Are you watching TV now? Is it real?: Hacking of smart TV with 0-day Hack in paris 2017 Security Analysis aNd Evaluation(SANE) Lab. Jongho Lee, Mingeun Kim*, Seungjoo Kim** hellsonic@korea.ac.kr, pr0v3rbs@kaist.ac.kr, skim71@korea.ac.kr CIST
Security Analysis aNd Evaluation(SANE) Lab.
Jongho Lee, Mingeun Kim*, Seungjoo Kim**
hellsonic@korea.ac.kr, pr0v3rbs@kaist.ac.kr, skim71@korea.ac.kr
CIST (Center for Information Security Technologies), Korea University
*KAIST **Corresponding Author
2
4
5
Hack er er Hacker
Kernel Vulnerability App Vulnerability Network Vulnerability … webOS based Smart TV Malware Install Invasion of Privacy Pirate Broadcasting
“Making hacking scenarios and demonstrate it, for smart TV through analysis of webOS vulnerability.”
7
2008
Selected as Palm's next generation OS
2009
webOS (CES 2009)
iPhone 3GS)
Pixi
2010
HP products
announcement
2011 2012
announcement
before webOS Project announcement
2013
smart TV and Internet of things
8
Web SW Platform Native SW Platform C , C++ , Java HTML , JavaScript
Apple iOS Android Ubuntu OS Firefox OS Chrome OS webOS
efficiency
affected by SW and HW platforms
standards
9
Application is runs in browser that uses HTML, JavaScript, HTTP, etc.
Development environment based on Enyo Web App Framework Increase of system scalability
(Embedded-optimized Luna Bus system)
Maximize the use of JavaScript (Node.js service framework)
webOS Features
Convenient Development Dependency Mitigation Code Portability
10
webOS Features
that use the private bus.
Luna Bus
11
/usr/bin/WebAppMgr /usr/sbin/activitymanager /usr/sbin/sam /usr/palm/nodejs/unified_service_server.js /usr/sbin/appinstalld
▪ Processes that run non-web-based applications ▪ Chrome-based QTWebEngine program that runs webOS app ▪ A service process that manages all activities(apps, services, networks, etc.) running on the device ▪ Nodejs local server to run the webOS app ▪ Service process that creates and manages files when installing Application
webOS structure
12
Emulator analysis
13
Why Analyze Emulator?
activitymanager sam WebAppMgr appinstalld Node.js service
▪ Has a similar environment with real TV ▪ Was provided for application testing ▪ Rooting easily (maybe?) ▪ We can attack, even virtual disk! ▪ We can predict attack vectors for real TV
14
▪ The mount order is partition 1 through 4. ▪ boot ▪ / ▪ LUKS Encrypt ▪ appstore ▪ Partition 2 has a script that decrypts Partition 3. ▪ On encrypted Partition 3, there will be a scripts to execute the important daemon.
Partitions of webOS Emulator
15
Part rtit itio ion 3 decr cryptio ion pro rogram
▪ Analysis of service configuration file executed at emulator boot time
Partition 2 configuration file analysis
▪ /home/root/openV ▪ Partition 3 decryption program found.
16
Partitions of webOS Emulator
▪ Partition 3 decrypted with the decryption key found by strace
17
exec /usr/sbin/dropbear –w –g -B -F -d /var/lib/dropbear/dropbear_dss_host_key
exec /usr/sbin/dropbear –B –F –d /var/lib/dropbear/dropbear_dss_host_key -r /var/lib/dropbear/dropbear_rsa_host_key
Modify the dropbear option in 12.sh
Modify the dropbear option inside Partition 3
18
root shell Emulator root shell
19
Each application was sandboxed.
webOS
/
/var/palm/jail/{app}
Application
Application Sandbox
20
▪ Remote Control ▪ Different binary ▪ Different work process ▪ ssh daemon ▪ Openssh ▪ FrameBuffer ▪ Can’t access with root privilege ▪ Architecture ▪ ARM
Other difference
22
Key Process
upnpd appinstalld ls-hubd bsa_server sam ss.apiadapter Daemon receiving application install command Daemons for communication between applications HTTP protocol as a daemon for plug & play communication Pass the command through Helps to run non-web-based applications. Bluetooth server for communication with remote control Daemon that sends and receives commands when remote control
23
Analysis of input vector as hacking path ls-hubd
Commands in Luna protocol for application communication
Vulnerability due to xml tampering. (BOF, Command Injection)
Modify command received from remote control
Replay attack, hidden service?
Ability to modulate XML, HTTP header information when connecting to
Possible memory vulnerability(BOF)
ss.apiadapter upnpd WebAppMgr / Nodejs server bsa_server
Page modifiable by user creating application. Running applications on the Node.js server.
Vulnerability in Chrome browser possible Node.js server vulnerability attack target
The remote control modulates the transmitted Bluetooth signal and attacks the running server
Possible replay attack vulnerability Possible BOF memory corruption vulnerability
24
Analysis of input vector as hacking path
▪ Process luna protocol data centrally ▪ Transfers commands to a system or other apps ▪ Maybe has a vulnerabilities about… ▪ Command injection
ls-hubd
Commands in Luna protocol for application communication
Vulnerability due to xml tampering. (BOF, Command Injection)
25
Analysis of input vector as hacking path
▪ Communicate with mobile remote control ▪ Receives general TV functions (WSS) ▪ Receives touchpad inputs (WS) ▪ Maybe has a vulnerabilities about… ▪ Command injection ▪ Replay attack by capturing the packet
ss.apiadapter
Modify command received from remote control
Replay attack
26
Analysis of input vector as hacking path upnpd
Ability to modulate XML, HTTP header information when connecting to
BOF, CSRF, command injection
▪ Broadcasts to announce the presence of TV ▪ Sends and receives upnp packets ▪ Maybe has a vulnerabilities about… ▪ CSRF ▪ Command Injection
27
Analysis of input vector as hacking path WebAppMgr / Nodejs server
Page modifiable by user creating application. Running applications on the Node.js server.
Vulnerability in Chrome browser possible Node.js server vulnerability attack target
▪ Runs the webOS application ▪ Uses QtWebEngine based on chrome ▪ Maybe has a vulnerabilities about… ▪ Chrome ▪ Nodejs
28
Analysis of input vector as hacking path bsa_server
The remote control modulates the transmitted Bluetooth signal and attacks the running server
Possible replay attack vulnerability Possible BOF memory corruption vulnerability
▪ Communicates with remote control using BT ▪ Used for air-mouse and sending voice data ▪ Maybe has a vulnerabilities about… ▪ Replay attack by using captured BT data
29
Analysis of input vector as hacking path
30
Vulnerability with Incorrect Permission
Acc Access to to phy hysical memory ry with th pris isoner r priv ivile lege
31
Vulnerability with Incorrect Permission
32
Vulnerability with Incorrect Permission
Che hecking phy hysical memory ry af afte ter r bina nary executio ion
33
Vulnerability with Incorrect Permission
Program is loaded into memory Run the program Memory modulation Running a Modulated Program
34
Vulnerability with Incorrect Permission
Phys hysical Memory Modula latio ion
Obt btain in root root auth thorit ity
35
DirtyCOW Vulnerability
DirtyCOW Vulnerability
Vulnerability to write different contents to read-only area using Race Condition while executing Copy-On-Write function of Linux
CVE-2016-5195 code fix Check your TV's kernel code Ch Check for for poss possib ible Dirt rtyCOW vuln lnerabil ility
36
① Fi Find th the binary ry th that at has has se setu tuid id att attri ribute te
DirtyCOW Vulnerability
② Mak ake the he bi binary that hat ex executes the he she hell ll
37
① Fi Find th the binary ry th that at has has se setu tuid id att attri ribute te
DirtyCOW Vulnerability
Overwrite setuid-binary with the shell-binary to
Get root privileged shell!
② Mak ake a a bina nary th that at executes the the she shell
39
Hacker
커널 취약점 App 취약점 네트워크 취약점 …
Invasion of privacy
Hacker
커널 취약점 App 취약점 네트워크 취약점 …
Hacker
커널 취약점 App 취약점 네트워크 취약점
Force installation
Ha Hacker
커널 취약점 App 취약점 네트워크 취약점 …
Pirate broadcast
Remote control
40
Hacker
Country Enterprise Person
Developer Mode.
screen modulation
Pirate broadcasting
41
Developer Mode.
exporting information
log collection
Enterprise Person
Hacker
Exporting information
42
Screen Modulation & Pirate Broadcasting
43
Screen Modulation & Pirate Broadcasting
44
Check source code of FB device from webOS kernel source FB input/output routine found Create a kernel driver and successfully modifies the screen User level Kernel level
/dev/fbdriver fbdriver.ko
Screen tampering success!
Screen Modulation & Pirate Broadcasting
45
46
