I-75 South Managed Lanes Whats the Toll for a Hoverboard? Session 5 I-75 South Metro September 29, 2015 Presenters Moderator : Mark Demidovich, GDOT Panel: Darryl VanMeter, GDOT Keith Kunst, Arcadis Shubendu Mohanty, Arcadis

slide-1
SLIDE 1

I-75 South Managed Lanes

What’s the Toll for a Hoverboard? Session 5

I-75 South Metro

September 29, 2015

slide-2
SLIDE 2

Presenters

Moderator: Mark Demidovich, GDOT Panel:

 Darryl VanMeter, GDOT  Keith Kunst, Arcadis  Shubendu Mohanty, Arcadis  Annie Gillespie, SRTA  Jennifer Tsien, Atkins  Bill Gunter, BBH

  • M. Demidovich
slide-3
SLIDE 3

I-75 South Managed Lanes

Project History and Background

Darryl VanMeter

I-75 South Metro

September 29, 2015

slide-4
SLIDE 4

Overall Express Lanes Network

  • D. VanMeter
slide-5
SLIDE 5

Conceptual Overview

 I-75 Express Lanes is identified as a Tier 1

recommendation in the Managed Lane System Plan, adopted by the State Transportation Board in December 2009.

 From the MLSP GDOT recognized that:

 Managed lanes would be defined as a set of lanes where operational

strategies are proactively implemented and managed in response to changing conditions.

 Managed lanes are considered to be complementary treatments to metro

Atlanta’s interstate network

 Managed lane solutions would preserve mobility choices and likely represent

the most appropriate and cost beneficial improvements.

 Transportation needs have outpaced traditional revenue sources  In some locations it is not feasible to build all the additional lanes necessary

to meet current and future needs.

  • D. VanMeter
slide-6
SLIDE 6

Why Is This Project Important?

 I-75 is an important local and regional corridor

 One of the nation’s most traveled highways, especially in metro Atlanta  Primary connection between jobs and fast-growing Henry County

 Safety, travel demand, regional growth and accessibility

are major issues

 Transportation investments are the solution

 Improve roadway capacity, accessibility, efficiency  Address safety -- increased traffic congestion increases crash frequency  Context of Traffic volumes between SR 155 and I-75/675 lends credible

  • pportunity for a ML solution
  • D. VanMeter
slide-7
SLIDE 7

Project Facts

 The project will add two reversible barrier separated

managed lane system along I‐75 in Henry and Clayton Counties from SR 155 to SR 138 for 12.24 miles.

 The express lanes are designed to improve the flow of

traffic, increase travel options for motorists, transit and registered vanpool customers, provide reliable trip times, create jobs and bring economic benefits to the residents of this region.

 The project funding sources: state-motor fuel, federal

aid and toll revenue bonds.

  • D. VanMeter
slide-8
SLIDE 8

Project Facts

 Express Toll Lanes (ETL) is the selected tolling alternative.  The project will add two reversible barrier separated

managed lane system along I‐75 in Henry and Clayton Counties from SR 155 to SR 138 for 12.24 miles.

 The express lanes are designed to improve the flow of

traffic, increase travel options for motorists, transit and registered vanpool customers, provide reliable trip times, create jobs and bring economic benefits to the residents of this region.

 Total Project Phase: $226 Million.

  • D. VanMeter
slide-9
SLIDE 9

Project Schedule

 Decision on Reversible System (2010)  Draft RFP – January 18, 2013  RFP – March 22, 2013  DB Letting – June 22, 2013  EA/FONSI Approval – June 28, 2013  Award – July 5, 2013  Groundbreaking - October 6, 2014  Open to Tolling – Early 2017

  • D. VanMeter
slide-10
SLIDE 10

RACS Integration Org Chart

  • D. VanMeter
slide-11
SLIDE 11

I-75 South Metro

  • D. VanMeter
slide-12
SLIDE 12

Construction Progress

  • D. VanMeter
slide-13
SLIDE 13

Construction Progress

  • D. VanMeter
slide-14
SLIDE 14

I-75 South Managed Lanes

Design-Build Challenges

Keith Kunst

I-75 South Metro

September 29, 2015

slide-15
SLIDE 15

Project Team/ D-B Effort

Contracting Team Prime Contractor - CW Matthews Contracting Company ITS and Tolling Subcontractor – Brooks Berry Haynie Design Team Prime Design Engineer ARCADIS – 85% of the Design including 100% all ITS and Electrical Design Highway Lighting Subconsultant – Atlanta Consulting Engineers

  • K. Kunst
slide-16
SLIDE 16

Roadway Design Aspects of Toll Facilities

Basic Elements

 Reversible System  Barrier Separated System with Access Control Gates  I-75 Southbound shifted out to Create Space for Express Lanes  70 mph Design Speed for Express Lanes, 55 mph for Slip Ramps

  • K. Kunst
slide-17
SLIDE 17

Roadway Design Aspects of Toll Facilities

Toll Plaza Design

Restrictions

 Profile Restrictions at Toll

Zones (0.5% revised to 1%)

 Highway Lighting

throughout toll zones

 Lane and Shoulder Width

Considerations

 Drainage and Metal

Restrictions

  • K. Kunst
slide-18
SLIDE 18

Roadway Design Aspects of Toll Facilities cont’d…

Access Point Design

 Shifts Interstate Mainline to create access points  Distinct Divergences for Exits  Proper entrance ramp tapers, gores, visibility  Distinct wrong way at entrances/exits  Coordinate design with gates

  • K. Kunst
slide-19
SLIDE 19

Roadway Design Aspects of Toll Facilities cont’d…

Accommodating Access

Control System

 Access Control Gate Sequencing

  • Series of warning gates
  • Resistance gate to prevent

wrong way movements

 Gate Heights and Mounting

Accommodations

  • Warning gate arms need to be

between 2’-6” and 3’-6”

  • Gate positions need to account

for cross slopes

  • Side barriers transitioned in

width for structural mounting

  • K. Kunst
slide-20
SLIDE 20

Roadway Design Aspects of Toll Facilities cont’d…

 Locating Generator/ Tolling

Maintenance Sites

 Specialized Site Design  Facilitate SRTA Access  Incorporate Utilities

 Special Access Point -

I-75 at I-675 Split

 Special Access Point -

Jonesboro Road Access Drop Ramp

  • K. Kunst
slide-21
SLIDE 21

I-75 South Managed Lanes

ITS Design

Shubhendu Mohanty

I-75 South Metro

September 29, 2015

slide-22
SLIDE 22

Role of ITS

Traffic Management Tolling System Management

Tolling System Operation General Purpose Operation Reversible Express Lane Operation

  • S. Mohanty
slide-23
SLIDE 23

ITS Components

General Purpose Operation Tolling System Operation Reversible Express Lane Operation

  • S. Mohanty
slide-24
SLIDE 24

Network Topology

Jonesboro Rd Hudson Br Rd Jodeco Rd

HUB-CC HUB-BB SRTA Tolling System Network HUB-U GDOT Navigator Network

Legend

ACS #1 ACS #6 ACS #5 ACS #7 ACS #3 ACS #4

Reversible Access Control System (ACS)

ACS #2

  • S. Mohanty

Project consist of multiple ITS networks.

slide-25
SLIDE 25

Reversible Access Control System

Access Control Signalized Int. Ramp Access Signs Status Beacon Warning Gates Resistance Gate

ACCESS CONTROL SYSTEM

Toll Rate Signs Access Control Signs Travel Time Information Signs

  • S. Mohanty

What are the components of a typical Access Control System?

slide-26
SLIDE 26

Emergency Generator Power

Reversible Express Lane Operation Tolling System ITS Backbone Infrastructure

Jonesboro Rd Hudson Br Rd Jodeco Rd

  • S. Mohanty

Necessary to maintain continuity of reversible lane & tolling operation.

slide-27
SLIDE 27

Resource Sharing

Shared Microwave Detection System Existing Navigator Network Emergency Power System

  • S. Mohanty

Resource Sharing Between GDOT & SRTA

Ductbank System

slide-28
SLIDE 28

Design Initiatives

Comprehensive Design

  • f Electrical System

CCTV Line-of-Sight Verification Device Nomenclature Detailed Toll Site Plan

  • S. Mohanty

Initiatives to address design challenges.

slide-29
SLIDE 29

I-75 South Managed Lanes

Reversal Operations and Redundancy

Annie Gillespie

I-75 South Metro

September 29, 2015

slide-30
SLIDE 30

Reversing I-75 South

 Typically two reversals per day

 Mid-day reversal for outbound evening commute  Late-night reversal for the inbound morning commute

 HERO units will be on-site during all reversals

 Two dedicated units required for reversal

Check that the gates open/close properly at every entry and

exit point

Can access the ACS cabinet to start/continue the reversal (if

reversal fails

  • A. Gillespie
slide-31
SLIDE 31

Access Points

Reversals are completed by Access Point Each Access Point contains equipment for both

entrances and exits

 Gates  Signs  Toll points  Signals/Blank-out Signs

Order of operations is pre-determined, site-specific, and

  • peration specific
  • A. Gillespie
slide-32
SLIDE 32

Example of Slip Ramp Opening

  • 1. GDOT runs camera sweep of entire corridor – looking for debris and stalled vehicles that may be

blocking the managed lanes prior to reversal

  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Inactive SRTA Toll Rate Sign

slide-33
SLIDE 33

Example of Slip Ramp Opening

  • 2. GDOT sends command to SRTA that the managed lanes are ready to open/reverse –Toll Zone set to

expect vehicles

  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-34
SLIDE 34

Example of Slip Ramp Opening

  • 3. GDOT opens barrier and warning gates
  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-35
SLIDE 35

Example of Slip Ramp Opening

  • 3. GDOT opens barrier and warning gates
  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-36
SLIDE 36

Example of Slip Ramp Opening

  • 3. GDOT opens barrier and warning gates
  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-37
SLIDE 37

Example of Slip Ramp Opening

  • 3. GDOT opens barrier and warning gates
  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-38
SLIDE 38

Example of Slip Ramp Opening

  • 4. GDOT changes message on Advanced Guide Signs
  • A. Gillespie

GDOT Advanced Guide Sign Toll Zone Status: Active SRTA Toll Rate Sign

slide-39
SLIDE 39

Example of Slip Ramp Opening

  • 5. GDOT sends command to SRTA to change the message on Toll Rate Sign

– Toll Rate Sign displays a rate; Access point open to traffic

  • A. Gillespie

Toll Zone Status: Active SRTA Toll Rate Sign GDOT Advanced Guide Sign

slide-40
SLIDE 40

75 South Northbound Operation

  • A. Gillespie
slide-41
SLIDE 41

75 South NB to SB Reversal

  • A. Gillespie
slide-42
SLIDE 42

75 South NB to SB Reversal

  • A. Gillespie
slide-43
SLIDE 43

75 South NB to SB Reversal

  • A. Gillespie
slide-44
SLIDE 44

75 South NB to SB Reversal

  • A. Gillespie
slide-45
SLIDE 45

75 South Southbound Operation

  • A. Gillespie
slide-46
SLIDE 46

Physical Redundancy

 Power

 Permanent, natural gas generators  Mobile, trailer-mounted generator  All Access Control Devices have battery backup

 Communication

 Ring of fiber along the main corridor  Redundant pathways to the TMC and SRTA HQ

  • A. Gillespie
slide-47
SLIDE 47

Operational Redundancy

 Active-Active Hub Failover

 SRTA will have a complete system in each hub  If one hub fails, will automatically failover to second hub

 Traffic Management Center

 All managed lanes will operate out of TMC (both GDOT and

SRTA)

 Generator backup  Both GDOT and SRTA have Disaster Recovery Facilities

  • A. Gillespie
slide-48
SLIDE 48

I-75 South Managed Lanes

Electronic Tolling – Comparison of I-85 Express and I-75 South

Jennifer Tsien

I-75 South Metro

September 29, 2015

slide-49
SLIDE 49

Roadside Equipment

  • In-vehicle transponders and/or license plate tolling
  • In-lane equipment
  • Antennas and readers
  • Violation enforcement system including triggers
  • Lighting
  • Audit Cameras
  • Lane Controllers on a LAN
  • Roadside Equipment
  • Traffic Cameras
  • Traffic Sensors
  • Toll Rate signs/cameras
  • J. Tsien

Gantry-Mounted Antenna Inductance Loop Detector VES Camera

slide-50
SLIDE 50

Roadside Equipment – I-85 Express Lanes

  • J. Tsien

VES Camera Gantry Mounted Antenna Inductance Loop Detector RTMS Device

slide-51
SLIDE 51

Roadside Equipment – I-75 South

  • J. Tsien

Reversible Gantry

slide-52
SLIDE 52

Roadside Equipment - Comparison

I-85 Express

 67 total gantries NB and SB  Gantries are located in ½ mile

increments

I-75 South

 75S - 7 total toll zones NB and

SB

 Toll zones are located at each

entry and exit

 Each toll zone has 2 full span

gantries

  • J. Tsien
slide-53
SLIDE 53

Trip Building Overview

  • J. Tsien

Collect Transactions at Gantries Pair/Combine Transactions into Trips Rate Based on Trip Origin and Destination Send to Back Office for Posting

slide-54
SLIDE 54

Trip Building by Project

I-85 Express

 Trip may include a single

tolling segment or multiple tolling segments

 A minimum of two gantry

reads per segment are necessary to form a valid trip

 Minimum number of reads to

form shortest trip is two

 Maximum number of reads to

form longest trip is 34

I-75 South

 No concept of a tolling

Segment

 Entry/exit transactions are

used to create trips

 Two gantry reads are required

to form shortest trip and longest trip

  • J. Tsien
slide-55
SLIDE 55

Toll Operations

  • Host that can be located on

project or remotely

  • Stores images, video,

transactions, traffic data

  • Calculates toll rates and posts to

signs

  • Builds trips and assigns rates
  • Back Office
  • Account management
  • Violations processing
  • Customer Service Center
  • Image review
  • Toll Operation Center
  • Manage toll rates
  • Monitor traffic incidents and

coordinate with GDOT Traffic Management Center (TMC)

  • Monitor tolling equipment
  • J. Tsien
slide-56
SLIDE 56

Toll Pricing – I-85 Express

  • Static, variable, or dynamic
  • I-85 Express Lanes are a

combination of all of the above

  • Minimum rate per mile $0.01,

Maximum rate per mile $0.90

  • Dynamic tolls are calculated

using live traffic speeds and volumes from both the EL and the GP lane

  • Trip rate is calculated per

mile, locked in at point of entry.

  • Signage is based upon

next/last destination

  • Designated weave areas for

ingress/egress.

  • J. Tsien
slide-57
SLIDE 57

Toll Pricing – I-75 South

  • Static, variable, or dynamic
  • I-75 South Express Lanes can be

a combination of the above

  • Minimum – Flat $0.50,

Maximum rate per mile is $0.90

  • Dynamic tolls are calculated

using live traffic speeds and volumes from both the EL and the GP lane

  • Trip rate is segment based,

locked in at point of entry

  • Signage is based upon

next/last destination

  • Ingress/Egress via dedicated

slip ramps along mainline and arterial access ramps

  • J. Tsien
slide-58
SLIDE 58

I-75 South Managed Lanes

Building a Reversible Lane - Access Control System

Bill Gunter

I-75 South Metro

September 29, 2015

slide-59
SLIDE 59

Three Main ACS Components

 The System

 Control cabinet and components  Interlocks and overrides

 Passive Controls

 Changeable Message Signs (CMS)  Conventional / Thermal cameras

 Active Controls

 Warning Gates  Resistance Gates

  • B. Gunter
slide-60
SLIDE 60

System Component Highlights

System designed and built by Cameleon sever and client software Redundant server architecture Interlocks and lane control sequencing ACS cabinets and local controls

  • B. Gunter
slide-61
SLIDE 61

ACS Cabinet and HMI

  • B. Gunter
slide-62
SLIDE 62

Chameleon Software

  • B. Gunter
slide-63
SLIDE 63

Chameleon Software

  • B. Gunter
slide-64
SLIDE 64

Chameleon Software

  • B. Gunter
slide-65
SLIDE 65

Passive Control - CMS

CMS’ alert motorists of lane status and pricing Two types: inserts and walk-in Full color, full matrix

  • B. Gunter
slide-66
SLIDE 66

CMS Bricks

  • B. Gunter
slide-67
SLIDE 67

Full Matrix CMS

  • B. Gunter
slide-68
SLIDE 68

Passive Control – Thermal Cameras

Conventional and Thermal cameras for lane

monitoring

Infrared (IR) Thermal Imaging Cameras Day or night, rain or shine

  • B. Gunter
slide-69
SLIDE 69

Passive Control – Thermal Cameras

  • B. Gunter
slide-70
SLIDE 70

Active Control – Warning Gates

Horizontal-swing gates Provide active warning to

motorists not to enter lane.

Open and close in sequence

  • B. Gunter
slide-71
SLIDE 71

Access Control – Warning Gates

  • B. Gunter
slide-72
SLIDE 72

Active Control – Resistance Gate

Vertical-swing gates Lock into barrier wall Prevent vehicles from entering a closed lane Open and close in sequence with warning gates

  • B. Gunter
slide-73
SLIDE 73
  • B. Gunter
slide-74
SLIDE 74

Active Control – Resistance Gate

  • B. Gunter
slide-75
SLIDE 75

Putting It All Together…

  • B. Gunter
