Hardware Algos Made Easy: Deploy your trading strategies on FPGAs - - PowerPoint PPT Presentation
Hardware Algos Made Easy: Deploy your trading strategies on FPGAs - - PowerPoint PPT Presentation
Hardware Algos Made Easy: Deploy your trading strategies on FPGAs with the nxAccess HLS Framework May 2019 1 nxAccess HLS Framework Increasing volumes & tough competition The challenges of leveraging FPGA technology nxAccess HLS
SLIDE 2
SLIDE 3
- Full featured, full hardware FPGA feed handler:
- Hardware order management & book building
- A/B arbitration (supports wireless & fiber feeds)
- Filtering per symbol, message type, and book depth
- Full featured, FPGA-enabled execution gateway:
- Pre-load up to 16 384 orders or groups of orders in FPGA
- Full hardware TCP stack
- In-FPGA kill switch & Full audit-trail
- Easy integration:
- Interface with trading application via lean C++ API
- Standard network connectivity
- Hardware trading logic:
- Sub 800ns latency
- Normalized interfaces
nxAccess HLS Framework
What is nxAccess?
The Enyx end-to-end market access solution
SLIDE 4
- Framework based on Xilinx Vivado HLS:
- C++ based language
- Enyx HLS libraries:
- Enyx market data API
- Enyx execution API
- Basic functions
- Enyx C++ software libraries
- Feed handler configuration and monitoring
- Execution engine configuration and monitoring
- Hardware/software bi-directional communication
- Enyx development tools:
- Software simulation models
- Packaging and building scripts
- Graphical debugging tools
nxAccess HLS Framework
What if I don’t have hardware expertise?
An innovative approach to FPGA trading strategies
SLIDE 5
HLS Development Software Unit Tests
Seconds Minutes Hour
Firmware Generation
Hours
Production Deployment
Enyx Firmware Netlist
Hardware Synthesis Hardware Co-simulation
nxAccess HLS Framework
How does it work?
A step by step workflow for best efficiency
SLIDE 6
nxAccess HLS Framework
What is the performance?
Tick-to-cancel & tick-to-trade running @250MHz 24 ns
Latency Interval 24 ns 1 clk
SLIDE 7
nxAccess HLS Framework
What is the performance?
CME Globex tick-to-trade, Wire-to-wire, SOP-to-SOP, 1x replay, 300 Bytes orders
Test Duration Sample Count Minimum Average 90% Maximum 1 hour 4391 750 ns 776 ns 765 ns 1 773 ns * * Maximums are due to the 10Gbs throughput limit causing queuing of orders when several orders are sent at once
SLIDE 8
- Market data coverage: 60+ venues
- Equities, Futures, Treasuries, Options
- USA, Europe, Asia
- Native execution coverage: 3 venues
- CME
- ICE
- Eurex
- Pass-through deployment: 60+ venues
- Enyx exchange-agnostic OE API allows for support of
most venues using a pass-through deployment
- Interactions with the exchange and building of messages
and orders is left to a third party library
nxAccess HLS Framework
What exchanges are supported?
nxAccess is designed to scale across venues
SLIDE 9
nxAccess HLS Framework
How can you try the nxAccess HLS framework
Code examples, documentation, and tutorials are available on our website
SLIDE 10
nxAccess HLS Framework
How can you try the nxAccess HLS framework
Code examples, documentation, and tutorials are available on our website
SLIDE 11
nxAccess HLS Framework
How can you try the nxAccess HLS framework
Code examples, documentation, and tutorials are available on our website
SLIDE 12
nxAccess HLS Framework
nxAccess HLS framework in summary
Leveraging FPGA technology efficiently
SLIDE 13
nxAccess HLS Framework
Any Questions?
Learn more about the nxAccess HLS framework:
http://info.enyx.com/nxAccess-HLS
