

slide-21
SLIDE 21

21

3 3 Recycled Content Concrete MAT 5 2 2 Recycled Content Steel MAT 6 2 2 PVC Minimisation MAT 7 3 Shell and Core/ Int. Fitout MAT 4 2 2 Sustainable Timber MAT 8 14 Na Na 2 Points Available Points Achieved Title Credit No 11 Total Na Re-use Structure MAT 3 Na Re-use Façade MAT 2 2 Recycling Waste Storage MAT 1

Materials

slide-22
SLIDE 22

22

1 4 Change in Eco Value ECO 4 1 Topsoil and Fill Removal ECO 5 8 2 1 Yes Points Available Points Achieved Title Credit No 4 Total 2 Contaminated Land ECO 3 1 Reuse of Land ECO 2 Yes Ecological Value of Site ECO 1

Land Use and Ecology

slide-23
SLIDE 23

23

1 1 Cooling Towers EMI 8 1 1 Insulant ODP EMI 9 1 1 Light Pollution EMI 7 2 2 Watercourse Pollution EMI 5 4 4 Reduced Flow to Sewer EMI 6 1 1 Refrigerant Recovery EMI 4 14 1 1 2 Points Available Points Achieved Title Credit No 13 Total 1 Refrigerant Leak Detection EMI 3 Refrigerant GWP EMI 2 2 Refrigerant ODP EMI 1

Emissions

slide-24
SLIDE 24

24

5 5 Points Available Points Achieved Title Credit No 3 Total 2 Environment Design Initiatives INN 3 1 Exceeding Benchmarks INN 2

Innovation 6 star = 75 Workplace 6 = 83 points

slide-25
SLIDE 25

25

If we were standard…

Energy = 87 kgCO2/m2 = 309 cars* Water = 31,100,000L = 15.5 olympic pools**

  • * based on a car producing 4.5t CO2/ year
  • ** based on an olympic pool capacity of 2 mega L

but we are not!

Energy = 39 kgCO2/m2 = 138 cars Water = 2,100,000L = 1 olympic pool

ZERO IMPACT

slide-26
SLIDE 26

Panel question time

?
