HOW V VIRTUAL BEC ECOMES R REA EAL Find structural form with Karamba. Form-finding with Large deformations ( G_01.2) FO FORM-FIND NDING NG identifies the process of designing optimal structural shapes by means of experimental tools

SLIDE 1

HOW V VIRTUAL BEC ECOMES R REA EAL

Find structural form with Karamba. Form-finding with “Large deformations” (G_01.2)

SLIDE 2

FO FORM-FIND NDING NG

identifies the process of designing optimal structural shapes by means of experimental tools and strategies (physical models) to simulate a specific (expected) mechanical behavior

SLIDE 3

D. Chen, J., Kure, K. Usto, K. Clausen, T. Manickam, 2010

SLIDE 4

IL Archive, Graefe, Otto, Tomlow, Walz

SLIDE 5

IL Archive, Atelier Frei Otto

SLIDE 6

Heinz Isler, Concrete Shells Derived from Experimental Shapes, SEI, 1994

SLIDE 7

Minimal surfaces

(S. Musmeci, Bridge over the Basento river)

Pneumatic forms

(F. Otto, experiments)

Geometric forms

(F. Candela, Los Manantiales Restaurant)

OTHER FORM-FINDING TECHNIQUES

SLIDE 8
