Handling Flash Crowds From Your Garage Jeremy Elson and Jon Howell Microsoft Research USENIX ATC 2008 Tuesday, August 3, 2010 Scaling For Many Users Tuesday, August 3, 2010 Scaling For Many Users... quickly Tuesday, August 3, 2010 Scaling

slide-1
SLIDE 1

Handling Flash Crowds From Your Garage

Jeremy Elson and Jon Howell Microsoft Research USENIX ATC 2008

Tuesday, August 3, 2010

slide-2
SLIDE 2

Scaling For Many Users

Tuesday, August 3, 2010

slide-3
SLIDE 3

Scaling For Many Users... quickly

Tuesday, August 3, 2010

slide-4
SLIDE 4

Scaling For Many Users... quickly... on a budget

Tuesday, August 3, 2010

slide-5
SLIDE 5

Enabled by Utility Computing

  • Pay proportional to use
  • Minimal Starting Cost (often free!)
  • Quickly scalable

Tuesday, August 3, 2010

slide-6
SLIDE 6

Examples of Utility Computing

Tuesday, August 3, 2010

slide-7
SLIDE 7

Storage Data Networks

Tuesday, August 3, 2010

slide-8
SLIDE 8

Storage Data Networks

  • SDNs store static content in large clusters
  • Expose HTTP interface

Tuesday, August 3, 2010

slide-9
SLIDE 9

Storage Data Networks

  • SDNs store static content in large clusters
  • Expose HTTP interface
  • Different from CDNs:
  • No startup or recurring cost
  • Fee based on usage

Tuesday, August 3, 2010

slide-10
SLIDE 10

Storage Data Networks

  • SDNs store static content in large clusters
  • Expose HTTP interface
  • Different from CDNs:
  • No startup or recurring cost
  • Fee based on usage
  • Examples: S3, Nirvanix

Tuesday, August 3, 2010

slide-11
SLIDE 11

Storage Data Networks

  • SDNs store static content in large clusters
  • Expose HTTP interface
  • Different from CDNs:
  • No startup or recurring cost
  • Fee based on usage
  • Examples: S3, Nirvanix

Tuesday, August 3, 2010

slide-12
SLIDE 12

Compute Clouds

  • Allow developers to configure and save a VM


  • Instantiate images as needed
  • Fee based on “compute units”
  • Examples: EC2, Flexiscale

Tuesday, August 3, 2010

slide-13
SLIDE 13

DNS Outsourcing

  • Used to host authoritative DNS servers
  • Many replicas provide reliability and

performance

  • Examples: UltraDNS and DynDNS

Tuesday, August 3, 2010

slide-14
SLIDE 14

Outline

  • Introduction
  • Examples of Utility Computing
  • Scaling Architectures
  • Analyzing the Design Space
  • Application Experiences

Tuesday, August 3, 2010

slide-15
SLIDE 15

Scaling Architectures

Tuesday, August 3, 2010

slide-16
SLIDE 16

Using the bare SDN

  • Works only if content is predominantly

static

Tuesday, August 3, 2010

slide-17
SLIDE 17

HTTP Redirection

  • Uses a dedicated

redirection server

  • Redirects to server S
  • n first access
  • All future interactions

with server S

Re- director

Tuesday, August 3, 2010

slide-18
SLIDE 18

HTTP Redirection

  • Uses a dedicated

redirection server

  • Redirects to server S
  • n first access
  • All future interactions

with server S

Re- director

Tuesday, August 3, 2010

slide-19
SLIDE 19

L4/L7 Load Balancing

  • Spread incoming traffic

across servers

  • Spreading based on

source TCP port or HTTP session

  • Free/utility load

balancers available:

  • HAProxy, Linux

Virtual Server, Flexiscale, EC2 Load balancing

Tuesday, August 3, 2010

slide-20
SLIDE 20

DNS Load Balancing

  • Advertise many IP

addresses for single hostname

  • Use DNS to spread

load across servers

  • Example: RightScale, or

build your own using UltraDNS

  • Relies on good DNS

resolver behavior

Tuesday, August 3, 2010

slide-21
SLIDE 21

DNS Load Balancing

Tuesday, August 3, 2010

slide-22
SLIDE 22

DNS Load Balancing

  • Advertise many IP

addresses for single hostname

  • Use DNS to spread

load across servers

Tuesday, August 3, 2010

slide-23
SLIDE 23

DNS Load Balancing

  • Advertise many IP

addresses for single hostname

  • Use DNS to spread

load across servers

  • Example: RightScale, or

build your own using UltraDNS

Tuesday, August 3, 2010

slide-24
SLIDE 24

DNS Load Balancing

  • Advertise many IP

addresses for single hostname

  • Use DNS to spread

load across servers

  • Example: RightScale, or

build your own using UltraDNS

  • Relies on good DNS

resolver behavior

Tuesday, August 3, 2010

slide-25
SLIDE 25

Outline

  • Introduction
  • Examples of Utility Computing
  • Scaling Architectures
  • Analyzing the Design Space
  • Application Experiences

Tuesday, August 3, 2010

slide-26
SLIDE 26

Analyzing the Design Space

  • Application Scope
  • Scale Limitation
  • Scale-up Time
  • Fault Tolerance

Tuesday, August 3, 2010

slide-27
SLIDE 27

Application Scope

  • SDN: Only HTTP

Tuesday, August 3, 2010

slide-28
SLIDE 28

Application Scope

  • SDN: Only HTTP
  • HTTP Redirection: Only HTTP

Tuesday, August 3, 2010

slide-29
SLIDE 29

Application Scope

  • SDN: Only HTTP
  • HTTP Redirection: Only HTTP
  • L7 Load Balancing: All apps with the same

L7 protocol

Tuesday, August 3, 2010

slide-30
SLIDE 30

Application Scope

  • SDN: Only HTTP
  • HTTP Redirection: Only HTTP
  • L7 Load Balancing: All apps with the same

L7 protocol

  • L4/DNS Load Balancing: All apps

Tuesday, August 3, 2010

slide-31
SLIDE 31

Scale Limitations

  • SDNs: Limited only by provider’s SLA

Tuesday, August 3, 2010

slide-32
SLIDE 32

Scale Limitations

  • SDNs: Limited only by provider’s SLA
  • HTTP Redirection: Very scalable if client

sessions long

Tuesday, August 3, 2010

slide-33
SLIDE 33

Scale Limitations

  • SDNs: Limited only by provider’s SLA
  • HTTP Redirection: Very scalable if client

sessions long

  • L4/L7 Load Balancing: Scales if app is not

communication-bound

Tuesday, August 3, 2010

slide-34
SLIDE 34

Scale Limitations

  • SDNs: Limited only by provider’s SLA
  • HTTP Redirection: Very scalable if client

sessions long

  • L4/L7 Load Balancing: Scales if app is not

communication-bound

  • DNS Load Balancing: Scales to thousands of

servers

Tuesday, August 3, 2010

slide-35
SLIDE 35

Scale Limitations

  • SDNs: Limited only by provider’s SLA
  • HTTP Redirection: Very scalable if client

sessions long

  • L4/L7 Load Balancing: Scales if app is not

communication-bound

  • DNS Load Balancing: Scales to thousands of

servers

Tuesday, August 3, 2010

slide-36
SLIDE 36

Scale-Up Times

Tuesday, August 3, 2010

slide-37
SLIDE 37

Scale-Up Times

  • SDN: Scales up very quickly

Tuesday, August 3, 2010

slide-38
SLIDE 38

Scale-Up Times

  • SDN: Scales up very quickly
  • L4/L7 Load Balancing+HTTP Redirection
  • ~1-minute scale-up time

Tuesday, August 3, 2010

slide-39
SLIDE 39

Scale-Up Times

  • SDN: Scales up very quickly
  • L4/L7 Load Balancing+HTTP Redirection
  • ~1-minute scale-up time
  • DNS Load Balancing
  • Scale-up time hampered by DNS caching

Tuesday, August 3, 2010

slide-40
SLIDE 40

Front-End Failures

  • SDN: Failure unlikely

Tuesday, August 3, 2010

slide-41
SLIDE 41

Front-End Failures

  • SDN: Failure unlikely
  • L4/L7 Load Balancers
  • Single load-balancer fails miserably
  • Need hot spares or DNS load-balanced front-ends

Tuesday, August 3, 2010

slide-42
SLIDE 42

Front-End Failures

  • SDN: Failure unlikely
  • L4/L7 Load Balancers
  • Single load-balancer fails miserably
  • Need hot spares or DNS load-balanced front-ends
  • HTTP Redirectors
  • Existing sessions don’t fail

Tuesday, August 3, 2010

slide-43
SLIDE 43

Front-End Failures

  • SDN: Failure unlikely
  • L4/L7 Load Balancers
  • Single load-balancer fails miserably
  • Need hot spares or DNS load-balanced front-ends
  • HTTP Redirectors
  • Existing sessions don’t fail
  • DNS Load Balancers
  • With replicated DNS, failover is very quick

Tuesday, August 3, 2010

slide-44
SLIDE 44

Latency when DNS Servers Fail

Tuesday, August 3, 2010

slide-45
SLIDE 45

Back-end Failures

  • SDN: Not our problem!

Tuesday, August 3, 2010

slide-46
SLIDE 46

Back-end Failures

  • SDN: Not our problem!
  • HTTP Redirector+L4/L7 Load Balancer
  • Transient failures at worst

Tuesday, August 3, 2010

slide-47
SLIDE 47

Back-end Failures

  • SDN: Not our problem!
  • HTTP Redirector+L4/L7 Load Balancer
  • Transient failures at worst
  • DNS Load Balancer
  • Bad! Several minutes of delay...

Tuesday, August 3, 2010

slide-48
SLIDE 48

Application Experiences

Tuesday, August 3, 2010

slide-49
SLIDE 49

MapCruncher

  • Tool to author AJAX-style interactive maps
  • Server only retrieved from a 25 GB set of

map images

  • S3 solved the flash crowd problem
  • ~$200 total cost

Tuesday, August 3, 2010

slide-50
SLIDE 50

Asirra CAPTCHA service

  • Images stored in S3
  • Based on EC2 and Python
  • DNS-based load balancing
  • Handled 75,000 requests on first day,

including a DOS attack

  • Starting more servers solved the DOS

problem

Tuesday, August 3, 2010

slide-51
SLIDE 51

InkblotPassword.com

  • Implemented in Python and EC2
  • No code optimization
  • Depend on starting new servers for scale
  • ~10,000 users registered in a day
  • ~$150 spent to handle Slashdotting

Tuesday, August 3, 2010

slide-52
SLIDE 52

Conclusion

  • Utility computing enables cheap handling of

flash crowds

  • No “best” architecture
  • Depends on application workload
  • Enable scaling to many instances instead of
  • ptimizing one instance

Tuesday, August 3, 2010

slide-53
SLIDE 53

Tuesday, August 3, 2010
