Group R14300 Digital Microfluidics Peter Dunning Paulina - - PowerPoint PPT Presentation

Group R14300 Digital Microfluidics Peter Dunning Paulina Klimkiewicz Matthew Partacz Andrew Greeley Thomas Wossner Wunna Kyaw Problem Statement Need for point of care medical testing devices where access to conventional tests is


slide-1
SLIDE 1

Group R14300 – Digital Microfluidics

Peter Dunning Paulina Klimkiewicz Matthew Partacz Andrew Greeley Thomas Wossner Wunna Kyaw

slide-2
SLIDE 2

Problem Statement

  • Need for point of care medical testing devices where

access to conventional tests is restricted

  • Ex: Doctor’s Offices, Remote Areas, Battlefields
  • A solution must be portable and cheap
slide-3
SLIDE 3

Problem Statement

  • Lab-on-a-chip devices

are capable of miniaturizing and automating biological protocols.

  • Devices suited for

commercial use have just started to be developed.

http://2.imimg.com/data2/GK/EX/MY-920622/micro-biological-testing-250x250.jpg http://www.lionixbv.nl/technology/technology-microfluidics.html

slide-4
SLIDE 4

Digital Microfluidic Devices - Electro-wetting

Cross-section view of Digital Microfluidic device. Dotted line indicates the shape of the meniscus before

  • actuation. Modified from [2]

“Top view of flow on a ring structure” [3]

  • Array of electrodes which use

the electrowetting effect to manipulate droplets.

slide-5
SLIDE 5

Voice of the Customer

slide-6
SLIDE 6

Voice of the Customer

slide-7
SLIDE 7

Functional Decomposition

Much room for creativity Little to no room for creativity Medium amt. of room for creativity

slide-8
SLIDE 8

Project Breakdown

  • Control System
  • Fluid Delivery System
  • Fabrication
  • Automation
  • User Interface
  • Packaging
slide-9
SLIDE 9

Control System - Specs and Metrics

Problem: Can an Arduino board be used to control a DMF device

to the same or better accuracy as a NI PXI control system?

What Do We Need?

  • Generate a sine wave
  • Amplify the wave to a large voltage (~90-110 Vrms)
  • Measure capacitance with a good resolution (~0.2pF)
  • Complete the protocol quickly (~30min)
  • Move/Merge droplets quickly (~100ms)
  • Split droplets quickly (~500ms)

What Do We Know?

  • Benchmark: Dr. Schertzer completed these protocols at the

University of Toronto using a National Instruments (NI) control system, a signal generator, and an amplifier

slide-10
SLIDE 10

Control System - Potential Concepts

Benchmark - Control System used in Schertzer et al

  • 1. NI PXI System
  • a. Signal Generator
  • i. Voltage: 10Vp-p
  • ii. Frequency: 10kHz
  • b. Controller
  • c. Matrix-Switching Device (4

inputs / 32 outputs)

  • 2. Agilent 4288A Capacitance Meter
  • a. Resolution to ~0.20 pF
  • 3. Custom Amplifier
  • a. Voltage: 90-110 Vrms
slide-11
SLIDE 11

Control System - Potential Concepts

  • Generates a sine wave
  • Voltage: up to 20 Vp-p
  • Frequency: (0.1-50)kHz

Signal Generator Board Control Board

  • Controls is a shield for the

Arduino Microcontroller Switching Board

Arduino Dropbot System in Fobel et al

Trek Model PZD700A High Voltage Amplifier

  • Input Voltage: 0 to ±10 VDC
  • Output Voltage: 0 to ±700 VDC
  • Droplet was found to

completely cover an electrode in 200ms

  • Arduino is open source
  • firmware
  • pin mapping
  • board schematics
  • KiCAD Hardware designs

available for Board designs

  • 320 independent channels and is

highly modular

slide-12
SLIDE 12

Control System - Potential Concepts

  • Controls Signal Generator Board, High Voltage Switching Board
  • Can estimate drop position, velocity
  • Software Available:
  • Arduino firmware
  • C++ Software
  • Microdrop Plugin

Arduino Mega 2560 Microcontroller

  • Arduino is open source
  • firmware
  • pin mapping
  • board schematics
  • KiCAD Hardware designs

available for Board designs

  • 320 independent channels and is

highly modular

Arduino Dropbot System in Fobel et al

slide-13
SLIDE 13

Control System - Feasibility

  • The Arduino Dropbot system used in

Fobel et al paper was able to instantaneously measure droplet velocity, capacitance, and impedance in real time.

  • Arduino has:

a. Software: C++ software, Open source firmware b. Hardware: Microcontroller with board schematics, and pin mapping

  • Dropbot has:

a. Software: Open source firmware, Microdrop Plugin b. Hardware: KiCAD models to create the boards Potential Staffing Needed

  • Mechanical Engineering
  • Electrical Engineering
  • Software Engineering
  • Computer Engineering
slide-14
SLIDE 14

Fluid Delivery System-HOQ

slide-15
SLIDE 15

Fluid Delivery System-Specs and Metrics

Problem: Is there a specific delivery system so that the desired volume of fluid can be extracted within the desired time? What We Need

  • Droplet to be extracted between .5s and 5s.
  • Droplet Volume must be within 3% error of desired

volume. What We Know

  • Conventional Biological Protocols have been using

pipettes and Syringes

  • Duke University have used Reservoirs in their DMF

Devices.

slide-16
SLIDE 16

Fluid Delivery System-Concepts

  • Syringe
  • .55 L ± .028
  • Pipette
  • 1µL ± 4%
  • Reservoir
  • Volume from User Input
  • Plug-in Canister
  • Desired Volume can be extracted
  • Combination of These
slide-17
SLIDE 17

Fluid Delivery System- Feasibility

  • Solutions
  • Reservoir system will allow us to easily dispense

the fluids to the DMF device.

  • Using together with Pipettes will allow us to

accurately dispense the desired droplet volume.

  • Plug-in Canister can be programmed to dispense

the right amount while easily detachable and portable.

  • Staffing Required:
  • Students in the Mechanical Engineering discipline
  • Students in the Industrial Engineering discipline
slide-18
SLIDE 18

Fabrication- HOQ

[10]

slide-19
SLIDE 19

Fabrication: Potential Concepts

Common Techniques:Photolithography and wet or dry etching (clean room) Solutions outside the clean room:

  • PDMS stamp used to transfer a

pattern onto a gold surface

  • Desktop laser printer pattern

transfer: directly onto sheet of polyimide

  • Permanent marker electrode array
  • utline

Dielectric: Saran wrap Hydrophobic coating: Rain-X

slide-20
SLIDE 20

Fabrication: Feasibility

Microcontact printing (microCP) [7]

  • PDMS stamp used to deposit patterns of self assembled

monolayers onto a substrate

  • device capable of full range of operations: dispensing,

merging, motion and splitting Formed from circuit board substrates and gold compact disks using rapid marker masking [8]

  • procedure capable of producing devices with 50-60 μm

spacing between actuating electrodes

  • saran wrap used a removable dielectric coating
  • rain-x: hydrophobic coating
  • able to move merge and split 1-12 μL droplets

Desktop Laser Printer Pattern transfer [9]

  • Droplet motion: comparable to performance on chips

made by photolithography

  • ultrarapid: 80 chips in 10 mins
slide-21
SLIDE 21

Automation - HOQ

slide-22
SLIDE 22

Automation - Specs and Metrics

Problem: Can a protocol be automated using existing

computing methods and hardware?

What Do We Need?

  • Data Storage (~0.5GB)
  • Send Signal
  • Receive Signals
  • Processor (>10kHz, ~0.5GB)
  • Motion Planning

What Do We Know?

  • Many algorithm based computing solutions

already exist, just must be tailored for this specific application

slide-23
SLIDE 23

Automation - Potential Concepts

How to compute:

  • Existing computer
  • On-board processor
  • Open-source system

Function:

  • Inputs: state of each electrode, protocol
  • Process: compute necessary move, merge, mix &

split instructions for a specified protocol

  • Outputs: signals to activate control system

switches, error signal to the user interface, result

slide-24
SLIDE 24

Automation - Feasibility

Needed Features: Available Solutions:

Data Storage Memory Card, HD, SSD, Peripheral networking, ROM cartridge Send Signals Analog signals, digital signals Receive Signals Many ways to process signals.. Processor Micro-processor, multi-core processor Motion Planning Grid based algorithm, Sampling based algorithm

Each feature has many well known solutions. This project is determined to be feasible.

slide-25
SLIDE 25

User Interface HOQ

slide-26
SLIDE 26

User Interface - Potential Concepts

  • Computer program w/ visual

display (i.e. LabVIEW VI)

  • Touchpad
  • Manual input (i.e. turn dials)
  • Remote communication (i.e.

email)

  • LED indicators
  • Combination of these

LabVIEW Front Panel [4] Example of “lab

  • n a chip” [5]

Handheld DMF device [6]

slide-27
SLIDE 27

User Interface - Feasibility

Technical Feasibility

  • Concepts for the user interface exist in many forms
  • Many existing DMF devices are able to accept

instructions and output results via a user interface.

  • Example: RIT currently uses LabVIEW interface

provided by National Instruments Staffing Requirements A few IE, ME, and EE students, possibly a CE as well

slide-28
SLIDE 28

Packaging HOQ

slide-29
SLIDE 29

Packaging-Concepts

Minimizing Evaporation

  • Humidity sensing/control
  • Humidifier/hygrometer/controls
  • Temperature sensing/control
  • Refrigerator/thermometer/controls
  • Hybrid
slide-30
SLIDE 30

Packaging-Feasibility

Verify that size and weight constraints are met: Staff required: Several ME students, several EE students, possibly IE students

slide-31
SLIDE 31

Questions/Areas of Uncertainty

  • How will environmental controls be

implemented?

  • Chip form factor?
slide-32
SLIDE 32

Next Steps

  • Confirm ER’s
  • Continue to refine HOQs
  • Examine resource and staffing

requirements

  • Begin PRP development
slide-33
SLIDE 33
  • [1] Mark, D., Haeberle, S., Roth, G., Von Stetten, F., and Zengerle, R., 2010, "Microfluidic Lab-on-a-

Chip Platforms: Requirements, Characteristics and Applications," Chemical Society Reviews, 39(3),

  • pp. 1153-1182.
  • [2] Cho, S. K., Moon, H. J., and Kim, C. J., 2003, "Creating, Transporting, Cutting, and Merging Liquid

Droplets by Electrowetting-Based Actuation for Digital Microfluidic Circuits," Journal of Microelectromechanical Systems, 12(1), pp. 70-80.

  • [3] Fair, R., The Electrowetting Effect (in Air), February 1, http://microfluidics.ee.duke.edu/
  • [4] http://www.mstarlabs.com/software/labview.html
  • [5] http://www.inc.com/magazine/201111/innovation-a-blood-test- on-a-chip.html
  • [6] http://doktori.bme.hu/bme_palyazat/2011/tudomanyos_muhely/ szenzorlabor_en.htm
  • [7] Watson, Michael W. L., Mohamed Abdelgawad, George Ye, Neal Yonson, Justin Trottier, and Aaron
  • R. Wheeler. "Microcontact Printing-Based Fabrication of Digital Microfluidic Devices." Analytical

Chemistry 78.22 (2006): 7877-885. Print.

  • [8] Abdelgawad, Mohamed, and Aaron R. Wheeler. "Low-cost, Rapid-prototyping of Digital

Microfluidics Devices." Microfluidics and Nanofluidics 4.4 (2008): 349-55. Print.

  • [9] Abdelgawad, M., and A. R. Wheeler. "Rapid Prototyping in Copper Substrates for Digital

Microfluidics." Advanced Materials 19.1 (2007): 133-37. Print.

  • [10] Schertzer, M. J., R. Ben-Mrad, and Pierre E. Sullivan. "Mechanical Filtration of Particles in

Electrowetting on Dielectric Devices." Journal of Microelectromechanical Systems 20.4 (2011): 1010-

  • 015. Print.

References

slide-34
SLIDE 34

End Questions?
