Guarding Vulnerable Code: Module 2: Mitigation Mathias Payer, Purdue University http://hexhive.github.io 1 Defense: Testing vs. Mitigations Software Testing Mitigations Discover bugs Stop exploitation Development tool Always

slide-1
SLIDE 1

1

Guarding Vulnerable Code: Module 2: Mitigation

Mathias Payer, Purdue University http://hexhive.github.io

slide-2
SLIDE 2

2

Defense: Testing vs. Mitigations

Mitigations

  • Stop exploitation
  • Always on
  • Low overhead

Software Testing

  • Discover bugs
  • Development tool
  • Result oriented
slide-3
SLIDE 3

3

* The Matter of Heartbleed. Zakir Durumeric, James Kasten, J. Alex Halderman, Michael Bailey, Frank Li, Nicholas Weaver, Bernhard Amann, Jethro Beekman, Mathias Payer, Vern Paxson. In ACM IMC'14 (best paper)

Heartbleed: reactive patching*

  • 11% of servers remained

vulnerable after 48 hours

  • Patching plateaued at 4%
  • Only 10% of vulnerable sites

replaced certificates

  • 15% of replaced cert's used

vulnerable keys

Heartbleed vulnerable hosts

Update process is slow, incomplete, and faulty

slide-4
SLIDE 4

4

https://en.wikipedia.org/wiki/Pwn2Own

Bugs are everywhere?

slide-5
SLIDE 5

5

Different threat models

slide-6
SLIDE 6

6

Problem: broken abstractions?

C/C++ void log(int a) { printf("Log: "); printf("%d", a); } void (*fun)(int) = &log; void init() { fun(15); } ASM log: ... fun: .quad log init: ... movl $15, %edi movq fun(%rip), %rax call *%rax

slide-7
SLIDE 7

7

Control-Flow Hijack Attack

slide-8
SLIDE 8

8

Attack scenario: code injection

  • Force memory corruption to set up attack
  • Redirect control-flow to injected code

Code Heap Stack

slide-9
SLIDE 9

9

Attack scenario: code reuse

  • Find addresses of gadgets
  • Force memory corruption to set up attack
  • Redirect control-flow to gadget chain

Code Heap Stack

slide-10
SLIDE 10

10

Attacker model: hijacking control-flow

Attacker may read/write arbitrary data

– Code is read-only, vtables are read-only – Code pointers remain writable!

Code Heap Stack vtables RX R RW RW

slide-11
SLIDE 11

11

Demo Time!

slide-12
SLIDE 12

12

Control-Flow Bending

  • Attacker-controlled execution along valid CFG

– Generalization of non-control-data attacks

  • Each individual control-flow transfer is valid

– Execution trace may not match non-exploit case

  • Circumvents protection of CFI

Nicholas Carlini, Antonio Barresi, Mathias Payer, David Wagner, and Thomas R. Gross “Control-Flow Bending”, Usenix SEC'15

slide-13
SLIDE 13

13

What does a CFG look like?

system() vuln()

slide-14
SLIDE 14

14

What does a CFG look like? Really?

system() vuln() memcpy()

slide-15
SLIDE 15

15

Necessity of shadow stack*

  • Defenses without stack integrity are broken

– Loop through two calls to the same function – Choose any caller as return location

  • Shadow stack enforces stack integrity

– Attacker restricted to arbitrary targets on the stack – Each target can only be called once, in sequence

* Control-Flow Bending: On the Effectiveness of Control-Flow Integrity. Nicholas Carlini, Antonio Barresi, Mathias Payer, David Wagner, and Thomas R. Gross. In Usenix SEC'15

void func() { … bar(); … void bar() { … } bar(); … }

slide-16
SLIDE 16

16

CFB key lessons

  • CFI without shadow stack is broken

– Stateless defenses insufficient for stack attacks

  • Turing-complete programming in most contexts

– Bend execution to dispatcher/functional gadgets – In case study CFI not effective for 5/6 vulnerabilities

  • Attack is program-dependent, harder to pull off
slide-17
SLIDE 17

17

Counterfeit OO Programming

  • OO-programs use vtables for inheritance
  • Introduce fake objects

– Use valid vtables – Functions become gadgets – Chaining functions gives Turing-completeness

  • Stateless defenses struggle

Felix Schuster, Thomas Tendyck, Christopher Liebchen, Lucas Davi, Ahmed-Reza Sadeghi, and Thorsten Holz. Counterfeit Object-Oriented Programming, Oakland'15

slide-18
SLIDE 18

18

Mitigation space in a nutshell [SP13]

Memory/type safety Integrity Confidentiality Flow Integrity Bad things

C *C &C *&C Corruption

Code corruption Control-flow hijack

C &C *&C

SoftBound [PLDI09, POPL12, ISCA12]; CCured [POPL02]; DShield/nC [2x AsiaCCS17] Code Integrity [AMD06]; SafeO [FSE03]; WIT [SP08]; CPI [OSDI14]; OTI [NDSS18] ASLR [CCS03, 04, 10, 12]; DSR [DIMVA08]; PG [SEC03]; Diversity SoK [SP14]; CFI [CCS05]; MCFI [PLDI14]; FCFI [SEC14]; vTrust [NDSS17]; SoK [CSUR17]

slide-19
SLIDE 19

19

Attack classification

  • Data-only attack

– Overwriting arguments to exec()

  • Non-control-data attack

– Overwriting is_admin flag

  • Control-Flow Bending

– Modify function pointer to (valid) alternate target

slide-20
SLIDE 20

20

Control-Flow Integrity

slide-21
SLIDE 21

21

Control-Flow Integrity (CFI)*

  • Restrict a program’s dynamic control-flow to the

static control-flow graph

– Requires static analysis – Dynamic enforcement mechanism

* Control-Flow Integrity. Martin Abadi, Mihai Budiu, Ulfar Erlingsson, Jay Ligatti. CCS ‘05 * Control-Flow Integrity: Protection, Security, and Performance. Nathan Burow, Scott A. Carr, Joseph Nash, Per Larsen, Michael Franz, Stefan Brunthaler, Mathias Payer. ACM CSUR ‘17

slide-22
SLIDE 22

22

Control-Flow Integrity (CFI)

CHECK(fn); (*fn)(x); CHECK_RET(); return 7;

slide-23
SLIDE 23

23

Three directions for CFI

Goal: minimize target sets, increase precision

slide-24
SLIDE 24

24

Enforce CFI in the kernel*

  • Kernel protection crucial for system integrity
  • So far, kernel only coarsely protected (if at all)
  • Enforce strict pointer propagation rules

– Function pointers can only be assigned – Data pointers to function pointers are forbidden

  • Compiler enforces type system, instruments
  • High compatibility for hypervisors, kernels

* Fine-Grained Control-Flow Integrity for Kernel Software. Xinyang Ge, Nirupama Talele, Mathias Payer, and Trent Jaeger. In EuroS&P'16

slide-25
SLIDE 25

25

Lockdown*: enforce CFI for binaries

  • Fine-grained CFI relies on source code
  • Coarse-grained CFI is imprecise
  • Goal: enforce fine-grained CFI for binaries

– Support legacy, binary code and modularity (libraries) – Leverage precise, dynamic analysis – Low performance overhead

  • Binary translator runs online analysis, adds checks

* Fine-Grained Control-Flow Integrity through Binary Hardening Mathias Payer, Antonio Barresi, and Thomas R. Gross. In DIMVA'15

slide-26
SLIDE 26

26

Enforce CFI for C++ applications*

  • C++ applications are prone to Counterfeit

Object-Oriented Programming (COOP)

  • Virtual inheritance scatters code pointers
  • Protect all virtual function calls

– Enforce type check of prototype for virtual calls – Sanitize VTable pointers before use

  • Compiler encodes types and enforces checks

* VTrust: Regaining Trust on Your Virtual Calls. Chao Zhang, Scott A. Carr, Tongxin Li, Yu Ding, Chengyu Song, Mathias Payer, and Dawn Song. In NDSS'16

slide-27
SLIDE 27

27

CFI: analysis precision [CSUR17]

Greeter *o = new Greeter();

  • ->sayHi(char *str); // o[0][1]();

Valid functions Arity Prototype Class Hierarchy

ShrinkWrap [ACSAC15]; VTrust [NDSS17]; LLVM-CFI [head] MCFI [CCS13, PLDI14]; RockJIT [CCS14]; PICFI [CCS15]; C-CFI [CCS15]; PathArmor [CCS15]; KCFI [EuroSP16] CFI? [CCS05]; FCFI [SEC14] kBouncer [SEC13]; CCFIR [SP13]; binCFI [SEC13]; ROPecker [NDSS14]; DynCFI [DIMVA15]

slide-28
SLIDE 28

28

CFI: strength of analysis

Greeter *o = new Greeter();

  • ->sayHi(char *str);

0xf000b400 int bar1(int b, int c, int d); int bar2(char *str); void bar3(char *str); void B::foo(char *str); class Greeter :: Base {... }; void Base::bar5(char *str); void Greeter::sayHi(char *str); class Related :: Greeter {... }; void Related::sayHi(char *str);

slide-29
SLIDE 29

29

Are we making progress?

2007 2017

slide-30
SLIDE 30

30

Class hierarchy depth

  • Impl. Count Chromium

Firefox [1-10] 13,751 (99.33%) 4,632 (99.90%) >10 78 (0.57%) 47 (0.10%) Max 78 107

CFI prohibits use of corrupted pointer. Can we do better?

slide-31
SLIDE 31

31

Summary: Control-Flow Integrity

  • CFI restricts indirect control-flow to target set

– Inherently stateless defense – Effectiveness depends on precision of analysis and

program functionality

– Low performance overhead

  • Limitations

– Large target sets, statelessness – Backward edge often neglected

slide-32
SLIDE 32

32

Object-Type Integrity

slide-33
SLIDE 33

33

Two stages of control-flow hijacking

  • Stage 1: corrupt a code pointer

– Overwrite where with what?

  • Stage 2: dereference the code pointer

– Guide execution to dispatch

slide-34
SLIDE 34

34

Mitigation space in a nutshell [SP13]

Memory/type safety Integrity Confidentiality Flow Integrity Bad things

C *C &C *&C Corruption

Code corruption Control-flow hijack

C &C *&C

SoftBound [PLDI09, POPL12, ISCA12]; CCured [POPL02]; DShield/nC [2x AsiaCCS17] Code Integrity [AMD06]; SafeO [FSE03]; WIT [SP08]; CPI [OSDI14]; OTI [NDSS18] ASLR [CCS03, 04, 10, 12]; DSR [DIMVA08]; PG [SEC03]; Diversity SoK [SP14]; CFI [CCS05]; MCFI [PLDI14]; FCFI [SEC14]; vTrust [NDSS17]; SoK [CSUR17]

slide-35
SLIDE 35

35

Object Type Integrity (OTI)*

  • Enforce integrity of vtable pointer

– Relocate to safe area – Use protected version for dispatch

* CFIXX: Object Type Integrity for C++ Virtual Dispatch. Nathan Burow, Derrick McKee, Scott A. Carr, and Mathias Payer. In ISOC NDSS '18 Code Heap Stack Safe memory area vtables

slide-36
SLIDE 36

36

CFIXX instrumentation

  • C++ dynamic dispatch has single target

– Only constructor allowed to write vtable pointer – Deallocation invalidates vtable pointer – Dispatch uses vtable pointer

  • Enforcing OTI protects against

– VTable injection even with correct method signature – Swap vtable even in the same hierarchy – Fake object creation (COOP)

slide-37
SLIDE 37

37

CFIXX performance

  • Chromium: 2.03% (Octane), 1.99% (Kraken)
slide-38
SLIDE 38

38

Future Directions

slide-39
SLIDE 39

39

slide-40
SLIDE 40

40

Future trends in software security

Memory/type safety Integrity Confidentiality Flow Integrity Bad things

C *C D *D &C *&C &D *&D Memory/type corruption

Code corruption Data-only attack Control-flow hijack

C &C &D *&C

slide-41
SLIDE 41

41

Defense: Testing vs. Mitigations

Mitigations

  • C++ type integrity
  • Data integrity
  • Compartments

Software Testing

  • Firmware fuzzing
  • Transform. fuzzing
  • Data-flow testing
slide-42
SLIDE 42

42

Conclusion

slide-43
SLIDE 43

43

  • CFI makes attacks harder

– Effectiveness depends on analysis and complexity – Deployed in Microsoft Edge, Google Chrome – Limitation: large equivalence classes

  • Object Type Integrity (CFIXX)

– Protect object instead of dispatch – Single valid target per object

  • Future direction: type check / overhead

Conclusion

Source: https://github.com/HexHive/CFIXX
