HERO: Open-Source Heterogeneous Embedded Research Platform for - - PowerPoint PPT Presentation
HERO: Open-Source Heterogeneous Embedded Research Platform for Exploring RISC-V Manycore Architectures on FPGA First Workshop on Computer Architecture Research with RISC-V (CARRV) @ MICRO 50 2017-10-14 Andreas Kurth Pirmin Vogel Alessandro
First Workshop on Computer Architecture Research with RISC-V (CARRV) @ MICRO 50
2017-10-14
Andreas Kurth Pirmin Vogel Alessandro Capotondi Andrea Marongiu Luca Benini
Integrated Systems Laboratory Digital Circuits and Systems Group
I/O
Die shot of an Apple A11 SoC (Source: chipworks). Architectural template of HESoCs.
HESoCs co-integrate a general-purpose host processor and efficient, domain-specific programmable manycore accelerators (PMCAs). They combine versatility with extreme nominal energy efficiency. While industry rapidly advances products, ...
1 / 20
... research on HESoCs lags behind!
I/O
Architectural template of HESoCs.
There are many open questions in various areas of computer engineering: programming models, task distribution and scheduling, memory organization, communication, synchronization, accelerator architectures and granularity, ... But there is no research platform for HESoCs!
2 / 20
Developing HESoC components in isolation and estimating their system-level performance is problematic: Complex interactions between host, accelerators, and memory hierarchy make (reasonably accurate) simulations orders of magnitude slower than running prototypes. Even full-system simulators (e.g., GEM5) do not model all HESoC components. Models make assumptions about non-deterministic processes. The validity of results thus entirely depends on the validity of assumptions, and the assumptions for modeling HESoCs are very complex.
Conclusion: A research platform for HESoCs must be available.
This is not only about hardware: For system-level research, the platform must be efficiently programmable. Additionally, the platform should come with tools to increase the observability and decrease the validation and implementation overhead of the prototype.
3 / 20
Heterogeneous Hardware Architecture
TLX-400SoC Bus
MailboxL2 Mem X-Bar Interconnect Cluster Bus DMA
L1 SPM Bank M-1RISC-V PE N-1 Shared L1 I$
DEMUXCluster 0
L1 MemCluster 1
L1 MemCluster L-1
L1 Mem DEMUX DEMUX L1 SPM Bank 0 L1 SPM Bank 1 L1 SPM Bank 2RISC-V PE 1 RISC-V PE 0 Peripheral Bus
TRYX Per2AXI AXI2Per Timer Event Unit TRYX TRYXRAB L2 $
L1 I$ L1 D$MMU Coherent Interconnect
L1 I$ L1 D$MMU A57 Core 0 A57 Core 1 L2 $ Coherent Interconnect
L1 I$ L1 D$ MMU A53 Core 0 L1 I$ L1 D$ MMU A53 Core 1 L1 I$ L1 D$ MMU A53 Core 2 L1 I$ L1 D$ MMU A53 Core 3Coherent Interconnect DDR DRAM
TLX-400ARM Juno SoC
TLX-400 TLX-400 ACE-LiteHost PMCA
Shared APU
Heterogeneous Sofware Stack single-source, single-binary cross compilation toolchain OpenMP 4.5 shared virtual memory for Host and PMCA
Host Linux Kernel RTE LIB Driver OpenMP RTE Heterogeneous Application PMCA Hardware Kernel Level User Level Offloaded Kernel OpenMP RTE RTE VMM LIB
Profiling and automated verification solutions
4 / 20
TLX-400
SoC Bus
Mailbox
L2 Mem X-Bar Interconnect Cluster Bus DMA
L1 SPM Bank M-1
RISC-V PE N-1 Shared L1 I$
DEMUX
Cluster 0
L1 Mem
Cluster 1
L1 Mem
Cluster L-1
L1 Mem DEMUX DEMUX L1 SPM Bank 0 L1 SPM Bank 1 L1 SPM Bank 2
RISC-V PE 1 RISC-V PE 0 Peripheral Bus
TRYX Per2AXI AXI2Per Timer Event Unit TRYX TRYX
RAB L2 $
L1 I$ L1 D$
MMU Coherent Interconnect
L1 I$ L1 D$
MMU A57 Core 0 A57 Core 1 L2 $ Coherent Interconnect
L1 I$ L1 D$MMU A53 Core 0
L1 I$ L1 D$MMU A53 Core 1
L1 I$ L1 D$MMU A53 Core 2
L1 I$ L1 D$MMU A53 Core 3
Coherent Interconnect DDR DRAM
TLX-400
ARM Juno SoC
TLX-400 TLX-400 ACE-Lite
Host PMCA
Shared APU
industry-standard, hard-macro ARM Cortex-A Host processor scalable, configurable, modifiable FPGA implementation
shared main DRAM low-latency interconnect, which offers coherency to host caches HERO’s hardware, as implemented on the Juno ADP.
5 / 20
TLX-400
SoC Bus
Mailbox
L2 Mem Cluster 0
L1 Mem
Cluster 1
L1 Mem
Cluster L-1
L1 Mem
RAB
TLX-400
SoC Bus
Mailbox
L2 Mem Cluster 0
L1 Mem
Cluster 1
L1 Mem
Cluster L-1
L1 Mem
RAB X-Bar Interconnect Cluster Bus DMA
L1 SPM Bank M-1
RISC-V PE N-1 Shared L1 I$
L1 SPM Bank 0 L1 SPM Bank 1 L1 SPM Bank 2
RISC-V PE 1 RISC-V PE 0 Peripheral Bus
TRYX Per2AXI AXI2Per Timer Event Unit TRYX TRYX
Shared APU
DEMUX DEMUX DEMUX
multi-cluster design to overcome scalability limitations multi-banked, sofware-managed scratchpad memories (SPMs) and multi-channel DMA engine instead of data caches RISC-V processing elements (PEs) and shared auxiliary processing units (APUs) operating on local data shared virtual memory access through the sofware-managed, lightweight Remapping Address Block (RAB) PMCA based on the PULP architectural template.
6 / 20
Configurable:
TLX-400
SoC Bus
Mailbox
L2 Mem Cluster 0
L1 Mem
Cluster 1
L1 Mem
Cluster L-1
L1 Mem
RAB X-Bar Interconnect Cluster Bus DMA
L1 SPM Bank M-1
RISC-V PE N-1 Shared L1 I$
L1 SPM Bank 0 L1 SPM Bank 1 L1 SPM Bank 2
RISC-V PE 1 RISC-V PE 0 Peripheral Bus
TRYX Per2AXI AXI2Per Timer Event Unit TRYX TRYX
Shared APU
DEMUX DEMUX DEMUX
# of clusters ∈ {1, 2, 4, 8} # of PEs
∈ {2, 4, 8}
FPU
∈ {private, shared (APU), off}
integer DSP unit
∈ {private, shared (APU)}
L1 SPM size and # of banks I$ design, size, # of banks L2 SPM size system-level interconnect topology RAB L1 TLB size and L2 TLB size, associativity, and # of banks
Modifiable and expandable: All components are open-source and written in industry-standard SystemVerilog. Interfaces are either standard (mostly AXI) or simple (e.g., stream-payload). New components can be easily added to the memory map.
7 / 20
0x1000 0000 0x1FFF FFFF
256 MiB of virtual addresses reserved for PMCA-internal usage Own Cluster
0x1B00 0000 0x1B3F FFFF
Tightly-Coupled Data Memory
0x1B00 0000
Peripherals
0x1B20 0000
Timer
0x1B20 0400
Clkgate Control
0x1B20 0900
Event Unit
0x1B40 4000
DMA Control
0x1B40 4400
SoC Peripherals
0x1A10 0000 0x1A1F FFFF
UART
0x1A10 2000
Standard I/O
0x1A11 0000
Mailbox
0x1A12 0000
RAB Configuration
0x1A13 0000
Remote Cluster 0
0x1000 0000 0x103F FFFF
Remote Cluster 1
0x1040 0000 0x107F FFFF
Remote Cluster n
0x1000 0000 +n*0x40 0000 0x103F FFFF +n*0x40 0000
L2 Memory
0x1C00 0000 0x1CFF FFFF
8 / 20
Allows to write programs that start on the host but seamlessly integrate the PMCAs.
Host Linux Kernel RTE LIB Driver OpenMP RTE Heterogeneous Application PMCA Hardware Kernel Level User Level Offloaded Kernel OpenMP RTE RTE VMM LIB
int main() { vertex vertices[N]; load(&vertices, N); #pragma omp target map(tofrom:vertices) { #pragma omp parallel for for (i = 0; i < N; ++i) vertices[i] = process(); } }
Offloads with OpenMP 4.5 target semantics, zero-copy (pointer passing) or copy-based Integrated cross-compilation and single-binary linkage PMCA-specific runtime environment and hardware abstraction libraries (HAL)
9 / 20
The libgomp plugin determines how input and output variables are passed between host and PMCA: With copy-based shared memory, data is copied to and from a physically contiguous, uncached section in main memory, and physical pointers are passed to the PMCA. Shared virtual memory enables zero-copy offloads, directly passing virtual pointers to the PMCA. Furthermore, the plugin implements essential OpenMP functionality such as
parallel (starting parallel execution) team (definition of parallel thread teams) sections (distributed, one-time execution worksharing) barrier (synchronization barrier) critical (single-threaded execution within a parallel region)
efficiently on the specific PMCA hardware.
10 / 20
The PMCA can access the page table of the heterogeneous user-space application, and can
Assume a core accesses a virtual address that is currently not in the RAB. That core goes to sleep and its miss is enqueued in the RAB. Another core handles the miss using the VMM library (details in the paper). The VMM library is compatible with any host architecture supported by the Linux kernel.
11 / 20
OpenMP offloading with the GCC toolchain requires a host compiler plus one target compiler for each PMCA ISA in the system.
riscv-none-gcc
cc1-lto ld
GCC
arm-linux-gnueabihf-gcc cc1 ld lto-wrapper pulp-mkoffload
.text .text.target._omp_fn.0 { ... } .gnu.offload_vars .gnu.offload_funcs
.gnu.offload_images
.text { ... } .gnu.offload_vars .gnu.offload_funcs .target._omp_fn.0
src.bin target.bin (ARM ISA) (RISC-V ISA)
PULP Syslibs libgomp HAL OpenMP Expansion
SSA SSA-opt1
. . .
ipa_write_passes
Details in: Capotondi et. al. 2017. Enabling zero-copy OpenMP offloading on the PULP many-core accelerator.
A target compiler requires both compiler extensions (e.g., additional compilation and
HERO includes the first non-commercial heterogeneous cross compilation toolchain.
12 / 20
Problem: Poor observability of implementation internals compared to simulation. Solution: Run-time event tracing and post-mortem analysis. Requirements on the tracer:
1
must not interfere with program execution
(e.g., inserting instructions to write memory is not an option),
2 must be cycle-accurate yet be able to trace millions of consecutive events
(to cover complex applications), and
3 should use FPGA resources economically (to not hamper the evaluation of complex hardware).
Hybrid tracer design: sofware-controlled, lightweight, customizable hardware blocks that ...
can use any signals in the fabric for data and trigger, log timestamped events to dedicated, local buffers, get flushed to main memory by the host while the PMCA is “frozen”.
Details are in the paper.
13 / 20
Input: Recorded events from tracers, e.g., memory transactions at the RAB (with meta information on source, read/write, and hit/miss):
timestamp address meta 4789575
0x00580384 (1, 7), R, M
4790083
0x00581d2c (1, 2), W, H
4790493
0x00580384 (1, 5), R, H
Example: Time sequence analysis of events
VM hardware: L1 TLB hit-under-miss behavior and L2 TLB latency VM sofware: Page table walk and TLB entry replacement
Example: Memory access pattern analysis
Two phases of a parallel graph processing algorithm are shown; different colors are different PEs.
1
First phase: Two linear traversals and sparse memory accesses in parallel.
2
Second phase: Single linear traversal.
virtual address time
14 / 20
Automated full-system builds and tests are a prerequisite for many effective development
combination is highly complex on HESoCs. Our solution is described in the paper.
change HDL of IP simulate unit test commit HDL change simulate all TBs build bitstreams for all targets check results and deploy bitstreams target platforms execute all (app., build conf., run param.) combinations
build all tests and benchmarks in all (platform- specific) configs. commit SW change compile and run individual tests change SW execute if failed if failed automated manual hardware-related sofware-related
15 / 20
Property ARM Juno (with a Xilinx Virtex-7 2000T) Xilinx Zynq ZC706 Host CPU 64-bit ARMv8 big.LITTLE 32-bit ARMv7 dual-core A9 Shared main memory 8 GiB DDR3L 1 GiB DDR3 PMCA clock frequency 31 MHz 57 MHz # of RISC-V PEs 64 in 8 clusters 8 in 1 cluster Integer DSP unit private per PE L1 SPM 256 KiB in 16 banks Instruction cache 8 KiB in 8 single-ported banks 4 KiB in 4 multi-ported banks
Slices used by clusters
80% 65%
Slices used by infrastructure
7% 12%
BRAMs used by clusters
89% 70%
BRAMs used by infrastructure
6% 13% Price 25 000 $ 2500 $
16 / 20
Benchmarking parallel execution and data transfers of the PMCA on the Juno ADP Matrix-matrix multiplication C = AB A and C are tiled row-wise over the clusters, and each row is parallelized block-wise over the PEs. Data is transferred with DMA bursts, and all PEs operate on data in local SPMs. baseline perfect linear speedup bottleneck interconnect
(NoC could be selected instead)
◮ HERO allows to make architectural choices based on measured results of benchmarks.
17 / 20
The main motivation for shared virtual memory (SVM) is programmability. However, SVM can also significantly improve performance! PageRank is a well-known algorithm for analyzing the connectivity of graphs.
The overhead of manipulating pointers at offload-time in copy-based offloading exceeds the run-time overhead of translating pointers with shared virtual memory. In this case, SVM reduces the run time by nearly 60 %.
Offload Kernel Execution Total 0.2 0.4 0.6 0.8 1 Normalized Run Time Copy-Based SM SVM
MemCopy simply copies a large array from DRAM to the PMCA and back, which is representative for streaming applications with little actual work.
Letting the host copy data to physically contiguous, uncached memory is much slower than letting the PMCA access data directly with high-bandwidth DMA transfers. In this case, SVM reduces the run time by more than 95 %.
Offload Kernel Execution Total 0.2 0.4 0.6 0.8 1 Normalized Run Time
◮ HERO allows to back research claims with reproducible, falsifiable implementation results.
18 / 20
HERO is the first open-source heterogeneous embedded research platform. It unites an ARM Cortex-A host processor with a fully modifiable RISC-V manycore implemented on an FPGA. HERO enables efficient hardware and sofware research on HESoCs through a heterogeneous sofware stack, which supports shared virtual memory and OpenMP 4.5—tremendously simplifying porting of standard benchmarks and real-world applications, and profiling and automated verification solutions. We have been successfully using HERO in our research over the last years and will continue its development as open-source hardware and sofware!
