[PPT] - Altitude Terrain Guarding and Guarding Uni-Monotone Polygons PowerPoint Presentation

SLIDE 1

Stephan Friedrichs Valentin Polishchuk Christiane Schmidt

Altitude Terrain Guarding and Guarding Uni-Monotone Polygons

SLIDE 2

EuroCG 2018 2

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png https://www.dronerush.com/best-drones-1977/drone.bmp

SLIDE 3

EuroCG 2018 2

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png https://www.dronerush.com/best-drones-1977/drone.bmp

SLIDE 4

EuroCG 2018 2

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png https://www.dronerush.com/best-drones-1977/drone.bmp

SLIDE 5

EuroCG 2018 2

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png https://www.dronerush.com/best-drones-1977/drone.bmp

SLIDE 6

EuroCG 2018 2

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png https://www.dronerush.com/best-drones-1977/drone.bmp

SLIDE 7

EuroCG 2018 3

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png

SLIDE 8

EuroCG 2018 3

image source: http://2.bp.blogspot.com/-eUnhAo8SfFQ/VDaLij2_csI/AAAAAAAABPM/847rgT6VpQE/s1600/Screen%2BShot%2B2014-05-01%2Bat%2B00.02.54.png

2.5D

SLIDE 9

EuroCG 2018 3

2.5D 1.5D

SLIDE 10

EuroCG 2018

Altitude Terrain Guarding Problem

4

SLIDE 11

EuroCG 2018

Altitude Terrain Guarding Problem

4

SLIDE 12

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T

SLIDE 13

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

SLIDE 14

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn}

SLIDE 15

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} Monotonicity

SLIDE 16

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} Monotonicity ➡ Points on T are totally ordered wrt to x-coordinate: p<q .

SLIDE 17

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). p ∈ A q ∈ T

SLIDE 18

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). p ∈ A q ∈ T q2 ∈ T

SLIDE 19

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). p ∈ A q ∈ T q2 ∈ T

SLIDE 20

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). VT(p) is the visibility region of p with VT(p) := {q∈T | p sees q} . p ∈ A q ∈ T

SLIDE 21

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). VT(p) is the visibility region of p with VT(p) := {q∈T | p sees q} . For G⊆A VT(G) := ∪g∈G VT(g). p ∈ A q ∈ T

SLIDE 22

EuroCG 2018

Altitude Terrain Guarding Problem

4

Terrain T Altitude line A

x-monotone chain of line segments in R2 defined by its vertices V(T) = { v1 , . . . , vn} A point p ∈ A sees or covers q ∈ T if and only if pq is nowhere below T (i.e. pq lies on or above T ). VT(p) is the visibility region of p with VT(p) := {q∈T | p sees q} . For G⊆A VT(G) := ∪g∈G VT(g). p ∈ A q ∈ T Altitude Terrain Guarding Problem (ATGP) ATGP(T,A) Given: a terrain T and an altitude line A . A minimum set of guards that see all of T. (Formally: A guard set G⊂A is optimal w.r.t. ATGP(T,A) if G is feasible, that is, T⊆VT(G) , and |G| = OPT(T,A) := min{|C| | C⊂A is feasible w.r.t. ATGP(T,A)} .)

SLIDE 23

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon?

SLIDE 24

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? monotone polygon

SLIDE 25

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? monotone polygon

SLIDE 26

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? monotone polygon

SLIDE 27

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

SLIDE 28

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

H

SLIDE 29

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

H

LC(P)

SLIDE 30

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

H

p ∈ P LC(P)

SLIDE 31

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

H

p ∈ P VP(p) - visibility polygon LC(P)

SLIDE 32

EuroCG 2018

AGP in uni-monotone polygons

5

uni-monotone polygon? uni-monotone polygon

H

p ∈ P VP(p) - visibility polygon Formally: Art Gallery Problem (AGP) AGP(G,W) Given: a polygon P and sets of guard candidates and points to cover G,W⊆P. A minimum guard set C⊆G that covers W (that is, W⊆VP(C)). We want to solve AGP(P,P). LC(P)

SLIDE 33

EuroCG 2018

AGP in uni-monotone polygons

6

If we want to solve the AGP for a uni-monotone polygon, w.l.o.g. we can restrict our guards to be located on H.

SLIDE 34

EuroCG 2018

AGP in uni-monotone polygons

6

If we want to solve the AGP for a uni-monotone polygon, w.l.o.g. we can restrict our guards to be located on H. Proof: Consider any optimal guard set G, let g∈G be a guard not located on H

SLIDE 35

EuroCG 2018

AGP in uni-monotone polygons

6

If we want to solve the AGP for a uni-monotone polygon, w.l.o.g. we can restrict our guards to be located on H. Proof: Consider any optimal guard set G, let g∈G be a guard not located on H

SLIDE 36

EuroCG 2018

AGP in uni-monotone polygons

6

If we want to solve the AGP for a uni-monotone polygon, w.l.o.g. we can restrict our guards to be located on H. Proof: Consider any optimal guard set G, let g∈G be a guard not located on H

SLIDE 37

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G).

SLIDE 38

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G)

SLIDE 39

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G)

SLIDE 40

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G)

SLIDE 41

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G)

SLIDE 42

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G)

SLIDE 43

EuroCG 2018

AGP in uni-monotone polygons

7

Let P be a uni-monotone polygon, let G be a guard set with g∈H ∀g∈G that covers LC(P), that is, LC(P)⊂VP(G) . Then G covers all of P, that is, P⊆VP(G). Proof: Assume p∈P, p∉LC(P), p∉VP(G) ➜ATGP and AGP for uni-monotone polygons equivalent

SLIDE 44

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

SLIDE 45

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard

SLIDE 46

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard NP-hard, even in monotone polygons

SLIDE 47

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard NP-hard, even in monotone polygons

Altitude Terrain Guarding Problem (ATGP) Given: a terrain T and an altitude line A . A minimum set of guards that see all of T.

SLIDE 48

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard NP-hard, even in monotone polygons

Altitude Terrain Guarding Problem (ATGP) Given: a terrain T and an altitude line A . A minimum set of guards that see all of T. Art Gallery Problem (AGP) in Uni-Monotone Polygons Given: a uni-monotone polygon P. A minimum guard set that covers P.

SLIDE 49

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard NP-hard, even in monotone polygons

Our Problems: “Inbetween”?!

Altitude Terrain Guarding Problem (ATGP) Given: a terrain T and an altitude line A . A minimum set of guards that see all of T. Art Gallery Problem (AGP) in Uni-Monotone Polygons Given: a uni-monotone polygon P. A minimum guard set that covers P.

SLIDE 50

EuroCG 2018

AGP-TGP-ATGP

8

Terrain Guarding Problem (TGP) Given: a terrain T. Find: minimum number of guards located on T. Art Gallery Problem (AGP) Given: a polygon P. A minimum guard set that covers P.

NP-hard NP-hard, even in monotone polygons Both polytime

Our Problems: “Inbetween”?!

Altitude Terrain Guarding Problem (ATGP) Given: a terrain T and an altitude line A . A minimum set of guards that see all of T. Art Gallery Problem (AGP) in Uni-Monotone Polygons Given: a uni-monotone polygon P. A minimum guard set that covers P.

SLIDE 51

EuroCG 2018 9

We show:

SLIDE 52

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons

SLIDE 53

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

SLIDE 54

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

SLIDE 55

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

A set W⊂P (W⊂T ) is a witness set if ∀wi≠wj ∈W we have VP(wi)∩VP(wj) = ∅.

SLIDE 56

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

A set W⊂P (W⊂T ) is a witness set if ∀wi≠wj ∈W we have VP(wi)∩VP(wj) = ∅.

SLIDE 57

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

A set W⊂P (W⊂T ) is a witness set if ∀wi≠wj ∈W we have VP(wi)∩VP(wj) = ∅. A maximum witness set Wopt is a witness set of maximum cardinality, |Wopt| = max{|W|: witness set W}.

SLIDE 58

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

A set W⊂P (W⊂T ) is a witness set if ∀wi≠wj ∈W we have VP(wi)∩VP(wj) = ∅. A maximum witness set Wopt is a witness set of maximum cardinality, |Wopt| = max{|W|: witness set W}. A polygon class P is perfect if

SLIDE 59

EuroCG 2018 9

We show:

A polytime algorithm for AGTP and AGP in uni-monotone polygons
Uni-monotone polygons are perfect - first non-trivial class

perfect ?

A set W⊂P (W⊂T ) is a witness set if ∀wi≠wj ∈W we have VP(wi)∩VP(wj) = ∅. A maximum witness set Wopt is a witness set of maximum cardinality, |Wopt| = max{|W|: witness set W}. A polygon class P is perfect if cardinality of an optimum guard set = cardinality of a maximum witness set ∀P∈P

SLIDE 60

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 61

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 62

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 63

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 64

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 65

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 66

EuroCG 2018

Altitude Terrain Guarding Problem

10

Guards to the left “don’t help”:

SLIDE 67

EuroCG 2018

Sweep Algorithm

11

SLIDE 68

EuroCG 2018

Sweep Algorithm

11

SLIDE 69

EuroCG 2018

Sweep Algorithm

11

SLIDE 70

EuroCG 2018

Sweep Algorithm

11

SLIDE 71

EuroCG 2018

Sweep Algorithm

11

SLIDE 72

EuroCG 2018

Sweep Algorithm

11

SLIDE 73

EuroCG 2018

Sweep Algorithm

11

SLIDE 74

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

SLIDE 75

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right

SLIDE 76

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.

SLIDE 77

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)

SLIDE 78

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg

SLIDE 79

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

SLIDE 80

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

SLIDE 81

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

Delete pec and add pe’c to C

SLIDE 82

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

Delete pec and add pe’c to C
Delete e from Eg and add e’

SLIDE 83

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

Delete pec and add pe’c to C
Delete e from Eg and add e’

SLIDE 84

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

Delete pec and add pe’c to C
Delete e from Eg and add e’

SLIDE 85

EuroCG 2018

Sweep Algorithm

12

Start: empty set of guards G = ∅ ; at leftmost point of A ; all edges in E(T) are completely unseen

(Eg=E(T)).

Sweep along A from left to right
Place a guard gi whenever we could no longer see all of an “edge” e if we would move more to the right
first point in C.
Compute VT(gi)
Remove all completely seen edges from Eg
For each edge e = {v,w} partially seen by gi: split edge, keep the open interval that is not yet guarded

—>new “edge” e’⊂e

Delete pec and add pe’c to C
Delete e from Eg and add e’

SLIDE 86

EuroCG 2018
