How Tracking Companies Circumvented Ad Blockers Using WebSockets

Muhammad Ahmad Bashir, Sajjad Arshad, Engin Kirda, William Robertson, Christo Wilson



Northeastern University

slide-2
SLIDE 2

Online Tracking

2

slide-3
SLIDE 3

Online Tracking

Surge in online advertising (internet economy)

  • Ad networks pour in billions of dollars.
  • Value for their investment?
  • Extensive tracking to serve targeted ads.

2

slide-4
SLIDE 4

Online Tracking

Surge in online advertising (internet economy)

  • Ad networks pour in billions of dollars.
  • Value for their investment?
  • Extensive tracking to serve targeted ads.

2

User concern over tracking

  • Led to the proliferation of ad blocking extensions
slide-5
SLIDE 5

Online Tracking

Surge in online advertising (internet economy)

  • Ad networks pour in billions of dollars.
  • Value for their investment?
  • Extensive tracking to serve targeted ads.

2

User concern over tracking

  • Led to the proliferation of ad blocking extensions

Ad networks fight back

  • E.g Using anti ad blocking scripts
slide-6
SLIDE 6

Google & Safari

  • Google evaded Safari’s third-party cookie blocking policy

(Jonathan Mayer)

  • … by submitting a form in an invisible iFrame
  • Google was fined $22.5M by FTC

3

slide-7
SLIDE 7

This Talk

How Ad Networks leveraged a bug in Chrome API to bypass Ad Blockers using WebSockets

4

slide-8
SLIDE 8

This Talk

How Ad Networks leveraged a bug in Chrome API to bypass Ad Blockers using WebSockets

4

  • 1. What caused this?
  • 2. How this bug was leveraged by ad networks?
slide-9
SLIDE 9

Web Sockets

5

slide-10
SLIDE 10

Web Sockets

5

HTTP/S

slide-11
SLIDE 11

Web Sockets

5

HTTP/S

request response

slide-12
SLIDE 12

Web Sockets

5

HTTP/S

request response

Chatting App

slide-13
SLIDE 13

Web Sockets

5

HTTP/S

request response

Chatting App

anything new?

slide-14
SLIDE 14

Web Sockets

5

HTTP/S

request response

Chatting App

anything new?

Web Socket

slide-15
SLIDE 15

Web Sockets

5

HTTP/S

request response

Chatting App

anything new?

Web Socket

bidirectional

  • Both client and server can send/receive data
  • This is a persistent connection
slide-16
SLIDE 16

Web Sockets

5

HTTP/S

request response

Chatting App

anything new?

Web Socket

bidirectional ws:// or wss://

  • Both client and server can send/receive data
  • This is a persistent connection
slide-17
SLIDE 17

Ad Blockers

6

slide-18
SLIDE 18

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests
slide-19
SLIDE 19

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

webRequest API

slide-20
SLIDE 20

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API

slide-21
SLIDE 21

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

Usually borrowed
 from EasyList

slide-22
SLIDE 22

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

url

Usually borrowed
 from EasyList

slide-23
SLIDE 23

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

url

Usually borrowed
 from EasyList

slide-24
SLIDE 24

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

url

Usually borrowed
 from EasyList

slide-25
SLIDE 25

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

url

webRequest API

Usually borrowed
 from EasyList

slide-26
SLIDE 26

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

http://doubleclick.com/s1.js url

webRequest API

Usually borrowed
 from EasyList

slide-27
SLIDE 27

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

http://doubleclick.com/s1.js url

webRequest API

url

Usually borrowed
 from EasyList

slide-28
SLIDE 28

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

http://doubleclick.com/s1.js url

webRequest API

url

Usually borrowed
 from EasyList

slide-29
SLIDE 29

Ad Blockers

6

  • Chrome extension chrome.webRequest API
  • Extension can inspect / modify / drop outgoing requests

http://cnn.com/logo.jpeg

webRequest API Rule List

http://doubleclick.com/s1.js url

webRequest API

url

Usually borrowed
 from EasyList

slide-30
SLIDE 30

AdBlock Evasion

7

slide-31
SLIDE 31

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

webRequest API

slide-32
SLIDE 32

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

webRequest API

slide-33
SLIDE 33

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

Original bug
 reported

webRequest API

slide-34
SLIDE 34

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

Original bug
 reported Users report
 unblocked ads

webRequest API

slide-35
SLIDE 35

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

Original bug
 reported Users report
 unblocked ads Patch Finalized
 ( Landed)

webRequest API

slide-36
SLIDE 36

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

Original bug
 reported Users report
 unblocked ads Patch Finalized
 ( Landed) Chrome 58
 released

webRequest API

slide-37
SLIDE 37

AdBlock Evasion

  • Bug in
  • ws/wss requests did not trigger the API

7

2012 2013 2014 2015 2016 2017 2018

* * * *

Original bug
 reported Users report
 unblocked ads Patch Finalized
 ( Landed) Chrome 58
 released

* Represents when our crawls were done

webRequest API

slide-38
SLIDE 38

Data Crawling

8

slide-39
SLIDE 39

Data Crawling

8

100K websites
 sampled from Alexa

slide-40
SLIDE 40

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources

slide-41
SLIDE 41

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources

This means we know which resource included which other resource

slide-42
SLIDE 42

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets

This means we know which resource included which other resource

slide-43
SLIDE 43

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets Detect A&A
 WebSockets

Mark web sockets
 which are used by A&A domains

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs This means we know which resource included which other resource

slide-44
SLIDE 44

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets Detect A&A
 WebSockets

Mark web sockets
 which are used by A&A domains

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs This means we know which resource included which other resource

pub/ index.html srv.ws ads/ script.js ads/ frame.html ads/ img_a.jpg adnet/ data.ws

Example Inclusion Tree

slide-45
SLIDE 45

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets Detect A&A
 WebSockets

Mark web sockets
 which are used by A&A domains

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs This means we know which resource included which other resource

pub/ index.html srv.ws ads/ script.js ads/ frame.html ads/ img_a.jpg adnet/ data.ws

Example Inclusion Tree

WebSocket WebSocket

slide-46
SLIDE 46

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets Detect A&A
 WebSockets

Mark web sockets
 which are used by A&A domains

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs This means we know which resource included which other resource

pub/ index.html srv.ws ads/ script.js ads/ frame.html adnet/ data.ws

Example Inclusion Tree

WebSocket WebSocket

slide-47
SLIDE 47

Data Crawling

8

100K websites
 sampled from Alexa

Visit 15
 links / website

Collected chains for all included resources Filter all resources which end in
 web sockets

Filter
 WebSockets Detect A&A
 WebSockets

Mark web sockets
 which are used by A&A domains

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs This means we know which resource included which other resource

pub/ index.html ads/ script.js ads/ frame.html adnet/ data.ws

Example Inclusion Tree

WebSocket

slide-48
SLIDE 48

High-Level Numbers

9

slide-49
SLIDE 49

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18 Before
 Chrome 58

slide-50
SLIDE 50

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18 Before
 Chrome 58 After
 Chrome 58

slide-51
SLIDE 51

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18

  • ~2% websites use web sockets.

Before
 Chrome 58 After
 Chrome 58

slide-52
SLIDE 52

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18

  • ~2% websites use web sockets.
  • ~61 % sockets are initiated by A&A domains

Before
 Chrome 58 After
 Chrome 58

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs

slide-53
SLIDE 53

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18

  • ~2% websites use web sockets.
  • ~61 % sockets are initiated by A&A domains
  • ~71 % sockets contact an A&A domain

Before
 Chrome 58 After
 Chrome 58

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs

slide-54
SLIDE 54

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18

  • ~2% websites use web sockets.
  • ~61 % sockets are initiated by A&A domains
  • ~71 % sockets contact an A&A domain
  • # Initiators drop after Chrome 58 release.

Before
 Chrome 58 After
 Chrome 58

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs

slide-55
SLIDE 55

High-Level Numbers

9

Crawl Dates %Websites
 with sockets % Sockets
 with A&A
 Initiators % Sockets
 with A&A
 Receivers #Unique A&A
 Initiators #Unique A&A
 Receivers Apr 02-05, 2017 2.1 60.6 73.7 75 16 Apr 11-16, 2017 2.4 61.3 74.6 63 18 May 07-12, 2017 1.6 60.2 69.7 19 15 Oct 12-16, 2017 2.5 63.4 63.7 23 18

  • ~2% websites use web sockets.
  • ~61 % sockets are initiated by A&A domains
  • ~71 % sockets contact an A&A domain
  • # Initiators drop after Chrome 58 release.
  • Small but persistent A&A receivers.

Before
 Chrome 58 After
 Chrome 58

A&A = Advertising and Analytics e.g. DoubleClick, Criteo, Adnxs

slide-56
SLIDE 56

Initiators and Receivers

10

slide-57
SLIDE 57

Initiators and Receivers

10

Initiator Receiver

JavaScript

slide-58
SLIDE 58

Initiators and Receivers

10

Initiator Receiver ws/s

JavaScript

slide-59
SLIDE 59

Initiators and Receivers

10

Initiator Receiver ws/s

JavaScript

slide-60
SLIDE 60

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3

Top A&A
 Initiators

Initiator Receiver ws/s

JavaScript

slide-61
SLIDE 61

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3

Top A&A
 Initiators

Initiator Receiver ws/s

JavaScript

slide-62
SLIDE 62

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3 A&A Receiver #A&A
 Initiators realtime 27 33across 19 intercom 16 disqus 13 zopim 12 hotjar 11 feedjit 10 lockerdome 8 inspectlet 6 smartsupp 4

Top A&A
 Initiators Top A&A
 Receivers

Initiator Receiver ws/s

JavaScript

slide-63
SLIDE 63

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3 A&A Receiver #A&A
 Initiators realtime 27 33across 19 intercom 16 disqus 13 zopim 12 hotjar 11 feedjit 10 lockerdome 8 inspectlet 6 smartsupp 4

Top A&A
 Initiators Top A&A
 Receivers

Initiator Receiver ws/s

  • Disqus provides

comment board services.

JavaScript

slide-64
SLIDE 64

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3 A&A Receiver #A&A
 Initiators realtime 27 33across 19 intercom 16 disqus 13 zopim 12 hotjar 11 feedjit 10 lockerdome 8 inspectlet 6 smartsupp 4

Top A&A
 Initiators Top A&A
 Receivers

Initiator Receiver ws/s

  • Disqus provides

comment board services.

  • Zopim, Intercom,

Smartsupp provide live chat services.

JavaScript

slide-65
SLIDE 65

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3 A&A Receiver #A&A
 Initiators realtime 27 33across 19 intercom 16 disqus 13 zopim 12 hotjar 11 feedjit 10 lockerdome 8 inspectlet 6 smartsupp 4

Top A&A
 Initiators Top A&A
 Receivers

Initiator Receiver ws/s

  • Disqus provides

comment board services.

  • Zopim, Intercom,

Smartsupp provide live chat services.

  • 33across & Lockerdome

are advertising platforms.

JavaScript

slide-66
SLIDE 66

Initiators and Receivers

10

A&A Initiator #A&A
 Receivers facebook 11 google 11 doubleclick 9 youtube 8 addthis 8 hotjar 7 googlesyndication 6 twitter 5 sharethis 4 adnxs 3 A&A Receiver #A&A
 Initiators realtime 27 33across 19 intercom 16 disqus 13 zopim 12 hotjar 11 feedjit 10 lockerdome 8 inspectlet 6 smartsupp 4

Top A&A
 Initiators Top A&A
 Receivers

Initiator Receiver ws/s

  • Disqus provides

comment board services.

  • Zopim, Intercom,

Smartsupp provide live chat services.

  • 33across & Lockerdome

are advertising platforms.

  • Inspectlet & Hotjar are

session replay services.

JavaScript

slide-67
SLIDE 67

Sent Items Over Web Sockets

11

slide-68
SLIDE 68

Sent Items Over Web Sockets

11

Cookie IP User IDs Fingerprinting
 Variables DOM

% Requests

20 40 60 80

WebSockets HTTP/S

slide-69
SLIDE 69

Sent Items Over Web Sockets

11

  • Stateful Identifiers like Cookie and User IDs

Cookie IP User IDs Fingerprinting
 Variables DOM

% Requests

20 40 60 80

WebSockets HTTP/S

slide-70
SLIDE 70

Sent Items Over Web Sockets

11

  • Stateful Identifiers like Cookie and User IDs
  • Fingerprinting data in ~3.4% WebSockets.


97% is 33across

Cookie IP User IDs Fingerprinting
 Variables DOM

% Requests

20 40 60 80

WebSockets HTTP/S

slide-71
SLIDE 71

Sent Items Over Web Sockets

11

  • Stateful Identifiers like Cookie and User IDs
  • Fingerprinting data in ~3.4% WebSockets.


97% is 33across

  • ~1.6% WebSockets sends the entire DOM to


Hotjar, LuckyOrange, TruConversion

Cookie IP User IDs Fingerprinting
 Variables DOM

% Requests

20 40 60 80

WebSockets HTTP/S

slide-72
SLIDE 72

12

Received Items Over Web Sockets

slide-73
SLIDE 73

12

Received Items Over Web Sockets

HTML JSON JavaScript Images

% Responses

10 20 30 40 50

WebSockets HTTP/S

slide-74
SLIDE 74

12

Received Items Over Web Sockets

HTML JSON JavaScript Images

% Responses

10 20 30 40 50

WebSockets HTTP/S

slide-75
SLIDE 75

12

Received Items Over Web Sockets

HTML JSON JavaScript Images

% Responses

10 20 30 40 50

WebSockets HTTP/S

slide-76
SLIDE 76

12

Received Items Over Web Sockets

Ads served from Lockerdome

HTML JSON JavaScript Images

% Responses

10 20 30 40 50

WebSockets HTTP/S

slide-77
SLIDE 77

Summary

  • ~67% of socket connections are initiated or received by A&A domains.
  • Major companies like Google, Facebook, Addthis adopted WebSockets.


Abandoned after Chrome 58 was released.

  • The culprits:
  • 33across was harvesting fingerprinting data.
  • DOM exfiltration by HotJar, LuckyOrange, TruConversion
  • Lockerdome downloaded URLs to serve ads.
  • We need to keep up with the current practices of A&A companies.

13

slide-78
SLIDE 78

Summary

  • ~67% of socket connections are initiated or received by A&A domains.
  • Major companies like Google, Facebook, Addthis adopted WebSockets.


Abandoned after Chrome 58 was released.

  • The culprits:
  • 33across was harvesting fingerprinting data.
  • DOM exfiltration by HotJar, LuckyOrange, TruConversion
  • Lockerdome downloaded URLs to serve ads.
  • We need to keep up with the current practices of A&A companies.

13

Questions?

ahmad@ccs.neu.edu

slide-79
SLIDE 79

Backup Slides

slide-80
SLIDE 80

Inclusion Chain

15

<html> <body> <script src=“tracker/script.js” </script> <img src=“tracker/img.jpg”> </img> <script src=“ads/script.js”> </script> <iframe src=“frame.html”> <html> <body> <script src=“script_12.js”> </script> <img src=“img_a.jpg”> </img> </body> </html> </iframe> </body> </html> pub/ index.html tracker/ script.js tracker/ img.jpg ads/ script.js ads/ frame.html ads/ script_12.js ads/ img_a.jpg adnet/ data.ws

Source code for ads/script_12.js

 let ws =
 new WebSocket(“ws://adnet/data.ws”, …);
 ws.onopen = function (e) {ws.send(“…”);}

DOM Tree Inclusion Tree
