HMSE Implementation: Models, Mockups, and Prototypes

2

Users, Operators, Subject Matter Experts

A User-Centered Human-Machine Systems Engineering Process

Needs, Problems, Opportunities Operation,Test & Evaluation Analysis Design Implementation Design Specifications Requirements HMS: Humans, Machines, Processes

(Model, Mockup, Prototype, Product) HFE Principles & Guidelines

3

Implementation and Operation

• Implementation

–

Static Mockups

–

Dynamic Mockups

–

Digital Storyboards

–

Virtual Prototypes

–

Part-Functional Prototypes

–

Functional (Engineering) Prototypes

–

Computer Models and Simulations

–

Operational Systems

• Operation

–

Mockups, Storyboards

• Scripted Role Playing

–

Prototypes

• Simulated Scenarios

–

Computer Models

• Simulation

–

Operational Systems

• Real Operation

Static Mockups

5

Mockup: Healthcare Toolkit Instrument Set

Third Generation Unified Medical Instrument Mockup

7

Mockups: Silicon wafer slicing saw

8

Mockup framework

9

Mockup exterior construction

10

Mockup large features

11

Mockup operator interface

Dynamic Mockups

13

Mockup display/control details

Digital Storyboards

15

Mockup/Electronic Storyboard: Healthcare Toolkit

16

Mockup/Electronic Storyboard: Healthcare Toolkit

17

ECD Prototype 4 Storyboard

Virtual (Part-Functional) Prototypes

19

Virtual Prototype (HTML): DVD- VHS Player

20

Virtual Prototype: Electronic Checklist

• Full-scale physical

mockup (from rapid prototyping machine)

• Simulator (MS Access

database)

21

Virtual/Part-Functional Prototype: Healthcare Toolkit V1

Part-Functional Prototypes

• and Rapid Prototyping Systems

Human Factors Engineering 23

Mockup and Functional Prototypes: Healthcare Toolkit Unified Medical Instrument

iPad Diagnosis Decision Aid (MS Thesis) UMI Functional Prototypes (Capstone Projects)

First Generation Second Generation

Rapid Prototyping Environment For Targeting Device UI Development

Graphical User Interface Development Environment:

GUIDE

24

Gen 3 TD Emulator

Functional Prototypes

26

Functional Prototype: ECD Facilitator V3

Computer Models and Simulations

28

Computer Models: Digital Human Modeling

Examples from Dr. Onan Demirel

OSU Assistant Professor, Mechanical Design

INTEGRATED COCKPIT DESIGN

AN INTEGRATED OCCUPANT PACKAGING STUDY FOR A RACE CAR

A.1

pg.5

TRANSPORTATION

Focus: to incorporate Digital Human Modeling (DHM) early stages of the vehicle development and to improve driver posture comfort (in terms of joint angles and vision) without sacrifjcing structural integrity. Methodology: consist of using my Human-in-The-Loop design framework for modeling and simulation, and utilize Virtual Reality (VR) tools to extend the advance visualization techniques during design process. Results: joint angle discomfort were improved while maintaining the aerodynamics and structural integrity of the vehicle. Center of gravity was further lowered. Future Work: includes a total-vehicle integration design study, which aims to form a high fjdelity digital vehicle design system that manages and monitors engine simulation, steering controls, suspensions with DHM. Posture Improvement Study Based on Joint Angles through DHM Assembly Simulation in Virtual Reality with CAVE Integrated CAD Model with DHM Integrated CFD with DHM

INITIAL POSTURE IMPROVED POSTURE

Y ellow indicates posture angles out of comfort range Green indicates posture angles are within comfort range

Industrial Engineering Form Concept Function Proof About: This study was held as an integrated concept vehicle development research project at European Ford Design Studios. I was asked to demonstrate an integration showcase of Digital Human Modeling (DHM) and Virtual Reality (VR) for a concept vehicle development.

VERSATILE CODE CART

A REVERSE ENGINEERING OF AN EMERGENCY CODE CART

A.2

pg.6

HEALTHCARE

.5

Patent Pending Unique Features Biomechanical Simulation of Push-Pull Movement (Strain Forces & Vision)

Nominal Static Strenght results (average strain forces applied on body corresponding segments) Good Static Strenght results (low strain forces applied on body corresponding segments) Poor Static Strenght results (high strain forces applied on body corresponding segments)

INITIAL PUSH POSTURE

(CURRENT CART MODEL)

IMPROVED PUSH POSTURE

(PROPOSED CART MODEL)

Current cart model creates cluttered vision Proposed cart model eleminates cluttering problem Bi-Drectional (Dual-Way) Drawers with T ranslucent Faces Adjustable Handles Rear Section Frontal Section

Engineering Function Proof About: This study was a collaboration between Purdue University and Franciscan St. Elizabeth. I was asked to design a user-friendly, safe, lightweight and versatile code cart, which replaces current cart models, and would accommodate nurses coming from different anthropometric backgrounds. Industrial Form Concept Focus: to create a user-friendly, light-weight, easy to use and a safe code cart to accommodate needs and limitations of nurses coming from different anthropometric backgrounds. Methodology: creating human-machine-interaction simulations for patent pending unique features (such as bi-directional drawers, adjustable handles...etc.) through my Human-in-The-Loop design framework. Results: percent capable summary of upper and lower limbs were improved and visual obscuration (cluttler) zones were cleared. Proposed cart model accomodates a wide range of nurses comparing to current models. Future Work: fjnalizing patent application, developing marketing/sales plans and creating manufacturing drafts for a possible large scale production opportunity.

USER-FRIENDLY WASH-MACHINE A STUDY OF DESIGNING FOR HUMAN VARIABILITY A.3

pg.7

CONSUMER GOODS

Focus: to improve posture when loading-unloading of clothes of user groups coming from a wide-range of anthropometric population by utilizing Digital Human Modeling (DHM) during product development cycle. Methodology: to generate digital postures based on user study (data collection) and develop human- machine simulations by using Human-in-the-Loop design framework to fjnd optimized geometry. Results: door inlet size was increased for ease of access, pedestal height was optimized for different users, and

• verall dimensions of the wash-machine was fjnalized.

Future Work: to develop future wash-machines that accommodate different needs and offer comforting features for users. Digital Posture Construction from Usability Study Comparison between Design Alternatives Inlet Door Validation through DHM

INITIAL REACH POSTURE

(NO PEDESTAL)

IMPROVED REACH POSTURE

(WITH PEDEST AL)

Industrial Engineering Form Concept Function Proof About: This consumer product design study was a collaboration between Whirlpool Corporation and Purdue University. I was asked to design a “wash-machine for all” around the requirements generated from consumer studies and technology integration.

29

Computer Models: MIDAS

• Man-machine Integration Design and Analysis System
• Workstation-based simulation system developed by the

U.S. Army, NASA, and Sterling Software Inc.

• Used to evaluate candidate crew procedures, controls,

and displays before changes become too costly.

• Capabilities

–

graphical equipment prototyping

–

dynamic simulation

–

human performance modeling

• kinematic
• sensory
• memory, cognition
• motor
• Applications

–

Air Warrior - 21st Century air crew life support system

–

Air MIDAS - assessment of flight management systems, communication, and automation in Air Traffic Control (ATC) aiding

–

Short Haul Civil Tiltrotor - crewstation in new vertical takeoff and landing vehicle

–

Taxi MIDAS - Preflight Checklist Study (Boeing 747 - 400)

–

911 MIDAS - Emergency Dispatch Console Design Study

• Website: http://humansystems.arc.nasa.gov/groups/midas/index.html
• Air Warrior: http://humansystems.arc.nasa.gov/groups/midas/application/airwarrior.html
• Air MIDAS: http://humansystems.arc.nasa.gov/groups/midas/application/taximidas.html
