I NTRODUCTION TO EWM April 2019 Extracting Minerals From Water I - PowerPoint PPT Presentation

I NTRODUCTION TO EWM April 2019 Extracting Minerals From Water I NTRODUCTION TO EWM n Enviro Water Minerals Company (EWM) has created a revolutionary desalination solution that extracts the dissolved solids contained in a variety of salty water


  1. I NTRODUCTION TO EWM April 2019 Extracting Minerals From Water

  2. I NTRODUCTION TO EWM n Enviro Water Minerals Company (EWM) has created a revolutionary desalination solution that extracts the dissolved solids contained in a variety of salty water sources for beneficial use n EWM extracts and sells the minerals found in salty waters, thereby reducing the cost to desalinate water – Full resource recovery (no residual waste water / disposal issues) – Coupling of revenue from mineral sales and sale of potable water makes business model feasible n Intellectual Property – portfolio of 12 patents / patents pending 2

  3. R EINVENTING D ESALINATION Example Sources Example Production Full Recovery Desalination SM Potable Water Brackish Water Seawater Agricultural Gypsum Caustic Solution ü All contaminants separated into mineral products (zero discharge) Potash Liquid Milk of Magnesia Fertilizer ü Water yield = ~99% Produced Water ü Is often cheapest new water Bromide Rich Brine High-Purity Salt supply option available 3

  4. Full Recovery Desalination Plant M UNICIPALITY / D ISTRICT R ETAINS W ATER R IGHTS , W ELLS , AND D ISTRIBUTION Disinfection and Distribution Brackish Wells Potable Water Chlorine To Distribution 99% water recovery E NVIRO W ATER M INERALS F ULL R ECOVERY D ESALINATION P LANT Ion Exchange Degasifier Nano-Filtration Electrodialysis Reverse Osmosis Heater Air+CO2 HCl Caustic Hot Water 100 F Air Sodium Dilute Acid* from Chloride Brine Low Hardness Soft Mineral Production To Mineral Sulfate Free Calcium Sulfate Brine Sulfate and Production Brine To Mineral Production Magnesium Chloride, Bicarbonate Calcium Chloride Brine Free Brine * NSF 60 certified acid provides additional product water and silica desaturation To Mineral Production 4

  5. F IRST S ITE : E L P ASO EWM’s first project in El Paso is finishing commissioning and expected to commence full commercial operations soon Benefits to El Paso include: § Enhanced yield from existing desalinization plant ( effectively 99%) § Avoided concentrate disposal issues § Preservation of brackish water aquifer life 5

  6. EWM AND EPWU r e t a W Enviro Water Minerals l l e W h s i k c a r B Concentrate Potable Quality Water El Paso Water Utilities KBH Desal Plant 6

  7. EWM P RODUCTION n Process 1.3 mgd of raw brackish water + 1.3 mgd concentrate § Influent raw brackish water TDS: 2,500 mg/L § Influent concentrate TDS: 13,000 mg/L n Products: § Potable-Quality Water (TDS<800 mg/L) § Caustic Soda (50% Concentration) § Hydrochloric Acid (35% Concentration) § Gypsum (high purity, 100% Soluble) § Magnesium Hydroxide (98% Purity, 56% Solid) 7

  8. S ELECT E L P ASO P ARTNERS EWM has partnered with leading designers, operators, equipment manufacturers and chemical distributors for its El Paso plant Engineering / Design / Construction Operations and Maintenance Equipment Manufacturers Revenue Partners 8

  9. D ESALINATION R EINVENTED EWM’s Full Recovery Desalination makes beneficial use of contaminants, eliminating costly and environmentally hazardous disposal issue n All contaminants are separated into mineral products 2017 (zero liquid discharge) Innovative Water n Water yield = ~99% Supply Award n Preserves finite aquifer resources n Avoids disposal issues Winner of the Texas Water n Often is cheapest new water supply option available Development Board’s 2017 Innovative Water Supply Award n Low CO2 footprint for the Technology Category n 12 Patents / patents pending 9
