IETF & ITU Standardization Activities IETF & ITU Standardization Activities

Emile Stephan

IETF & ITU Standardization Activities 2

Current Documents Current Documents

• RMON Protocol Identifier for IPv6 and MPLS

– Authors: Emile Stephan, Jordi Palet – RFC3919

• IPPM registry

– Authors: Emile Stephan – Latest Version: draft-ietf-ippm-registry-08.txt, October 2004 – Status: 2nd IESG tour soon

• IPPM MIB

– Authors: Emile Stephan, Jessie Jewitt – Latest Version:, draft-ietf-ippm-mib-06.txt February, 2004 – Status: removed from the charter, go to RFC on an individual base

• Metrics definition for interdomain

– draft-stephan-ippm-multicast-metrics-00.txt, draft-stephan-ippm-spatial-metrics-01.txt – Status: see further

• ITU 0.IPtest

– Authors: Renée le Viol, Emile Stephan – Status: format defined

IETF & ITU Standardization Activities 3

RFC3919 RFC3919

• "Remote Network Monitoring (RMON) Protocol Identifiers for IPv6 and Multi Protocol Label Switching

(MPLS)"

• What is a protocol identifier ?

– Codification – Defined in RFC 2896 and RFC 2895

• Why protocol identifiers ?

– Encourage better interoperability between RMON-2 agent implementations – produce valid protocolDirTable INDEX encodings; – Usage in Remote Network Monitoring MIB (Management Information Base) Version 2 [RFC2021]

• Why IPv6 ?

– Avoid error during configurationIPIP6 IP6;

• Success Story:

– 56th IETF:6QM partners identify RMON MIBs where not able to describe IPv6 capabilities; – 57th IETF: individual submission draft-stephan-ipv6-protocol-identifier-00.txt – 58th IETF WG Item: draft-ietf-rmonmib-pi-ipv6-01.txt – After 59th IETF WG last call: draft-ietf-rmonmib-pi-ipv6-02.txt – Before 60th IETF IESG Evaluation; draft-ietf-rmonmib-pi-ipv6-03.txt and 04 – After 60th IETF: RFC Queue – Before 61th IETF: It gained RFC in October 2004. Its number is RFC3919.

IETF & ITU Standardization Activities 4

IPPM MIB data IPPM MIB data model model

• PointOfMeasureTable
• NetMeasureTable
• SynchronizationTable
• HistoryTable
• MetricTable
• OwnersTable
• AggrMeasureTable
• ReportSetupTable
• ReportTable
• Notifications

History Owners

B C A

PointOfMeasure NetMeasure ReportSetup MetricTable Report Notification Synchronisation

Mgmt Usage Network

AggrMeasure

; Test Packet Setup Report ; Measure results Setup Report

IETF & ITU Standardization Activities 5

IPPM Proxy architecture IPPM Proxy architecture

History Table NetworkMeasureTable Notifications AggrMeasureSetupTable ReportSetupTable

V A C M

READ/ CREATE READ/ ONLY

Reportable

S N M P

SynchronisationTable pointOfMeasureTable probe probe probe probe

C O N T R O L L E R

IETF & ITU Standardization Activities 6

IPPM IPPM Registry Registry

• RFC 2678 " IPPM Metrics for Measuring Connectivity"

– Type-P-Instantaneous-Unidirectional-Connectivity,Type-P-Instantaneous-Bidirectional-Connectivity – Type-P-Interval-Unidirectional-Connectivity, Type-P-Interval-Bidirectional-Connectivity – Type-P1-P2-Interval-Temporal-Connectivity

• RFC 2679 "A One-way Delay Metric for IPPM"

– Type-P-One-way-Delay, Type-P-One-way-Delay-Poisson-Stream, Type-P-One-way-Delay-Percentile – Type-P-One-way-Delay-Median, Type-P-One-way-Delay-Minimum, Type-P-One-way-Delay-Inverse-Percentile

• RFC 2680 "One Way Packet Loss Metric for IPPM"

– Type-P-One-way-Packet-Loss, Type-P-One-way-Packet-Loss-Poisson-Stream, Type-P-One-way-Packet-Loss-Average

• RFC2681 "A Round-trip Delay Metric for IPPM"

– Type-P-Round-trip-Delay, Type-P-Round-trip-Delay-Poisson-Stream, Type-P-Round-trip-Delay-Percentile – Type-P-Round-trip-Delay-Median, Type-P-Round-trip-Delay-Minimum, Type-P-Round-trip-Inverse-Percentile

• RFC3357: "One-way Loss Pattern Sample Metrics"

– Type-P-One-Way-Loss-Distance-Stream, Type-P-One-Way-Loss-Period-Stream, Type-P-One-Way-Loss-Noticeable-Rate – Type-P-One-Way-Loss-Period-Total, Type-P-One-Way-Loss-Period-Lengths, Type-P-One-Way-Inter-Loss-Period-Lengths

• RFC3393: "IP Packet Delay Variation Metric for IP Performance Metrics (IPPM)"

– Type-P-One-way-ipdv, Type-P-One-way-ipdv-Poisson-stream, Type-P-One-way-ipdv-percentile – Type-P-One-way-ipdv-inverse-percentile, Type-P-One-way-ipdv-jitter, Type-P-One-way-peak-to-peak-ipdv

• RFC3432: "Network performance measurement with periodic streams"

– Type-P-One-way-Delay-Periodic-Stream

IETF & ITU Standardization Activities 7

Spatial Spatial metrics metrics

Usage: just a narrow scope of usage !

– Active

• a terminal and a node
• A node and a terminal

– Passive

• A node to a node

– Multicast tree – interdomain – Troubleshooting – …

Draft Status:

– need of spatial metrics definition became very urgent in IETF – request from chair to make archeology (see http://www.watersprings.org/pub/id/ ) – merge…

IETF & ITU Standardization Activities 8

ITU ITU O.Iptest O.Iptest

benefits:

– Network performance and QoS can be monitored – Compare results between different instruments – Interoperability between

• instruments of different manufacturers
• administrative domains
• composite networks
• IPv4 and IPv6 measures (NAT PT)

Discussion: Discussion: What is a MAY ? What is a MAY ? What is a MUST ? What is a MUST ?
