SLIDE 1

Hit Width vs. Extraction Field

Aidan Medcalf University of Dallas Oct 13, 2018

slide-2
SLIDE 2

Data and MC

  • Four extraction fields (see right)
  • Used 2018_August_24, MCB1 MuonsCN
  • Cuts:
  • Highway, CBR of 0.15 (no highway on MC)
  • 90 cm crossed in drift direction
  • Corner LEMs ignored
  • Individual average waveforms were

found for representative tracks with desirable angles

1

Extraction Field Data Run MCB 1.04 1192 Extr104 1.52 1175 Extr152 1.7 840 MuonsCN 2.08 838 Extr208

slide-3
SLIDE 3

Average Hit Widths

slide-4
SLIDE 4

Average Hit Widths, Data/MC Ratio

1.49 1.31

slide-5
SLIDE 5

Average Hit Widths, 2.08 kV/cm

Run 838

slide-6
SLIDE 6

Average Hit Widths, 1.7 kV/cm

Run 840

slide-7
SLIDE 7

Average Hit Widths, 1.52 kV/cm

Run 1157

slide-8
SLIDE 8

Average Hit Widths, 1.04 kV/cm

Run 1192

slide-9
SLIDE 9

Representative Waveforms, 1.7 kV/cm

Run 840

slide-10
SLIDE 10

Representative Waveforms, 2.08 kV/cm

Run 838

slide-11
SLIDE 11

Results

  • MC seems to match data well for high extraction fields, to within a

multiplicative constant

  • MC is wrong for low extraction fields

Extraction Field Data Mean MC Mean Data/MC Ratio View 0 View 1 View 0 View 1 View 0 View 1 1.04 37.1 36.6 12.3 6.26 3.01 5.84 1.52 18.6 17.2 11.2 5.84 1.66 2.96 1.7 16.9 7.29 10.8 5.63 1.64 1.36 2.08 16.1 7.38 10.3 5.36 1.49 1.31
