Hilltop Tacoma Link Extension

System Expansion Committee

06/11/2020

2

Why we are here

Hilltop Tacoma Link Extension Update

• Information only briefing of current project status

Today’s Proposed Board Actions

• To inform the System Expansion Committee for

recommendations to Board to increase the project budget and increase contingency for construction and professional services contracts

3

Today’s Presentation

• Project Overview
• Financial Snapshot
• Risk and Contingency Management
• Schedule
• Construction Work Underway
• Community Outreach
• Issues and Challenges
• Lessons Learned
• Questions

4

Hilltop Tacoma Link Extension (HTLE)

Project Overview

• 2.4 mile extension
• Seven new station platforms
• Five new vehicles
• Operations and Maintenance

Facility expansion

• Revenue Service Date: May 2022

5

Current HTLE Financial Snapshot

• Financials as of April 2020
• Project baselined in September 2017
• Year of Expenditure dollars
• Trends indicate the baseline budget of $217.3M requires a

supplement to address updated estimate at completion. Project Baseline Budget $217.3 Committed $202.7 Incurred $118.6

93% 55%

6

HTLE Risk and Contingency Management

May 2019

• Quantitative Risk Assessment

 20% likelihood of meeting project budget  80% likelihood of meeting revenue service date  Contingency forecast – minimum level by Q3 2019

September 2019

• Minimum contingency level reached

 Develop Recovery Plan

7

HTLE Risk and Contingency Management

October 2019

• Quantitative Risk Assessment/Recovery Workshop

Contractor and City of Tacoma stakeholders  Developed Recovery Plan

December 2019

• ST Board briefing and construction contract contingency

increase

April 2020

• Quantitative Risk Assessment
• Update estimate at completion
• Plan for Q1 quantitative risk assessment

8

Schedule

2018 2020 2022

City of Tacoma Pre-construction utility relocations

Sound Transit

Heavy utility work OMF construction Civil and systems construction** System testing and pre-revenue service Construction includes: *Water main, sanitary and storm sewer relocations and new water service connections. **Operations and Maintenance Facility, stations, artwork, track, traction power substations, contact system poles, signalized intersections and repaved roadway.

9

Construction Headings (Work Zones)

• Heading 1 – Commerce St./Stadium Way to Division

Ave.

• Heading 2 – Stadium District
• 2A – Stadium High School
• 2B – N. Tacoma Ave./N. 1st to Division/MLK
• Heading 3 – MLK/Division to MLK/S. 19th
• Operations and Maintenance Facility Expansion

10

Heading 1

9th/Commerce to Stadium Way/Division Avenue

11

Heading 2 – Stadium District

Stadium High School to Division Ave./MLK

12

Heading 3 - Hilltop District

MLK/Division Street to MLK/S.19th

13

Operations and Maintenance Facility

• E. 25th Street

14

Community Outreach

• During COVID-19:

virtual meetings, email, phone, mailed notification, social media, weekly construction alerts to about 5,000 subscribers

• Before COVID-19: more in-person

activities -- business visits, stakeholder briefings, community meetings, and events

• Collaborate with partners
• Coordinate access and signage
• Respond to questions and issues

15

Key Issues and Challenges

• Maintaining a high level of safety

awareness and accident prevention

• Tight budget and limited contingency
• Potential construction contract claims
• Stakeholder and neighborhood impacts during

construction

• Unidentified utilities/differing site conditions
• Public outreach during construction
• Impacts to operations - cutovers

16

Lessons Learned

For at-grade construction in City ROW, the agency should consider: Design

• Update Agency engineering procedures to include prescriptive

requirements for subsurface investigations during planning and design Construction

• Contract delivery method – allocation of risk
• Consider shared risk on third party utility relocation
• Consider the use of incentives to reduce impacts to the

community and/or improve schedule performance

• Ensure adequate contingencies

Today’s Proposed Board Actions

18

Proposed Board Actions

• Resolution No. R2020-12 – Amending the Adopted

2020 Budget by increasing the baseline budget by $35,400,000

19

Hilltop Tacoma Link Extension: Baseline Budget: $217.3M

ALLOCATION $ COMMITMENTS

$217.35M Project Development

Illustrative - Not to Scale

Approved Today’s Action Future Action

Construction

20

Hilltop Tacoma Link Extension: Board approves $35.4M for increase in baseline budget

ALLOCATION $ COMMITMENTS

$252.75M Project Dev.

Illustrative - Not to Scale

Approved Today’s Action Future Action

Construction

21

Proposed Board Actions

• Motion No. M2020-31 – Increase the construction contract

contingency in the amount of $27,400,000

• Motion No. M2020-32 – Increase contract contingency for

design services during construction in the amount of $1,000,000

• Motion No. M2020-33 – Increase the contract contingency for

construction management consultant services in the amount of $2,070,000

• Motion No. M2020-34 – Execute a planned contract modification

for Tacoma Link LRV engineering and inspection consultant services in the amount of $1,997,814

22

Hilltop Tacoma Link Extension: Baseline Budget: $252.7M

ALLOCATION $ COMMITMENTS

$252.7M Project Dev.

Illustrative - Not to Scale

Approved Today’s Action Future Action

Construction

23

Hilltop Tacoma Link Extension: Board approves Motion No. 31 through Motion No. 34

ALLOCATION $ COMMITMENTS

$252.7M Project Dev.

Illustrative - Not to Scale

Approved Today’s Action Future Action

Construction

24

Link Light Rail Portfolio

Project Name Project Budget (in millions) Project % Complete Projected Budget Surplus (in millions) Northgate Link $1,899.8 94.9% $52.5 plus project reserve of $50 Hilltop Tacoma Link $217.3 55.8%

• $35.4

East Link $3,677.2 78.2% Trending below budget Lynnwood Link Federal Way Link Downtown Redmond Link $6,753.1 Too early to project OMF East $449.2 83.6% Trending below budget Other Projects at or Near Completion Surplus varies by project

Thank you.
