IEEE 5G Summit

Nov 16, 2015 Tibor Boros tiboros@google.com

Confidential & Proprietary

Explosive Growth in Mobile Data Traffic

Source: CISCO VNI Report 2015

Confidential & Proprietary

5G Market Drivers

• Internet of Things
• Wireless Sensor Networks
• Smart Homes
• Smart Grid
• Intelligent Transport Systems
• Virtual Reality/Online Gaming
• Medical Sensors

Confidential & Proprietary

Diverse Set of Use Cases and Requirements

Questions:

• What’s the commonality?
• What does this mean for the

design of the protocol?

• Does it make sense to cover all

use cases with a single design?

• What’s the right fragmentation?

Confidential & Proprietary

Overall Objectives: ITU IMT-2020

• Higher data rates

○ Peak data rates up to 20 GBps ○ Average user data rates up to 1 GBps

• Lower latency: ~1 ms
• Higher mobility: Up to 500 km/h
• Higher density

○ Traffic density up to 10 Tbps/km2 ○ Connection density up to 1M/km2

• Higher spectrum efficiency
• Better energy efficiency

Confidential & Proprietary

Flash-Back: 3G/4G Small-Cell Deployment Forecast

Question:

• Why has it been so slow?
• Is technology the problem?

Confidential & Proprietary

Small-Cell Deployment Challenges

• How do we resolve

these challenges in 5G?

• 5G needs to focus on

ease of deployment.

• 5G needs to answer

backhaul challenges.

(Source: Fierce Wireless)

Confidential & Proprietary

Potential New Technologies

• Virtualized Cloud RAN
• Massive MIMO
• SON & Machine Learning
• mm-Wave Technologies
• Software Defined Networking
• Network Function Virtualization
• …..

Source: Daily News

Rice U. Argos project site

Confidential & Proprietary

Big Data Approach

• The network is complex and dynamic.
• Improving network KPIs is a great challenge.
• Traditional methods such as drive testing are

not so representative of actual user experience. Meaningful Goals:

• Focus on Actual User Experience
• Use new technologies such as SON & Machine Learning

to optimize network performance.

• Need open, standardized APIs!

Confidential & Proprietary

New Paradigm: Spectrum Sharing

• The FCC in the US is opening up the 3.5 GHz spectrum for commercial use.
• 3-tier approach

○ Tier 1: Incumbents, e.g. Navy, FSS Earth Stations ○ Tier 2: Protected Access ○ Tier 3: General Authorized Access

• The migration from Exclusive Use to Spectrum Sharing presents technology
• pportunities
• Multiple small operators, ad-hoc or crowd-sourced deployments, or neutral

hosting, etc.
