SLIDE 1
Agenda
- 1. Architecture overview
- 2. URL
- 3. HTTP
- 4. HTML
- 5. Java Socket
HTTP, HTML, URL, Java Socket Agenda 1. Architecture overview 2. - - PowerPoint PPT Presentation
HTTP, HTML, URL, Java Socket Agenda 1. Architecture overview 2. - - PowerPoint PPT Presentation
HTTP, HTML, URL, Java Socket Agenda 1. Architecture overview 2. URL 3. HTTP 4. HTML 5. Java Socket 1. Architectur al Overview (1) (a) A Web page (b) The page reached by clicking on Department of Animal Psychology. 1. Architectural
SLIDE 2
SLIDE 3
1. Architectur al Overview (1)
(a) A Web page (b) The page reached by clicking on Department of Animal Psychology.
SLIDE 4
- 1. Architectural Overview
(2)
The parts of the Web model.
SLIDE 5
- 1. Architectural Overview
(3):The Client Side
(a) A browser plug-in. (b) A helper application.
SLIDE 6
- 1. Architectural Overview
(4): The Server Side
A multithreaded Web server with a front end and processing modules.
SLIDE 7
- 2. URLs – Uniform
Resource Locaters
Some common URLs.
SLIDE 8
- 3. HTTP Methods (1)
The built-in HTTP request methods.
SLIDE 9
- 3. HTTP Methods (2)
The status code response groups.
SLIDE 10
- 3. HTTP Message Headers
(3)
Some HTTP message headers.
SLIDE 11
- 3. Example
HTTP Usage (4)
The start of the
- utput of
SLIDE 12
- 4. HTML – HyperText
Markup Language (1)
(a) The HTML for a sample Web page. (b) The formatted page.
(b)
SLIDE 13
- 4. HTML (2)
A selection of common HTML tags. some can have additional parameters.
SLIDE 14
- 4. HTML(3): Overview of
Forms
<FORM action=‘url’ method=‘get’>… Textarea Menus Input
- Button types
- Text (and password) type
- Hidden type
SLIDE 15
- 4. HTML(4): A simple form
SLIDE 16
- 4. HTML(5): A simple form
<html> <head><title>First Form</title></head> <body> </body> <h1>First Form</h1> <form name ='firstForm' method='get‘ action='http://localhost:8088/'> address: <input type='text' name='addr'><p> message: <textarea name='message' rows=5 cols=40> Enter message here </textarea><p> <input type='submit'> </form> </html>
SLIDE 17
- 4. HTML (6): Forms
The FORM tag
– Method attribute – Action attribute – Enctype attribute – Name attribute?
Form Elements in general
– output name-value pairs
SLIDE 18
- 4. HTML (7): Form output
SLIDE 19
- 4. HTML(8): Form
Elements
Text Area
- Rows & cols
- name attribute
- no value attribute
Menu (<select>)
<select name=‘options’ size=5 multiple> <option value=‘red’ selected>
- drop-down vs. list box use
SLIDE 20
- 4. HTML(9): Input types
Button types
- Submit
– value attribute – name attribute
- Reset
- button
– onclick attribute: executes JS code – can do anything the other buttons can do and more – uses?
SLIDE 21
- 4. HTML(10): Input types
(cont)
Text type
- Maxlength, Size
- Value – default value
Password type Checkbox type
- Value – return value
- key is undefined if not checked
- checked – default value
SLIDE 22
- 4. HTML(11): Input types
(cont)
Radio type
- name attribute determines grouping
- value – return value
Hidden type File upload
- method must be post
- enctype must be multipart/form-data
Server side image map
SLIDE 23
- 5. Socket (1)
- Software interface designed to
communicate between the user program and TCP/IP protocol stack
- Implemented by a set of library
function calls
- Socket is a data structure inside the
program
- Both client and server programs
SLIDE 24
- 5. Socket (2): Framework
Application Program Application Program Socket Layer Socket Layer TCP TCP UDP UDP IP IP User Space User Space Kernel Space Kernel Space Physical Network Physical Network (driver) (driver)
SLIDE 25
- 5. Socket (3): Socket
Families
There are several significant socket domain families: Internet Domain Sockets (AF_INET)
- implemented via IP addresses and port
numbers Unix Domain Sockets (AF_UNIX)
- implemented via filenames (think “named
