HARVESTER

FROM ITALY WITH EXPERIENCE AND INNOVATION

LEADER IN FRUIT HARVESTING

Tecnofruit

PRESENT IN 27 COUNTRY’S

FIELD TEST SERVICE AND

AFTER SALE

1.200 SATISFIED GROWERS TECHNICAL COURSE

THIS IS THE WORLD OF ALWAYS NEXT TO OUR PARTNERS

THE DEVELOPEMENT OF Tecnofruit ALLWAYS COME FROM NEEDS FORM THE GROWER AND HIS SUGGESTION’S

OUR TEAM CAN BOAST MORE THAN 30 YEARS FIELD EXPERIENCE IN HARVESTING

Tecnofruit CF 110 Tecnofruit CF 105 Tecnofruit CF levelling

the begin: 1970

NOW

NUFRI – SPAIN 150 Tecnofruit solded

“With Tecnofruit machines we managed to increase the capacity of the fruit harvest optimizing the staff number needed, and consequently the related management costs and also achieving high quality of the

• product. Only with Tecnofruit is possible to manage the harvesting season in our company.”

PETER PULINX – Belgium 40 Tecnofruit solded

“Thanks to Tecnofruit we managed to limit the harvesting waste, achieving a significantly superior fruit quality compared to the traditional methods used before. The collection system based on belts turned out to be an ideal system for a quality harvest.”

EINAN PELECH – ISRAEL 20 Tecnofruit solded

“Our agricultural holding deals with the harvest of different type of fruits. We can count on an innovative machinery which is Tecnofruit that help us to improve our organization of work, guaranteeing efficacy, velocity and a stable method during the harvest. Moreover, in Frumaco Europe Srl company we find an open mind and understanding to the growers needs.”

ERIC DESCHAMBAULT – CANADA 12 Tecnofruit solded

“We have 8 machines with excellent harvesting results… and this is only the beginning.”

25 COUNTRY – MORE THAN 1.200 SATISFIED GROWERS

BENEFITS OF USING Tecnofruit

 HIGH HARVESTING PERFORMANCE (TILL 350 KG/HOUR/PERSON)

LABOUR COST REDUCED

 VERY SOFT CONVERIANCE OF THE FRUIT, DIRECT IN THE BINS TROUGHT A GENTLE CONVEJOR BELT SYSTEM

BETTER FRUIT HARVEST QUALITY THAN ANY OTHER HARVESTING SYSTEM WITH LESS DAMAGES ON THE FRUITS

 HARVESTING OF THE COMPLET FRUIT WALL (TOP/LOW) WITH EQUIVALENT FRUIT QUALITY (COLOUR/SIZE)

SHORTER HARVESTING TIME ALLOW TO PICK THE FRUIT IN THE IDEAL STAGE OF MATURATION WIDE FLEXIBILITY (HARVESTING, PRUNING, THINNING, HAIL NETS HANDLING, MANUAL THINNING) USER FRIENDLY & EASY TO USE, HIGH RELIABILITY, MAINTENANCE FAST, EASY AND CONVENIENT

HIGHT HARVESTING PERFORMANC OF USING Tecnofruit

Flexibility On the machine can operate together 2-7 workers. The number of workers depends from the sort, the picking time and from the plant. So TECNOFRUIT allow to be very flexible in all kind of modern orchards. Conveying of the fruits Each worker has one lateral belt on which he provide to lay two fruits at time on the belts. The fruits are transported from the lateral belt’s to the main central belt and from them to a vertical filler that provide to fill automatically the bin… from the hand of the workers directly to the bins, without any intermediary step (boxes, …). That allow to get high level of quality. Picking level’s To increase the picking capacity the different lateral platforms allow to “divided” the plant in 2 or 3 levels: I level: 2 persons on the ground II level: 2 persons (one on each side) on the mid platform’s III level: 2 persons (one on each side) on the back platform’s The different level’s allow to pick in one time the full fruit wall reducing the picking time and in crease the quality.

LABOUR COST REDUCING USING Tecnofruit

PICKING by HAND PICKING with TECNOFRUIT

Average harvesting capacity: 125 kg/h/person Average harvesting capacity: 280 kg/h/person Labour cost (LOW LEVEL COST) : 1,60 €/hour Harvesting cost (1,60kg/125€): 0,013 €/Kg Harvesting cost (1,60kg/280€): 0,0057 €/Kg Average productivity (TON/ha): 50 Harvesting cost for 1 hectare: 650

Euro

Harvesting cost for 1 hectare: 285 Euro COSTS REDUCING -56%

BY HAND

550 285

Tecnofruit

*example

SOFT CONVERIANCE OF THE FRUITS USING Tecnofruit

Starting from the material

• f

the belts (developed in many years of experience), the passages from

• ne

belt to the next

• ne,

brushes positioned in the dedicated passages

• f the fruits and not at least the vertical filler, all

this take always care of the quality of the fruits. Also a key element responsible for the quality of the crop is the directly filling of the bins. Most of the traditional harvesting system need few steps between the hand of the picker and the

• bin. All additional handling causing damages
• n the fruits .

Let us make an example: Farm with 50 ha – total production 2.500 TON – difference price between first class fruit and industry fruit: Euro/kg 0,10 HARVESTING SYSTEM

TRADITIONAL CROP Tecnofruit

Average % of demage 4% 0,70% Total Kg of frist class loss 100.000 Kg 17.500 Kg Money loss 10.000,00 € 1.750,00 €

8.250,00 €

SHORTER HARVESTING TIME OF USING Tecnofruit

Tecnofruit FRUITS ON THE BEST

MATURATION:

• Better and longer cool storage

capacity

• Better price because the fruits can

be offered to the marked very fast

BY HAND LONGER HARVESTING TIME:

• Risk to have fruits not in the best

maturation

• Risk for the cool storage capacity

TIME REQUIRED FOR HARVESTING MATURATION

BEGIN OF THE HARVESTING

HARVESTING WINDOW IDEAL MATURATION

ENDING OF THE HARVESTING

MATURATION

WIDE FLEXIBLITY USING Tecnofruit

PRUNING HARVESTING HAIL NETS HANDLING

Tecnofruit A REAL WORKING CENTER

USER FRIENDLY (easy to use) and SIMPLY MAINTENANCE USING Tecnofruit

ALWAYS THE TECNOLOGIES HAS TO BE AT THE SERVICE OF THE USER. OTHERWISE THERE IS A RISK THAT THE TECNOLOGY WILL BE UNLESS. there is real progress only when the benefits of a new technology for everybody (Henry Ford) THE SIMPLIFICTY OF FRUMACO MACHINES ALLOW EVERYBODY TO UNTERSTAND HOW THE MACHINE WORKS. HYDRAULIC AND ELECTRICAL SYSTEMS ARE MADE FOR EASY AND FAST SERVICE AND MAINTENANCE, FOR EVERYBODY.

QUALITY, SIMPLICITY, EFFICIENCY, PERFORMANCE, FLEXIBILITY, ERGONOMIC HANDLING

THAT MAKES Tecnofruit TO A MODEN AND PROFESSIONAL HARVESTER

THE ideal MODEL for all MODERN STYLE ORCHARDS

Tecnofruit

3.00 – 3.80 m Up to 3.80 m

Tecnofruit

3.70 – 4.50 m Up to 4.50 m

Tecnofruit TOTAL FLEXIBILITY

Hail net platform

Manually

driving

system Automatic

driving

system Industry fruit container Air compresso r Adjustmen t speed belts 4WD Radio Remote controlled platform

CF-105 Tecnofruit

CF-110 Tecnofruit

CF-105 levelling Tecnofruit

Tecnofruit

Bins trailer

AUTOMATIC BINS TRAILER Tecnofruit CP-04 HANDLING OF THE FULL AND THE EMPTY BINS

• 5 Hyd. movements controlled by the harvester
• Easy and fast changing full/empty bins
• It’s the perfect solution for an integrate harvesting site

MANUAL BINS TRAILER Tecnofruit s-trailer HANDLING OF THE FULL AND THE EMPTY BINS

• Easy solution to handle full/empty bins
• Download of the full bins on the ground
• It’s the perfect solution short lines

THANK YOU FOR YOUR ATTENTION

Stefan Scharrer – sales manager
