Hermann Kolanoski Humboldt-Universitt zu Berlin and DESY Coll. Ljubljana, 16. 3. 2015 H.Kolanoski - IceCube Neutrino Observatory 1 What I want to tell you: What want to you Cosmic rays (CR) Cosmic rays (CR) How to measure cosmic

slide-1
SLIDE 1

Hermann Kolanoski Humboldt-Universität zu Berlin and DESY

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 1
slide-2
SLIDE 2

What I want to tell you:

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 2

– Cosmic rays (CR) – How to measure cosmic rays – What we know and don‘t know about CR – Neutrinos as messengers of cosmic accelerators – Neutrino Observatory IceCube – The IceCube Muppet Show .... – Do not talk about e.g. exotic searches (wimps, …)

What want to you

Cosmic rays (CR) measure cosmic rays know and don‘t know about CR

slide-3
SLIDE 3

Cosmic Rays

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 3

100 years after their discovery not yet understood Kernfragmente

ion pairs / (cm3 s)

Cosmic

100 years after their discovery not yet understood Viktor Hess 1912 5 km height faster discharge

  • f an electrometer

with increasing height interpreted due to radiation from space: “Höhenstrahlung”

slide-4
SLIDE 4

Zwicky’s proposal for the CR Origin

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 4

“Cosmic rays are caused by exploding stars which burn with a fire equal to 100 million suns and then shrivel from ½ million mile diameters to little spheres 14 miles thick.”, says Fritz Zwicky, Swiss Physicist. In Los Angeles Times, Jan. 1934

… since then we are trying to prove it

slide-5
SLIDE 5

Cosmic Ray Spectrum

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 5

LHC(p) LHC(pp)

~ 32 decades ~ 32 decades ⇒ very different detection methods very different detector sizes ~E-2.7

cut-off?

slide-6
SLIDE 6

Cosmic Ray Spectrum

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 6

LHC(p) LHC(pp)

~ 32 decades ~ 32 decades ⇒ very different detection methods very different detector sizes ~E-2.7

cut-off?

Where and how are the highest energies produced??? What is the elemental composition? Galactic and/or extragalactic?

slide-7
SLIDE 7
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 7

Extensive Air Showers

Use the atmosphere as calorimeter

slide-8
SLIDE 8

Air Shower Detectors

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 8

IceTop IceTop

distance 125 m size 1 km2 energies PeV – EeV

1 km2 3000 km2

Pierre Auger Observatory

distance 1500 m size 3000 km2 energies EeV – 100 EeV

slide-9
SLIDE 9

PeV to EeV

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 9

3.14 2.90 3.37 𝛿=2.65 The fine structure in the spectrum M.G. Aartsen et al, Physical Review D88 (2013) 042004!

𝐺 = 𝐹−𝛿

slide-10
SLIDE 10

Confinement in the Galaxy

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 10

O Fe H

10 kpc

B e z p R : Rigidity ρ = = CR in galaxy: mean lifetime 107 years Energy has to be refueled. Where, how?

Emax ~ Z ⇒ Emax (Fe) ≈ 26 Emax (H)

slide-11
SLIDE 11

Origin and Physics of the knee(s)

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 11

If the knee is due to the diffusion out of the galaxy we expect a change in composition towards heavier elements spectrum below the knee: well known by direct measurements; above the knee: indirect measurements via air showers, difficult p knee Fe knee

slide-12
SLIDE 12
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 12

Cosmic Ray Anisotropy

The orientation of the dipole moment does not correspond to the relative motion (~200 km/s) in the Galaxy (Compton-Getting effect) Diffusive transport in galactic magnetic field from nearby sources?

IceCube

17 TeV 5 TeV

slide-13
SLIDE 13

Energy Dependence of CR Anisotropy

13

Energy Dependence of CR Anisotropy Energy Dependence of CR Anisotropy

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory
  • Anisotropy changes in position, size
  • Above 400 TeV there’s indication of

an increase in strength.

17 TeV 41 TeV 75 TeV 140 TeV 240 TeV 590 TeV 1.2 PeV 4.5 PeV

slide-14
SLIDE 14

Large and Small Scale Anisotropies

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 14

diffusive transport from nearby sources?

  • bserved small scale (10°) structures ⇒ few pc distance
slide-15
SLIDE 15 15
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory

UHECR Results

cut-off at 1020 eV definitely observed

Cen A

28/84 = 33% isotropic background = 21% ➙ <1 % chance probability direction correlation with AGN?

Auger Observatory

GZK or source power limited?

(GZK = Greisen-Zatsepin-Kuzmin)

slide-16
SLIDE 16
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 16

CMB 2.7 K → threshold Ep ≈ 4×1019 eV “GZK horizon” ~160 Mly

Cosmic Rays, CMB Photons and Neutrinos

Cosmic Microwave Background (CMB): perfect blackbody at 2.74 K

slide-17
SLIDE 17

Nature of the Cutoff?

17

Is this the “GZK cutoff”? Energy loss by collison with CMB photons? Or do accelerators run out of steam? ⇒ composition becomes heavier  Fe

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory

Auger: Xmax with florescence detectors

data suggest change of composition from light to heavy Not GZK cutoff?

Clarification from other messengers? Are there GZK neutrinos?

slide-18
SLIDE 18

Where could particles possibly be accelerated? Hillas diagram

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 18

supernova remnants (SNR) gamma ray bursts (GRB) active galactic nuclei (AGN) black holes Emax ≈ 1018 eV z βs (L / kpc) (B / μG)

B L

slide-19
SLIDE 19

Cosmic Accelerators

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 19

Supernova Remnants (SNR)

Crab Nebula (explosion 1054)

Fermi acceleration at shock front 1 % of the energy of all SN explosions can explain energy density of cosmic rays in galaxy (~ 0.5 MeV/m3) However: No SNR has been clearly pinned down as source

slide-20
SLIDE 20
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 20

Charged Particle

Twisted and Straight Paths

slide-21
SLIDE 21

Absorption of γ‘s by γ γ -> e+e-

e+ e- γ γ

γγ

σ

s

e

m 2

s 1 ~

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 21

I know! I did γ γ → hadrons

slide-22
SLIDE 22

Cosmic Rays, Gammas and Neutrinos

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 22

target accelerator CR – ν connection the γ – ν connection for hadron accelerators ν spectrum ~ E-2 assumed

p

target ν ν ν

μ

±

π±

γ γ

π0

CR – γ connection

slide-23
SLIDE 23

Neutrino fluxes

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 23

Cosmic neutrinos should have a hard spectrum

F ~ E-2

atmospheric ν F ~ E-3.7

E-3.7 E-2

slide-24
SLIDE 24

How to detect cosmic high energy neutrinos?

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 24

quite difficult

⇒large target volume Most efficient: Cherenkov light from charged ν products ⇒ transparent ⇒water or ice

Lake Baikal Mediterranean Sea Absorption small  detection probability small

slide-25
SLIDE 25

Amundsen – Scott Station

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 25
slide-26
SLIDE 26

Approaching the Pole these Days

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 26
slide-27
SLIDE 27
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 27
slide-28
SLIDE 28

Arriving at Pole

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 28
slide-29
SLIDE 29

IceCube Neutrino Observatory

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 29

1000 m

  • 86 Strings, 2450 m deep
  • 5160 Optical Modules
  • Instrumented: 1 km3
  • IceTop: 1 km2
  • Installation: 2005-2011

IceCube DeepCore IceTop

air shower array neutrino telescope

slide-30
SLIDE 30

The Drill Camp

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 30
slide-31
SLIDE 31

…. 2450 m deep

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 31
slide-32
SLIDE 32

.. what you see down there

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 32
slide-33
SLIDE 33

When the Season is over

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 33
slide-34
SLIDE 34

The Last Flight at the End of the Season

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 34
slide-35
SLIDE 35
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 35
slide-36
SLIDE 36

Detection of High Energy Neutrinos

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 36

extraterr. Neutrinos atmosph. Muons

Earth as filter

atmosph. Neutrinos

νµ

µ

km Energy

MeV GeV TeV PeV EeV ZeV Earth diameter

1012 102 104 106 108 1010

νµ +N→ µ + X

1 lightyear Radius Earth orbit

mean free path even for neutrinos the Earth becomes opaque above about 1 PeV ⇒ look upward – atm. background becomes less

density of Universe 10-23 × ρ(H2O)

slide-37
SLIDE 37

Detecting a Neutrino

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 37
slide-38
SLIDE 38
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 38
slide-39
SLIDE 39

Particle Signatures

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 39
  • muon tracks
  • em + had. shower

CR shower in IceTop µ bundle up-going νµ → point sources ν

µ

µ νe cascade → all flavours ν

e

µ background & physics W± l± νl N X CC Z0 νl νl N X NC

slide-40
SLIDE 40

Search for Diffuse Astrophysical Neutrino Flux Background: Atmospheric Neutrinos

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 40

~ 100,000 events per year “prompt” ν’s: from (semi-) leptonic decays of heavy hadrons (mainly charm). Flatter spectrum than “conventional” ν’s ⇒ large uncertainty for astro-ν’s IceCube has now constrained to ~ ERS model (Enberg et al.) E-2 astrophysical?

slide-41
SLIDE 41
  • Atmos. ν’s: background for one – Signal for the other

Neutrino Oscillation

41

Detector

Atmospheric Neutrinos

Different direction = different pass length νμ disappearence Survival probability in the 2ν scheme Eν ≈ 10 – 100 GeV in DeepCore

slide-42
SLIDE 42

Neutrino Oscillation

42

Disappearance atmospheric νμ with 3 years of data (for the normal hierarchy): sin2(θ23) = |∆m232| = ) =

arXiv:1410.7227 Ultimate goal: measure mass hierarchy with a densely instrumented extension: PINGU

slide-43
SLIDE 43

Search for Pointsources: The Method

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 43

Source background ≈ 2° - 3°

background: atmospheric ν Search for event excess within 2° - 3°

  • somewhere in the Northern sky
  • from list of candidate sources

4282 events (small sample)

slide-44
SLIDE 44

The Statistics Problem

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 44

If you search long enough you will for sure get an excess at some point “I only believe in statistics that I doctored myself”

Winston Churchill

Example: Expect 3 events background in a search window, but see 7. How significant is this?

0.05 0.1 0.15 0.2 0.25 1 2 3 4 5 6 7 8 9 10

w(n>6) = 3,3 % <n> = 3

Already for about 30 search windows the probability to see 7 or more events in any window is about 60% for background only. Significance is determined by ~10000-fold simulation of measurement

slide-45
SLIDE 45 45

Hottest spot in South: p-value* ≈ 10-6 (pre-trial) Ra: 296.95 Dec: -75.75 Ns=16.16 γ =2.34 p-value* ~ 9.3% (post-trial)

*p-value for background only
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory

Point Source Search 2008-2011

IC86+79+59+49

slide-46
SLIDE 46

Improving Statistical Significance

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 46
  • pre-defined source positions
  • pre-defined time-window
  • „stacking“ of pre-defined sources

„Pre-Definition“ with „multi-messenger“ information of

  • ptical, gamma, X-ray, radio telescopes …
slide-47
SLIDE 47
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 47
  • Intense flashes of gamma rays
  • Duration some seconds
  • highly-relativistic jet (‘fireball’)

Search for neutrinos which are in time and direction consistent with GRB

GCN: The Gamma-ray Coordinates Network

slide-48
SLIDE 48

Are GRBs the main sources of Cosmic Rays?

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 48

225 GRB ... no coincidences observed Standard Fireball Models excluded [Nature 484 (2012) 351]

slide-49
SLIDE 49

Extremly High Energy (EHE) Neutrinos

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 49

threshold ~ 5 × 1019 eV

GZK

Search for high number of Cherenkov photons = NPE θ = zenith angle Search region up-going down-going upward downward

slide-50
SLIDE 50

Search for cosmogenic neutrinos with 2010-2012 data.

  • Two shower type events found in 616 days of IceCube observations.
  • Neutrino energies could be higher than deposited energies, if neutral

current interaction.

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 50
  • Aug. 8, 2011

1.04 ± 0.14 PeV

  • Jan. 3, 2012

1.14 ± 0.14 PeV

deposited energies

slide-51
SLIDE 51

The Muppet Show

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 51

A detection of 1 neutrino is interesting … 2 is evidence … … and 3 is a spectrum!

A theoreticians view (Francis Halzen, IceCube PI) :

1.04 ± 0.14 PeV 1.14 ± 0.14 PeV 2.00 ± 0.26 PeV

slide-52
SLIDE 52

.

Follow-up Search

for contained and semi-contained events

52
  • find contained events below the energy threshold
  • f the “Bert-and-Ernie” analysis

– same dataset, 662 days of livetime

  • Use outer IceCube layers as incoming track veto

– Additional atmospheric muon veto – Sensitive to all flavors in region above ~ 60TeV – Muon background can be estimated from data

μ Veto μ νμ

✓ ✘

Effective volume

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory
slide-53
SLIDE 53

Some example events

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 53

declination: -0.4° deposited energy: 71TeV declination: -13.2° deposited energy: 82TeV declination: 40.3° deposited energy: 253TeV

slide-54
SLIDE 54

Excess of HE Starting Tracks

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 54

Significance about 5.7 σ

First observation of astrophysical flux of high energy neutrinos

Starting events depositing >60 TeV using 3 years of data, events up to ~2 PeV

  • Phys. Rev. Lett. 113, 101101
slide-55
SLIDE 55

Global Fit to 6 Different Measurements

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 55

Simplest model: flux and flavor ratio

Results:

Flavor ratio compatible with

„prompt“ < 2 × ERS

slide-56
SLIDE 56

Skymap

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 56

equatorial coordinates

no significant correlation with galactic plane

p-value: 7%

slide-57
SLIDE 57

Blazars or GRB as Sources?

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 57

Compare directions of the high energy νμ with directions of Blazars observed by Fermi Satellite at high γ luminosity Even more stringent for GRB: from analysis of 506 GRBs in four years it was found that no more than 1% of the high energy neutrinos could come from GRB 1% atmost from GRBs high luminosity 17% atmost from Blazars

slide-58
SLIDE 58
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 58

Anything new down there?

slide-59
SLIDE 59

CONCLUSION

  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 59

„Alles Wissen und alle Vermehrung unseres Wissens endet nicht mit einem Schlußpunkt, sondern mit Fragezeichen“

Hermann Hesse .

?

… imagine Sisyphos to be happy

»… il faut imaginer Sisyphe heureux« A.Camus

slide-60
SLIDE 60
  • Coll. Ljubljana, 16. 3. 2015
H.Kolanoski - IceCube Neutrino Observatory 60
slide-61
SLIDE 61
