SLIDE 1
How to prevent sabotage and ensure consumer privacy with RAIN RFID
Tjibbe van der Laan
2
How to prevent sabotage and ensure consumer privacy with RAIN RFID - - PowerPoint PPT Presentation
How to prevent sabotage and ensure consumer privacy with RAIN RFID - - PowerPoint PPT Presentation
How to prevent sabotage and ensure consumer privacy with RAIN RFID Tjibbe van der Laan 2 Hardware independent 3 780 stores 4 countries project start in 2017, roll-out in 2018 4 280 stores United Kingdom, some other countries
SLIDE 2
SLIDE 3
Hardware independent
3
SLIDE 4
4
780 stores 4 countries project start in 2017, roll-out in 2018
SLIDE 5 5
280 stores United Kingdom, some other countries roll-out in 2017
SLIDE 6 6
50 stores 23 countries from Japan to USA roll-out completed in three months
SLIDE 7
Stock accuracy Better customer service Product availability
SLIDE 8
Full supply chain coverage
8
🚛 🏭 🏸
(Source) Tagging
- Independent RFID label
performance quality control
- Purchasing assistance
- Validation of label-
encoding, serialisation and security/privacy
Logistics and DCs
- Nedap consults and leads
- Partnered approach
- !D Cloud DC Connector to
connect supply chain together
Store
- Covering all store stock
processes
- Intuitive solution including
training manuals, videos and support portal
- Open platform to integrate
with 3rd parties (customer interaction e.g.)
SLIDE 9
By default, RAIN RFID tags are not protected
Everybody is able to re-write the EPC and other memory contents Everybody is able to kill the tags
9
SLIDE 10
There are two ways to protect RAIN RFID tags
10
🔒 🔓
Passwords Lock
SLIDE 11
Access password used for (preventing) reading and writing specific memories in the chip Kill password used for (preventing) killing the chip
11
Two passwords
🔒
SLIDE 12
- 1. Write (and read) the memory - without Access
Password
- 2. Write (and read) the memory - when providing
Access Password
- 3. Impossible to write (and read) the memory - even
while having the Access Password
- 4. Always write (and read) the memory
12
Lock provides four options
🔓
Independent setting for both passwords, EPC, User and TID memory
SLIDE 13
Privacy is getting more and more important
13
Consumer attention is growing Retailers move from tickets to embedded tags
SLIDE 14
RAIN RFID poses privacy risk
Longe range identification Globally unique number (TID) Associated with or integrated in physical product ‘Indirectly identifiable personal information’
14
SLIDE 15
RAIN RFID privacy features
‘Untraceable’
- Read Range Reduction
Read only at short distance
- Hide Memory
Only read privacy-sensitive data when knowing the Access Password Works even with permanently locked memories; protected with Access Password
15
SLIDE 16
Want to know more?
Tjibbe van der Laan | tjibbe.vanderlaan@nedap.com
