Identification of Specific Variables: Part 1

Faith Asper, MHS Director, ResDAC Assistance Desk

Objectives

• Review the structure of the variables in the raw

data

• Identify the resource document needed to

determine which data file a variable will be found

• Review the coding scheme used to identify

variables

2

Review the Raw Data

• What is included with the ALPHA file versus the

NMRC file?

Alphanumeric File

3

HCRIS Data Model

4

Hospital [1996 or 2010]_Documentation: HCRIS Data ta Model.pdf

ALPHA File Contents

• The Alphanumeric file contains one record for

each cost report variable.

• File contains only alphanumeric variable types
• Some of the data elements found in this file

include:

˗ Hospital Name ˗ Provider number ˗ Yes/No variables

5

What resource identifies a variable as ALPHA or NMRC?

6

Resource Needed to Determine Variable Type

• “Specifications” document (PRM 15-2) contains

the “Record Specifications” which will identify if the variable is an alpha or numeric

˗ “R3P240S.pdf”, Table 3 (2010 Hospitals) ˗ “R25p236s.zip”, 96SPECS.xls, Table 3 (1996 Hospitals)

7

CMS Cost Report Section

http://www.cms.gov/Research-Statistics-Data-and-Systems/Files-for-Order/CostReports/Hospital-2010-form.html

8

Specifications

• This document includes several useful tables that

are used in identifications of variables and coding schemes.

• This is always included with the Provider

Reimbursement Manual 15-2

• Some cost report downloads will include the list of

data elements in the “documentation” zipped file

• n the provider’s cost report page

9

Specifications: Table 3

10

“X” = Alphanumeric value Field size gives the maximum variable width

Specifications: Table 3

• Identifies the variables contained within the

download

• Identifies the line number and column numbers

where the variable is found

• Identifies the variable type (called “Usage”) as

either alphanumeric or numeric

• Alphanumeric variables are identified with an “X”
• Numeric variables are identified with a “9”

11

NMRC File

• How can I tell if a variable can take a negative

value?

12

NMRC File Contents

• The Numeric file contains one record for each cost

report variable.

• File contains only Numeric variable types
• Some of the data elements found in this file

include:

˗ Number of beds ˗ Number of discharges ˗ Net income

13

Specifications: Table 3

14

“9” indicates a number

Usage Definitions

• From the Introduction of Table 3
• Table 3 ‘Usage’ column is used to specify the

format of each data item as follows:

15

Valu lue Defin initio tion 9 Numeric, greater than or equal to zero

• 9

Numeric, may be either grater than or less than zero 9(x).9(y) Numeric, greater than zero, with x or fewer significant digits to the left of the decimal point, a decimal point, and exactly y digits to the right of the decimal point. X Character

Identification of a Variable

16

Components to Identify a Variable

• Worksheet Code
• Line Code
• Column Code
• All three pieces are necessary to identify a specific

variable.

17

Resources Needed

• 1. Cost Report Forms

˗ Found in Provider Reimbursement Manual (PRM), Part 2 ˗ Found under the provider cost report page, “Related downloads” ˗ Zipped file within the download is labeled with an “F” at the end of the name. For 2010 Hospital cost reports is is “R3P240F.zip”

• 2. Worksheet Code Table

˗ File contained within the “Documentation” download ˗ Can also find this within the “Specifications” download in the PRM, Part 2

18

Resources Needed

• 3. HCRIS Data Model

˗ File will show the length of the variables ˗ File will show the variable type

19

Cost Report Form

• Hospital Name

˗ Worksheet S-2 Part 1, Line 3, Column 1

20

ALPHA File

• How do you find Hospital Name from the raw

data?

21

Worksheet Code Table

• The Worksheet code table provides the list of all

worksheet codes used in the cost report data

22

HCRIS Data Model

• Worksheet code

˗ Length of 7 ˗ Character value

• Line number

˗ Length of 5 ˗ Character value

• Column number

˗ Length of 4 (1996) ˗ Length of 5 (2010) ˗ Character value

23

Line Codes

• Line codes have a length of 5
• First 3 positions indicate the line

˗ Example: Line 1 = 00100

• Last 2 positions indicate a subline

˗ Example: Line 1.01 = 00101 ˗ Sublines occur when a variable is added to the form in between two existing lines.

24

Column Codes

• Column codes have a length of 4 for the 1996

forms and a length of 5 for the 2010 forms

• First 2 (1996) positions indicate the column

˗ Example: Column 1 = 0100

˗ First 3 (2010) positions indicate the column

˗ Example: Column 1 = 00100

• Last 2 positions indicate a subcolumn

˗ Example for 1996 forms: Column 1.01 = 0101 ˗ Example for 2010 forms: Column 1.01 = 00101 ˗ Subcolumns occur when a variable is added to the form in between two existing lines.

25

Cost Report Form

• Hospital Name

˗ Worksheet S-2 Part 1, Line 3, Column 1

26

Hospital Name

• Worksheet Code = S20001
• Line Code = 00300
• Column Code = 00100 (2010 form)
• All three pieces are necessary to identify a specific

variable.

27

Crosswalk Between New and Old Forms

• Crosswalk identifies equivilent variables between

1996 and 2010 forms.

28

Special Unit Coding for 1996 forms

• Note that for the 1996 forms, CMS codes certain

special units using cost center numbers versus using the line number.

• Refer to Documentation, Readme.txt for

information.

• Intensive Care Unit:

˗ Do NOT use the line 6 code 00600 ˗ Use the Cost center code range 02600-02619

29

Summary

• Use the Specifications file, Table 3 to determine if

a variable is in the ALPH or NMRC file.

• Three variables identify a single variable:

˗ Worksheet code ˗ Line code ˗ Column code

30
