HOME OF THE MUSES

SLIDE 2

ANA- LYTIC EMO- TION

“WITHOUT MUSIC LIFE WOULD Bb”

SIGN ABOVE ON CHOIR ROOM DOOR

UNI VERS ITAS

SLIDE 3

AUDITORIUM

2ND FLOOR CURRICULUM 1ST FLOOR ARTS THEATER COMMONS

SLIDE 4

ARCHITECTURAL MUSES

SLIDE 5

9.COLOR 5.RHYTHM 6.LIGHT 7.SHADOW 8.TEXTURE 1.SPACE 2.FORM 3.ORDER 4.STRUCTURE

“GOD IS IN THE DETAILS”

LUDWIG MIES VAN DER ROHE

SLIDE 6

“ARCHITECTURE IS FROZEN MUSIC”

JOHANN WOLFGANG VON GOETHE

LIGHT

The Kennedy Center for the Performing Arts

TEXTURE LIGHT RHYTHM FORM FORM

SLIDE 7

INTIMATE INVITING NATURAL LIGHT FLEXIBLE

Janet Wallace Fine Arts Center - Macalester College

SLIDE 8 Creative Arts and Design Center, Menlo School

FUNCTIONAL CONTEMPORARY OPEN

SLIDE 9

SITE PLAN

1. PRIOR TO START POSITION AND C 2. EXISTING BENCH 3. COORDINATE WIT ELEVATIONS. 4. ANY DISCREPANC WITH INDICATION BROUGHT TO TH CONSTRUCTION 5. FOR THE SOILS I PART 'C'-GEOTEC COPIES OF THE S FROM THE CONS ENGINEER, AND T 6. ALL ROAD/UTILIT WITH SIMILAR WO COORDINATED B CONSTRUCTION 7. FINAL POSITIONI TO THE APPROVA CONTRACTOR SH 8. IN CASE OF CON DRAWINGS, AS T CONCRETE CURB DRAWINGS SHAL G ASPH INFIEL GRAV MEAS FENC C.I.P. DRAW C.I.P. DRAW SWING PROP MONU SITE L M.L. SG-X 2 3 4 5 6 RE

FIELDS PARKING DROP OFF PHASE 1 PHASE 2

SLIDE 10 REF. UP 1. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO THE FACE OF STUDS FOR GWB WALLS / PARTITIONS. 2. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO FACE OF FINISHED MASONRY FOR CMU. 3. FOR FLOOR FINISHES RE: ROOM FINISH SCHEDULE, SHEETS _______ AND FINISH PLANS, SHEETS ________. 4. UNLESS NOTED OTHERWISE ALL GWB WALLS SHALL HAVE A 6" STUD FRAME RETURN AT ALL DOOR AND WINDOW JAMBS. 5. FOR SIZES OF MARKERBOARDS AND TACK BOARDS RE: SPECIFICATION SECTION DIVISION 10 - VISUAL DISPLAY SURFACES. LENGTH IS INDICATED ON FLOOR PLANS. 6. AT WARDROBE/TV CASEWORK, REFER TO EACH ROOM AS TO VERIFY DOOR SWING LOCATION. 7. RE: SHEETS _______ FOR BUILDING OCCUPANCY PLANS AND FIRE RESISTIVE CONSTRUCTION REQUIREMENTS. 8. SEE ENLARGED PLANS FOR ADDITIONAL WALL TYPES. 9. FOR GLAZING RECEIVING WINDOW TREATMENTS, COORDINATE WITH SPECIFICATION SECTION DIVISION 12 - HORIZONTAL LOUVER BLINDS.

10. FOR WALLS NOT DESIGNATED WITH A WALL TYPE, COORDINATE WITH

STRUCTURAL DRAWINGS & WALL SECTIONS. GENERAL NOTES STEEL STUD WALL AND GYPSUM BOARD WALL. RE: WALL TYPES. CONCRETE MASONRY UNIT (CMU) WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS, COORDINATE WITH STRUCTURAL DRAWINGS. CONCRETE WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. MASONRY VENEER. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. 1 XXXx XXXXXXX FLOOR DRAIN. COORDINATE WITH PLUMBING DRAWINGS. FIRE EXTINGUISHER CABINET. RE: DIVISION 10 - SPECIALTIES 10 AND SHEET XXXXX WINDOW TYPE, RE: WINDOW FRAME TYPE SHEETS, SHEET XXXX WALL TYPE, RE: SHEET XXXX DOOR SYMBOL, RE: DOOR SCHEDULE, SHEET XXXX TOILET AND BATH ACCESSORY, RE: SHEET XXXX XXX LEGEND FD 1018 SF BAND/CONTEMPORARY CLASSROOM 134 992 SF ORCHESTRA CLASSROOM 133 996 SF DANCE STUDIO 2 128 996 SF DANCE STUDIO 1 127 157 SF KILN 123 114 SF POTTERY STORAGE 122 905 SF ART STUDIO 124 213 SF SMALL CONFERENCE 112 290 SF LARGE CONFERENCE 111 68 SF STORAGE/VAULT 102 287 SF PRINCIPALS OFFICE 109 199 SF COUNSELING 106 227 SF NURSE/HEALTH SUITE 105 162 SF SECURITY OFFICE 103 157 SF REGISTRAR/BOOK KEEPING 119 258 SF COMMON BREAK AREA 115 97 SF MAIL AT ADMIN 116 100 SF STUDY ROOM 118 100 SF STUDY ROOM 117 73 SF PRACTICE 136 62 SF PRACTICE 137 106 SF PRACTICE 138 60 SF PRACTICE 139 60 SF PRACTICE 140 80 SF COPY CENTER 104 171 SF KITCHEN CAFE 120 39 SF STORAGE 110 994 SF CHOIR / VOCAL CLASSROOM 132 583 SF RECEPTION / CLERICAL 101 261 SF RESTROOM 130 260 SF RESTROOM 131 199 SF COUNSELING 107 86 SF RESTROOM 113 86 SF RESTROOM 114 137 SF MECH 129 109 SF PRACTICE 143 103 SF PRACTICE 144 88 SF PRACTICE 145 989 SF ART STUDIO 126 53 SF RESTROOM 105A 130 SF CHANGING ROOM 153 59 SF RR 153a 114 SF CHANGING ROOM 154 65 SF RR 154a 72 SF PRACTICE 158 107 SF PRACTICE 159 110 SF PRACTICE 160 P r o j e c t : S h e e t : P r o j e c t N o : D r a w n B y : C h e c k e d B y : D a t e : R e v i s i o n s : "THESE RECORD DRAWINGS HAVE BEEN PREPARED, IN PART, ON THE BASIS OF INFORMATION COMPILED AND FURNISHED BY OTHERS. THEREFORE, THE ARCHITECT AND OTHER DESIGN CONSULTANTS INVOLVED IN THIS PROJECT SHALL NOT BE RESPONSIBLE FOR ANY ERRORS OR OMISSIONS WHICH HAVE BEEN INCORPORATED INTO THESE DOCUMENTS AS A RESULT OF DOCUMENTS AND/OR INFORMATION PROVIDED FROM OTHER SOURCES." RECORD DRAWINGS E D C B A WEST ADA SCHOOL DISTRICT TBD Central Dr. Meridian, ID 83642 LEVEL 01 - FLOOR PLAN 19008 Author Checker 12/10/2019 PROGRAMMING REFERENCE NOTES AREA B AREA A

PHASE 1|1ST FLOOR PLAN

PHASE 2

COMMONS/ PERFORMANCE SPACE

SLIDE 11 UP 1. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO THE FACE OF STUDS FOR GWB WALLS / PARTITIONS. 2. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO FACE OF FINISHED MASONRY FOR CMU. 3. FOR FLOOR FINISHES RE: ROOM FINISH SCHEDULE, SHEETS _______ AND FINISH PLANS, SHEETS ________. 4. UNLESS NOTED OTHERWISE ALL GWB WALLS SHALL HAVE A 6" STUD FRAME RETURN AT ALL DOOR AND WINDOW JAMBS. 5. FOR SIZES OF MARKERBOARDS AND TACK BOARDS RE: SPECIFICATION SECTION DIVISION 10 - VISUAL DISPLAY SURFACES. LENGTH IS INDICATED ON FLOOR PLANS. 6. AT WARDROBE/TV CASEWORK, REFER TO EACH ROOM AS TO VERIFY DOOR SWING LOCATION. 7. RE: SHEETS _______ FOR BUILDING OCCUPANCY PLANS AND FIRE RESISTIVE CONSTRUCTION REQUIREMENTS. 8. SEE ENLARGED PLANS FOR ADDITIONAL WALL TYPES. 9. FOR GLAZING RECEIVING WINDOW TREATMENTS, COORDINATE WITH SPECIFICATION SECTION DIVISION 12 - HORIZONTAL LOUVER BLINDS.

10. FOR WALLS NOT DESIGNATED WITH A WALL TYPE, COORDINATE WITH

STRUCTURAL DRAWINGS & WALL SECTIONS. GENERAL NOTES STEEL STUD WALL AND GYPSUM BOARD WALL. RE: WALL TYPES. CONCRETE MASONRY UNIT (CMU) WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS, COORDINATE WITH STRUCTURAL DRAWINGS. CONCRETE WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. MASONRY VENEER. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. 1 XXXx XXXXXXX FLOOR DRAIN. COORDINATE WITH PLUMBING DRAWINGS. FIRE EXTINGUISHER CABINET. RE: DIVISION 10 - SPECIALTIES 10 AND SHEET XXXXX WINDOW TYPE, RE: WINDOW FRAME TYPE SHEETS, SHEET XXXX WALL TYPE, RE: SHEET XXXX DOOR SYMBOL, RE: DOOR SCHEDULE, SHEET XXXX TOILET AND BATH ACCESSORY, RE: SHEET XXXX XXX LEGEND FD 1075 SF SCIENCE LAB 215 855 SF CLASSROOM 216 852 SF CLASSROOM 201 852 SF CLASSROOM 202 851 SF CLASSROOM 203 848 SF CLASSROOM 211 851 SF CLASSROOM 204 848 SF CLASSROOM 210 269 SF PREP / STORAGE 214 858 SF CLASSROOM 205 867 SF CLASSROOM 213 217 SF RESTROOM 220 270 SF STORAGE 221 320 SF SPED 208 858 SF CLASSROOM 206 858 SF CLASSROOM 207 161 SF PRACTICE 209 184 SF STORAGE 212 80 SF RESTROOM 218 75 SF MECHANICAL 222 218 SF RESTROOM 219 1805 SF BLACK BOX 234 74 SF CUST 226 70 SF TECH 227 674 SF STORAGE 225 204 SF PRACTICE 230 204 SF PRACTICE 231 222 SF PRACTICE 232 P r o j e c t : S h e e t : P r o j e c t N o : D r a w n B y : C h e c k e d B y : R e v i s i o n s : "THESE RECORD DRAWINGS HAVE BEEN PREPARED, IN PART, ON THE BASIS OF INFORMATION COMPILED AND FURNISHED BY OTHERS. THEREFORE, THE ARCHITECT AND OTHER DESIGN CONSULTANTS INVOLVED IN THIS PROJECT SHALL NOT BE RESPONSIBLE FOR ANY ERRORS OR OMISSIONS WHICH HAVE BEEN INCORPORATED INTO THESE DOCUMENTS AS A RESULT OF DOCUMENTS AND/OR INFORMATION PROVIDED FROM OTHER SOURCES." RECORD DRAWINGS E D C B A WEST ADA SCHOOL DISTRICT TBD Central Dr. Meridian, ID 83642 LEVEL 02 - FLOOR PLAN 19008 Author Checker PROGRAMMING REFERENCE NOTES AREA B AREA A

PHASE 1 | 2ND FLOOR PLAN

PHASE 2

TEMP LIBRARY

SLIDE 12 UP DN DN REF. UP UP 1. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO THE FACE OF STUDS FOR GWB WALLS / PARTITIONS. 2. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO FACE OF FINISHED MASONRY FOR CMU. 3. FOR FLOOR FINISHES RE: ROOM FINISH SCHEDULE, SHEETS _______ AND FINISH PLANS, SHEETS ________. 4. UNLESS NOTED OTHERWISE ALL GWB WALLS SHALL HAVE A 6" STUD FRAME RETURN AT ALL DOOR AND WINDOW JAMBS. 5. FOR SIZES OF MARKERBOARDS AND TACK BOARDS RE: SPECIFICATION SECTION DIVISION 10 - VISUAL DISPLAY SURFACES. LENGTH IS INDICATED ON FLOOR PLANS. 6. AT WARDROBE/TV CASEWORK, REFER TO EACH ROOM AS TO VERIFY DOOR SWING LOCATION. 7. RE: SHEETS _______ FOR BUILDING OCCUPANCY PLANS AND FIRE RESISTIVE CONSTRUCTION REQUIREMENTS. 8. SEE ENLARGED PLANS FOR ADDITIONAL WALL TYPES. 9. FOR GLAZING RECEIVING WINDOW TREATMENTS, COORDINATE WITH SPECIFICATION SECTION DIVISION 12 - HORIZONTAL LOUVER BLINDS.

10. FOR WALLS NOT DESIGNATED WITH A WALL TYPE, COORDINATE WITH

STRUCTURAL DRAWINGS & WALL SECTIONS. GENERAL NOTES STEEL STUD WALL AND GYPSUM BOARD WALL. RE: WALL TYPES. CONCRETE MASONRY UNIT (CMU) WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS, COORDINATE WITH STRUCTURAL DRAWINGS. CONCRETE WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. MASONRY VENEER. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. 1 XXXx XXXXXXX FLOOR DRAIN. COORDINATE WITH PLUMBING DRAWINGS. FIRE EXTINGUISHER CABINET. RE: DIVISION 10 - SPECIALTIES 10 AND SHEET XXXXX WINDOW TYPE, RE: WINDOW FRAME TYPE SHEETS, SHEET XXXX WALL TYPE, RE: SHEET XXXX DOOR SYMBOL, RE: DOOR SCHEDULE, SHEET XXXX TOILET AND BATH ACCESSORY, RE: SHEET XXXX XXX LEGEND FD 2487 SF THEATER SEATING 142 1118 SF THEATER STAGE 141 1467 SF BLACK BOX 150 916 SF PROP ROOM 149 83 SF TICKET BOOTH 155 306 SF MAKE-UP 146 171 SF BOYS DRESSING 148 72 SF ELECTRICAL 156 1495 SF LOBBY 157 953 SF MEDIA CENTER / LIBRARY / CIRCULATION 121 171 SF GIRLS DRESSING 147 475 SF CORRIDOR 232 324 SF CORRIDOR 233 P r o j e c t : S h e e t : P r o j e c t N o : D r a w n B y : C h e c k e d B y : D a t e : R e v i s i o n s : "THESE RECORD DRAWINGS HAVE BEEN PREPARED, IN PART, ON THE BASIS OF INFORMATION COMPILED AND FURNISHED BY OTHERS. THEREFORE, THE ARCHITECT AND OTHER DESIGN CONSULTANTS INVOLVED IN THIS PROJECT SHALL NOT BE RESPONSIBLE FOR ANY ERRORS OR OMISSIONS WHICH HAVE BEEN INCORPORATED INTO THESE DOCUMENTS AS A RESULT OF DOCUMENTS AND/OR INFORMATION PROVIDED FROM OTHER SOURCES." RECORD DRAWINGS E D C B A WEST ADA SCHOOL DISTRICT TBD Central Dr. Meridian, ID 83642 LEVEL 01 - FLOOR PLAN 19008 Author Checker 12/10/2019 PROGRAMMING REFERENCE NOTES AREA B AREA A

PHASE 2|1ST FLOOR PLAN

SLIDE 13 UP UP UP 1. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO THE FACE OF STUDS FOR GWB WALLS / PARTITIONS. 2. UNLESS NOTED OTHERWISE, ALL DIMENSIONS ARE TO FACE OF FINISHED MASONRY FOR CMU. 3. FOR FLOOR FINISHES RE: ROOM FINISH SCHEDULE, SHEETS _______ AND FINISH PLANS, SHEETS ________. 4. UNLESS NOTED OTHERWISE ALL GWB WALLS SHALL HAVE A 6" STUD FRAME RETURN AT ALL DOOR AND WINDOW JAMBS. 5. FOR SIZES OF MARKERBOARDS AND TACK BOARDS RE: SPECIFICATION SECTION DIVISION 10 - VISUAL DISPLAY SURFACES. LENGTH IS INDICATED ON FLOOR PLANS. 6. AT WARDROBE/TV CASEWORK, REFER TO EACH ROOM AS TO VERIFY DOOR SWING LOCATION. 7. RE: SHEETS _______ FOR BUILDING OCCUPANCY PLANS AND FIRE RESISTIVE CONSTRUCTION REQUIREMENTS. 8. SEE ENLARGED PLANS FOR ADDITIONAL WALL TYPES. 9. FOR GLAZING RECEIVING WINDOW TREATMENTS, COORDINATE WITH SPECIFICATION SECTION DIVISION 12 - HORIZONTAL LOUVER BLINDS.

10. FOR WALLS NOT DESIGNATED WITH A WALL TYPE, COORDINATE WITH

STRUCTURAL DRAWINGS & WALL SECTIONS. GENERAL NOTES STEEL STUD WALL AND GYPSUM BOARD WALL. RE: WALL TYPES. CONCRETE MASONRY UNIT (CMU) WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS, COORDINATE WITH STRUCTURAL DRAWINGS. CONCRETE WALL. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. MASONRY VENEER. RE: WALL SECTIONS, WALL TYPES, EXTERIOR & INTERIOR ELEVATIONS. COORDINATE WITH STRUCTURAL DRAWINGS. 1 XXXx XXXXXXX FLOOR DRAIN. COORDINATE WITH PLUMBING DRAWINGS. FIRE EXTINGUISHER CABINET. RE: DIVISION 10 - SPECIALTIES 10 AND SHEET XXXXX WINDOW TYPE, RE: WINDOW FRAME TYPE SHEETS, SHEET XXXX WALL TYPE, RE: SHEET XXXX DOOR SYMBOL, RE: DOOR SCHEDULE, SHEET XXXX TOILET AND BATH ACCESSORY, RE: SHEET XXXX XXX LEGEND FD 1353 SF UPPER THEATRE SEATING 217 672 SF MEZZANINE 230 892 SF CLASSROOM 229 892 SF CLASSROOM 228 237 SF CONTROL BOOTH 231 P r o j e c t : S h e e t : P r o j e c t N o : D r a w n B y : C h e c k e d B y : D a t e : R e v i s i o n s : S h e e t N o : "THESE RECORD DRAWINGS HAVE BEEN PREPARED, IN PART, ON THE BASIS OF INFORMATION COMPILED AND FURNISHED BY OTHERS. THEREFORE, THE ARCHITECT AND OTHER DESIGN CONSULTANTS INVOLVED IN THIS PROJECT SHALL NOT BE RESPONSIBLE FOR ANY ERRORS OR OMISSIONS WHICH HAVE BEEN INCORPORATED INTO THESE DOCUMENTS AS A RESULT OF DOCUMENTS AND/OR INFORMATION PROVIDED FROM OTHER SOURCES." RECORD DRAWINGS E D C B A WEST ADA SCHOOL DISTRICT TBD Central Dr. Meridian, ID 83642 LEVEL 02 - FLOOR PLAN 19008 Author Checker 12/10/2019 PROGRAMMING REFERENCE NOTES AREA B AREA A TH

PHASE 2 | 2ND FLOOR PLAN

SLIDE 14

= = = = = = = = = =

EXTERIOR SKIN CONCEPT

SLIDE 15

“ARCHITECTURE IS FROZEN MUSIC”

JOHANN WOLFGANG VON GOETHE

SLIDE 16

WEST ELEVATION NORTH ELEVATION

SLIDE 17

EAST ELEVATION SOUTH ELEVATION

SLIDE 18

SLIDE 19

SLIDE 20

SLIDE 21
